Rack Adapter Panel
GRA-441
Assembly Manual
GW INSTEK PART NO. 82RA-44100M01
This assembly manual contains proprietary information, which is protected by copyrights. All rights are
reserved. No part of this manual may be photocopied, reproduced or translated to another language
without prior written consent of Good Will company.
The information in this manual was correct at the time of printing. However, Good Will continues to
improve products and reserves the rights to change specification, equipment, and maintenance
procedures at any time without notice.
Good Will Instrument Co., Ltd.
No. 7-1, Jhongsing Rd., Tucheng Dist., New Taipei City 236, Taiwan.
ISO-9001 CERTIFIED MANUFACTURER
Advertisement
Table of Contents
Related Manuals for GW Instek GRA-441
Summary of Contents for GW Instek GRA-441
- Page 1 Rack Adapter Panel GRA-441 Assembly Manual GW INSTEK PART NO. 82RA-44100M01 This assembly manual contains proprietary information, which is protected by copyrights. All rights are reserved. No part of this manual may be photocopied, reproduced or translated to another language without prior written consent of Good Will company.
- Page 2 GRA-441 Assembly Manual GRA-441 The GRA-441 rack mount is suited for the PPX DC Power Supply Series. The GRA-441 supports both the EIA (GRA-441-E) and JIS (GRA-441-J) standards for use with standard sized rack units. Rack Mount Adapter Component List and Assembly...
- Page 3 GRA-441 Assembly Manual 62RA-441HP201 *CA GRA-441 RIGHT BRACKET ,RoHS 1 62RA-410HPD01 CA GRA-410 RACK HP ,RoHS 599B-03006NS1 SCREW IMS ,+ ,3*6 ,ISO ,N ,RoHS SCREW PMS ,+ ,M3*8 ISO ,N (WASHER 592B-W3008NS1 P.S) ,RoHS 62RA-410HP9A1 CA GRA-410 RACK HP ,RoHS...
- Page 4 Assembly 62RA-441HP101 *CA GRA-441 LEFT BRACKET ,RoHS 5320-00403011 SNAP RIVET SR3-3.5 ,BLACK ,KY ,RoHS 62RA-441HP301 *CA GRA-441 HOLDER ,RoHS SCREW PMS ,+ ,3*6*0.5P ,ISO ,N 592B-W3006NS1 (WASHER P.S) ,RoHS 62RA-410HPC01 CA GRA-410-J TOP BRACKET ,RoHS Assembly Initial setup 1. Remove the handle (from) the unit.
- Page 5 GRA-441 Assembly Manual Instrument 1. Ensure the Middle Bracket is latched onto the catch on insertion the underside of the unit. Unit catch Middle Bracket 2. Attach the Front Bracket to the Middle Bracket with fastening the rack screws. Unit...
- Page 6 Appearance Blank panel 1. Insert the blank panel into the insertion groove of the Front and Middle Brackets. 2. Secure the panel with the PMS-W-3*8 screws. Blank Panel Appearance GRA-441-E...
- Page 7 GRA-441 Assembly Manual GRA-441-J...
- Page 8 Specification Specification Load Capacity Max 20kg Rack installation Diagram Please note the minimum width that is needed to be supported on the L-brackets.
