Summarization of Contents
Technical Specifications
General Specifications
Covers main supply voltage, input ratings, dimensions, weight, and operating environment.
Constant Voltage Operation
Describes output voltage adjustment, regulation, recovery time, ripple, and temperature coefficient.
Constant Current Operation
Outlines output current adjustment, regulation, and ripple characteristics.
Indicator Meter Specifications
Details digital and analog meter displays, accuracy, and dimensions.
Insulation Specifications
Specifies insulation resistance requirements for various connections.
Panel Controls and Indicators
Front Panel Controls
Describes front panel controls like indicators, coarse/fine adjustments, terminals, and meters.
Rear Panel Controls
Details rear panel components like fuse holder, power cord, AC select, Master-Slave switch, and connectors.
Operation Instructions
Precautions and Safety
Covers AC input, installation environment, and output voltage overshoot warnings.
Setting Current Limit
Step-by-step guide to setting the current limit using front panel controls.
Voltage/Current Characteristic
Explains the automatic crossover between constant voltage and constant current modes.
Operation Modes
Details procedures for single, series, and parallel operation of the power supply.
Remote Voltage Control
Explains how to remotely control the output voltage using an external voltage source.
Remote Current Control
Explains how to remotely control the output current using an external voltage source.
Maintenance and Adjustments
Fuse Replacement
Instructions for replacing blown fuses, including warnings and location.
Line Voltage Conversion
Procedure for changing the unit's operating line voltage using AC select switches.
Calibration Adjustments
Guidance on when and how to readjust the unit's voltage and current settings.
Cleaning Instructions
Instructions for cleaning the power supply using mild detergent and water.
