PRACTICAL USER'S GUIDE
ELECTRIC FIREPLACE
Serial Number
Model Number
CAT Number
Valued Customer,
We are pleased that you have chosen to purchase an electric
fi replace product manufactured by Dimplex North America Ltd.
Over the years, valuable memories will occur around the warmth
and comfort of your hearth. Thank you for allowing our product
to be the backdrop for those special moments.
EU
RU
UA
FOR THE DIMPLEX
MODEL NUMBER:
DF3220 series
FR
ES
IT
DE
PL
Quality checked by:
7208690100REV01

Advertisement

loading

Related Manuals for Dimplex purifire DF3220 Sseries

Summary of Contents for Dimplex purifire DF3220 Sseries

  • Page 1 Valued Customer, We are pleased that you have chosen to purchase an electric fi replace product manufactured by Dimplex North America Ltd. Over the years, valuable memories will occur around the warmth and comfort of your hearth. Thank you for allowing our product to be the backdrop for those special moments.

  • Page 2: Table Of Contents

    QUICK REFERENCE GUIDE 1. Prior to the fi rst use of the fi replace verify the following: • Are the circuit breakers for the unit on? • Are the light bulbs in your fi replace loose? (to check, follow the instructions for replacing the light bulbs under the Maintenance section of this manual) 2.

  • Page 3: Important Instructions

    IMPORTANT INSTRUCTIONS PLEASE RETAIN THIS USER’S GUIDE FOR FUTURE REFERENCE When using electrical appliances, basic precautions should always be followed to reduce the risk of fi re, electric shock, and injury to persons, including the following: 1. Read all instructions before using the electric fi replace. 2.

  • Page 4: Model And Serial Number Information

    NOTE: Procedures and techniques that are considered important enough to emphasize. CAUTION: Procedures and techniques, which, if not carefully followed, will result in damage to the equipment. WARNING: Procedures and techniques, which, if not carefully followed, will expose the user to the risk of fi...

  • Page 5: Site Selection And Preparation

    SITE SELECTION AND PREPARATION This section provides instructions for selecting a location and preparing the site to install the fi replace into your Dimplex mantel surround. 1. Select a suitable location that is not susceptible to moisture and is away from drapes, furniture and high traffi...
  • Page 6 2. Install the fi replace assembly into the mantel. (refer to mantel assembly instructions) IMPORTANT If not using a Dimplex mantel, the fi replace must be installed in an enclosure with the following MINIMUM internal/opening dimensions. (FIGURE 3) FIGURE 3...

  • Page 7: Operation

    OPERATION ELECTRIC FIREPLACE MANUAL CONTROL The manual controls for the fi replace are located in the upper right hand corner. (FIGURE 4) A. Main On/Off Switch Supplies power to the 3 position manual control switch. B. 3 Position Manual Control Switch Remote (left position): The unit is operated with the remote control.
  • Page 8 BATTERY INSTALLATION (FIGURE 5) FIGURE 5 1. Depress tab on the battery cover on the back of the remote transmitter and remove battery cover. Batteries 2. Install 2 AAA batteries into the remote control (included). 3. Ensure child lock is in the “unlocked” position. 4.
  • Page 9 REMOTE CONTROL FUNCTIONS (FIGURE 6) Room Temperature Set Temperature Temperature Temperature Up Down Dimmer Dimmer Dimmer Up Down Flame Speed Control Flame Speed Flame Speed Up Down Sleep Timer Sleep Timer Sleep Timer Up Down Purifi re Purifi re High Speed Speed Batteries Purifi...
  • Page 10 FLAME SPEED 1. Press the “Flame/Heat On/Off” button to turn the Flame/Heat ON. 2. Press the “Flame Speed Up” to increase the speed of the fl ame. 3. Press the “Flame Speed Down” to decrease the speed of the fl ame. LIGHT DIMMER 1.

  • Page 11: Maintenance

    MAINTENANCE WARNING Disconnect power before attempting any maintenance or cleaning to reduce the risk of fi re, electric shock or damage to persons. LIGHT BULB REPLACEMENT Allow at least 5 minutes for light bulbs to cool before touching bulbs to avoid accidental burning of skin. Light bulbs need to be replaced when you notice a dark section of the fl...
  • Page 12 UPPER LIGHT BULB REQUIREMENTS Quantity of 2 clear chandelier or candelabra bulbs with an E-14 (small) socket base, 25 watt rating. DO NOT EXCEED 25 WATTS PER BULB TO ACCESS THE UPPER LIGHT BULB AREA: 1. Open the bi-fold doors. 2.
  • Page 13 GLASS CLEANING The glass is cleaned in the factory during the assembly operation. During shipment, installation, handling, etc., the glass may collect dust particles, these can be removed by dusting lightly with a clean dry cloth. To remove fi ngerprints or other marks, the glass can be cleaned with a damp cloth. To prevent scratching, do not use abrasive cleaners or spray liquids on the glass surface.

  • Page 14: Warranty

    WARRANTY Dimplex Electric Fireplaces are tested and inspected prior to shipment and are guaranteed from defect to the purchaser of each new product. Any part which proves to be defective in material or workmanship under normal use within one year will be repaired or replaced without charge.* The Company will not be responsible for any expense incurred for installation, removal for service, or transportation costs.
