- Page 1 Instruction Manual RK-INLINE For sales, service or support call your local distributor or: 1800-BUY-RIVET 1-800-289-7483 www.rivet.com...
-
Page 2: Table Of Contents
ONTENTS Safety Page 3 Specifications Page 3 Preparing the tool for service Page 4 Air supply Page 4 Maintenance Daily Page 5 Assembly Drawings Schematic Addendum A Parts List Addendum B Page 10 Procedures Troubleshooting Page 11 Warranty Page 12... -
Page 3: Safety
AFETY RECOMMENDED BY O NOT USE OUTSIDE DEISNG INTENT OR WITH EQUIPMENT THAT IS NOT THE MANUFACTURER LWAYS DISCONNECT THE AIR SUPPLY BEFORE ATTEMPTING ANY MAINTENANCE OR ADJUSTMENT FITTING OF NOSE EQUIPMENT O NOT OPERATE A TOOL THAT IS DIRECTED TOWARDS ANY PERSON OR WITH THE NOSE PIECES OFF THE TOOL ... -
Page 4: Preparing The Tool For Service
REPARING THE TOOL FOR SERVICE I. Operation (A) Selection of rivet size Before riveting, there must of course be a hole in the materials to be rivets. Matching of hole and rivet sizes are very important. For example, where the outer diameter of the rivet is 3.2 mm, the hole diameter should be between 3.3-3.4 mm. -
Page 5: Maintenance
AINTENANCE In order to maintain the tool in a safe working order it is important to carry out regular maintenance as prescribed by the manufacturer. A thorough inspection replacement of all seals within the tool should be carried out after 500,000 placings or annually, whichever is the sooner. Item numbers in parentheses refer to assembly drawing part numbers Daily Maintenance ... - Page 6 PROCEDURES (A) CLEANING AND CHANG JAWS 1. Important: Disconnect the tool from the air pressure line. 2. Use WRENCH (66) to remove HEAD (2) and JAW HOUSING (3) at the same time hold the JAW HOUSING COUPLER (7) with an 14mm open end wrench. 3.
- Page 7 REMEDIES: 1. Increase air pressure but don't exceed 90 PSI at tool. Make sure all fittings including SCREW PLUG(50) and C. TOOL TAKES MORE THAN ONE STROKE UNDER IDEAL HEAD (2) are tight. If malfunction presists add oil as next procedure. CAUSES: 2.Dissemble AIR CYLINDER BODY (31) HYD.
-
Page 8: Schematic
SCHEMATIC PARTS LIST... - Page 9 Oil Details The recommended oil for priming is Hyspin VG32 available in 0.51 or one gallon containers, or, you can use 30W hydraulic oil. Please see safety data below. Hyspin VG 32 Oil Safety Data First Aid SKIN: Wash thoroughly with soap and water as soon as possible. Casual or short term contact requires no immediate attention.
-
Page 10: Troubleshooting
ROUBLESHOOTING Item numbers in parentheses refer to assembly drawing part numbers on page 9. Problem Possible Cause Remedy More than Air leak Tighten joints or replace components Insufficient air pressure Adjust air pressure to within specification operation of Air Lubrication Lubricate tool at air inlet point... - Page 11 Warranty Statement: Industrial Rivet & Fastener Co. Inc. and Zipp Tools (hereinafter “IRF”), hereby warrants to the initial retail customer and original distributor (“Warrantee”) only that its products will be free from defects in material and workmanship for a period of 1 year from the purchase date, provided that the products are used in accordance with “IRF’s”...
