- Page 1 Operation Manual Model# RK-59SPS For sales, service or support call your local distributor or: 1800-BUY-RIVET 1-800-289-7483 www.rivet.com...
-
Page 2: Table Of Contents
ONTENTS 1. GENERAL SAFETY INSTRUCTIONS AND PRINCIPLES 2. DESCRIPTION OF THE TOOL 2.1. Basic characteristics 2.2. Technical data 2.3. Range of usage 2.4. Tool operation 3. TOO L MAINTENANCE 3.1. Daily maintenance 3.2. Weekly maintenance 3.3. General maintenance 4. SPARE PA RTS 4.1 Ordering 4.2. -
Page 3: General Safety Instructions And Principles
1. GENERAL SAFETY INSTRUCTIONS AND PRINCIPLES ATTENTION! Read all instructions and principles carefully. Every person installing, operating or maintaining the tool must be first thoroughly acquainted with this operation manual and is obliged to adhere to the following safety instructions and principles: • The tool must not be used for other purposes than those for which it was designed. • The tool must not be used in a different manner than that recommended by the manufacturer • Any alterations of the tool, its accessories or spare parts remain in sole responsibility of the customer. -
Page 4: Description Of The Tool
2. DESCRIPTION OF THE TOOL 2.1. Basic characteristics 2.2. Technical data Weight: 4.9lbs / 2,23 kg Working pressure: 72.5-100psi / 0,5-- - 0,7 MPa Force @ 90 psi: 6,069 lbs / 27 Kn Air consumption: 2,5 l / stroke Stroke: .315’’ / 8 mm Height: 280 mm Length: 290 mm Width (over the aircoupling):... -
Page 5: Range Of Usage
2.3 Range of usage The pneumatic-hydraulic tool is designed for riveting with: rivet nuts 5/16-18’’~1/2-13’’ / M8-M12 rivet bolts ¼-20’’~5/16-18’’ / M6~M8 (steel) 2.4. Tool operation The manufacturer equipped the tool with a anvil and mandrel for rivet nuts __. For riveting of rivets with a different dimension, it is necessary to exchange the anvil and mandrel and change basic set up and regulation of the tool as following: 1) Loosen the counter-nut of the anvil... - Page 6 10) Adjust revolving air supply into any required position and connect the tool to the source of the compressed air. 11) Put the rivet on the mandrel and push towards the anvil, this will screw on the rivet. 12) Put the screwed rivet into the prepared hole. 13) Press the trigger and the rivet will be riveted in.
-
Page 7: Too L Maintenance
3. TOOL MAINTENANCE During maintenance the tool must be disconnected from the source of compressed air !!! 3.1. Daily maintenance Daily, before starting work, apply a drop of lubricating oil (we recommend hydraulic oil MOBIL DTE32) into the air inlet of the tool, on condition there is no lubricating device connected in the air distribution. Check the tool for air leakage, if necessary replace damaged hoses and clasps. -
Page 8: Spare Pa Rts
4. SPARE PARTS 4.1. Ordering Order the spare parts exclusively from the manufacturer or from your sales agents. The order must contain: a) tool serial number b) number of ordered part c) number of pieces d) name of your company and precise address e) your tax identification number and identification number 4.2. List of quickly expendable parts All types and dimensions of mandrels and anvils ..... see char in para 2.4 Front nozzle complete ............ RK55SPS‐600 Joint sleeve.. .............. RK55SPS‐400 ... -
Page 9: Storage
5. STORAGE the pneumatic‐hydraulic tool embedded in a shipping container must be stored in environment with relative humidity to 70% and temperature ranging from +5oc to +40oc, without aggressive evaporation of salts, acids and caustics. 6. COMPLETE TOOL EQUIPMENT Replaceable anvils and mandrels located in a plastic bag, operations manual. 7. OPERATIONS AND WARRANTY CONDITIONS 7.1. Operation conditions For reliable function of the tool, we recommend to use treated compressed air. treated compressed air means compressed atmospheric air bare of solid particles and water, reduced to required pressure and lubricated with anti‐corrosive oil. Immediately before the tool there must be a regulation valve set to maximum outlet pressure of 0,7 MPa, air filter and lubrication in the circuit of compressed air. Though sound-pressure level of impulse noise LpaI does not exceed ..db(a), still it is recommended to use ear protectors during continuous and long-term operation. average overall vibration total effective value ahv,8h = .. -
Page 10: Warranty Statement
Warranty Statement: Industrial Rivet & Fastener Co. Inc. (hereinafter “IRF”), hereby warrants to the initial retail customer or original authorized distributor (“Warrantee”) only that its products will be free from defects in material and workmanship for a period of 1 year from the purchase date provided that the products are used in accordance with “IRF’s”... -
Page 11: Msds
MSDS MSDS Lubricant Details MOLY GREASE MOBIL DTE 32 (MSC P/N: 60002136) Manufacturer: EXXONMOBIL Oil Corp., Fairfax, VA Emergency: (609)737-4411 (call collect) MSDS Number: 600684-00 Manufacturer: First Aid: T.S. Moly-Lubricants, Inc., Houston, TX SKIN: Emergency: (713)671-2676 Remove contaminated clothing and shoes and wipe excess MSDS Number: TS-122 Lithium EP-2 Moly Poly Grease from skin.
