- Page 1 ADVANCED METROLOGY SOLUTIONS MODEL 3000HR HIGH RESISTANCE STANDARD OPERATION MANUAL www. transmille.com...
- Page 2 3000HR Series High Resistance Standard Operation Manual Version 1.50 March 2021 All product names are trademarks of their respective companies...
-
Page 3: Guarantee And Service
OPERATION MANUAL Guarantee and Service Transmille Ltd. guarantees this instrument to be free from defects under normal use and service for a period of 1 year from purchase. This guarantee applies only to the original purchaser and does not cover fuses, or any instrument which, in Transmille’s opinion, has been modified, misused or subjected to abnormal handling or operating conditions. -
Page 4: Table Of Contents
GUARANTEE AND SERVICE ................... 2 SETTING AND CHECKING THE LINE VOLTAGE ........... 4 POWER LINE INLET FUSE ..................4 3000HR HIGH RESISTANCE STANDARD ............... 5 MAIN FEATURES ..................... 5 DESIGN NOTES ......................6 FRONT PANEL CONNECTIONS & CONTROLS ............. 6 REAR PANEL CONNECTIONS ................ -
Page 5: Setting And Checking The Line Voltage
3000HR HIGH RESISTANCE STANDARD OPERATION MANUAL Setting and checking the Line Voltage Warning: The line power cord must have an earth conductor to avoid risk of shock. This instrument must be correctly earthed. This instrument has been designed to work from either 100-120 Volt line supply or 200 - 240 Volt line supply. -
Page 6: 3000Hr High Resistance Standard
OPERATION MANUAL 3000HR High Resistance Standard The 3000HR is a designed as a dedicated high resistance standard, transfer standard as well as for calibration support for Transmille products The stability and temperature co-efficients of the 3000HR are designed for a working environment of 18-23°C and the standard is supplied complete with a calibration certificate. -
Page 7: Design Notes
3000HR HIGH RESISTANCE STANDARD OPERATION MANUAL Design Notes The 3000HR is built using precision resistors – no adjustable resistors are used within the design of this reference. Preset decade values can be selected using a RANGE button to step through in sequence with the selected decade displayed via LED indicator. -
Page 8: Rear Panel Connections
3000HR HIGH RESISTANCE STANDARD OPERATION MANUAL Rear Panel Connections Connection IEC Inlet Line Input 9 Way ‘D’ connector RS232 interface Connect to computer via USB to RS232 converter for computers with a USB port Label Reference Information Model Number Model number reference for product... -
Page 9: Operational Parameters
3000HR HIGH RESISTANCE STANDARD OPERATION MANUAL Operational Parameters CAUTION Do not apply voltages above the maximum ratings detailed below. Excessive voltage can cause permanent damage and affect the nominal resistance values of the reference. Preset Decade Outputs STABILITY / VOLTAGE... -
Page 10: Range : 10 To 100 Gohm Resistor Bank
3000HR HIGH RESISTANCE STANDARD OPERATION MANUAL Range : 1 to 10 GOhm Resistor Bank STABILITY / VOLTAGE TEMPERATURE VALUE YEAR RATING COEFFICIENT 1 GOhm 2 GOhm 3 GOhm 4 GOhm 5 GOhm 100 ppm / °C 6 GOhm 7 GOhm... -
Page 11: Operation Overview
3000HR HIGH RESISTANCE STANDARD OPERATION MANUAL Operation Overview Principle of Operation High value resistance measurements above 100MΩ traditionally require careful consideration with regards to noise / interference. The principle of the high resistance standard is to allow measurements to be taken at lower resistance values where a measurement can be achieved with lower noise / interference levels. -
Page 12: Individual Resistor Measurement : 10Gω Bank
3000HR HIGH RESISTANCE STANDARD OPERATION MANUAL Individual Resistor Measurement : 10GΩ Bank Connect between each bank position to measure each individual 1GΩ resistor To determine the 10GΩ value, calculate the sum of 1GΩ resistor values 10GΩ = R Individual Resistor Measurement : 100GΩ Bank Connect between each bank position to measure each individual 10GΩ... -
Page 13: Preset Decade Values
3000HR HIGH RESISTANCE STANDARD OPERATION MANUAL Preset Decade Values To select preset decade values, simply connect to the I Output and V Input and use the RANGE button to cycle through 10MΩ to 100GΩ. Note : The RANGE button will automatically set the output to the 10MΩ value again after the selected range reaches the 100GΩ... -
Page 14: User Selected Values
3000HR HIGH RESISTANCE STANDARD OPERATION MANUAL User Selected Values To select a value from the 10GΩ bank or 100GΩ bank, simply connect the first test lead to the relevant COMMON terminal, and connect the second lead to the terminal with the desired value, for example : 10GΩ... -
Page 15: Remote Commands
3000HR HIGH RESISTANCE STANDARD OPERATION MANUAL Remote Commands The preset decade values can be selected via the RS232 interface. The interface uses a standard 9 pin PC connector and a standard serial lead. The standard can be sent individual commands... -
Page 16: Specifications
3000HR HIGH RESISTANCE STANDARD OPERATION MANUAL Specifications GENERAL SPECIFICATIONS DESCRIPTION High Resistance Reference / Transfer Standard INTERFACE RS232 via 9 pin ‘D’ type connector fitted to rear panel INDICATORS 5 x LED Indicators for 5 preset output ranges OUTPUTS 10 MOhm... - Page 17 3000HR HIGH RESISTANCE STANDARD OPERATION MANUAL PERFORMANCE SPECIFICATIONS Range : Preset Decade Outputs STABILITY / VOLTAGE TEMPERATURE VALUE YEAR RATING COEFFICIENT 10 MOhm 0.01% 5 ppm / °C 100 MOhm 50 ppm / °C 1 GOhm 100 ppm / °C 10 GOhm 100 ppm / °C...
-
Page 18: Care & Maintenance
Cleaning the 30000HR To keep the external enclosure of the 3000HR in good condition, clean the outer case with a soft cloth. Do not use any liquids in cleaning the enclosure – removal of surface dust is all that is recommended. - Page 19 An unrivalled commitment to quality and innovation drives Transmille forwards, with a dedicated design and support Transmille was founded in 1995 as a commercial calibration team in house with a combined experience of over 60 years service, and soon after began to develop and manufacture...
