What You Need - modway EEI-6336 Assembly Instructions Manual

Provided hardware:
A
Cam Lock Ø15 mm
B
Cam Bolt Ø7.5 x 32 mm
C
Cam Cover Ø17 mm
D Plastic Dowel 8 x 32 mm
E
Cover Shock Ø15 mm
F
Screw M 10 x 33.5 mm
G
Screw M 6 x 8 mm
H
Backply Stopper
I
Screw M 4 x 19 mm
Missing parts or hardware? Need assistance?
Contact us before returning your item. We're here to help!
609.256.9000 • cs@modway.com
x14 J
x14
K
x10
L
Ø x24
M
x2
N
x10
O
x8
P
x14
Q
x14
R

What you need:

x4
Push To Open
Screw M 3 x 12 mm x2
x12
Screw M 10 x 25 mm
Full Curve Door Hinge x4
Screw M 4 x 10 mm
x16
H-Profile x1
Shelf Pin 7 x 16.5 mm Ø x8
Half Curve Door Hinge x4
Wall Bracket Set x1
Phillips Head Screwdriver
Phillips
PAGE 3 OF 16
