HIKVISION DS-2CD4312F-I Quick Operation Manual

HIKVISION DS-2CD4312F-I Quick Operation Manual

Network dome camera
Hide thumbs Also See for DS-2CD4312F-I:

Advertisement

Quick Links

Download this manual
Camera
Network Dome Camera
Quick Operation Guide
UD.6L0201B1228A01
1

Advertisement

loading

Related Manuals for HIKVISION DS-2CD4312F-I

Summary of Contents for HIKVISION DS-2CD4312F-I

  • Page 1 Camera Network Dome Camera Quick Operation Guide UD.6L0201B1228A01...
  • Page 2 Network Dome Camera·Quick Operation Guide Thank you for purchasing our product. If there are any questions, or requests, please do not hesitate to contact the dealer. About This Document This manual applies to the following camera models. Model Model DS-2CD4312F-(I)(Z)(H)(S) DS-2CD4312FWD-(I)(Z)(H)(S) DS-2CD4324F-(I)(Z)(H)(S) DS-2CD4332FWD-(I)(Z)(H)(S)
  • Page 3 Network Dome Camera·Quick Operation Guide Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 4 Network Dome Camera·Quick Operation Guide 2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points.
  • Page 5 Network Dome Camera· Quick Operation Guide Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions” Warnings: Serious injury or death may occur if any of the warnings are neglected.
  • Page 6 Network Dome Camera· Quick Operation Guide ● Do not connect several devices to one power adapter as adapter overload may cause over-heating or a fire hazard. ● Please make sure that the plug is firmly connected to the power socket. When the product is mounted on wall or ceiling, the device shall be firmly fixed.
  • Page 7 Network Dome Camera· Quick Operation Guide ● Do not place the camera in extremely hot, cold (the operating temperature shall be-30℃~+60℃,or -40°C ~ 60°C if the camera model has an “H” in its suffix), dusty or damp locations, and do not expose it to high electromagnetic radiation.

  • Page 8: Table Of Contents

    Network Dome Camera· Quick Operation Guide Table of Contents 1 Appearance Description ..............8 1.1 Overview of Type I Dome Camera ........8 1.2 Overview of Type II Dome Camera ........9 2 Installation ..................11 2.1 Installation of Type I Dome Camera....... 12 2.2 Installation of Type II Dome Camera......

  • Page 9: Appearance Description

    Network Dome Camera· Quick Operation Guide Appearance Description Overview of Type I Dome Camera Figure 1-1 Overview (1) of Type I Dome Camera Figure 1-2 Overview (2) of Type II Dome Camera...

  • Page 10: Overview Of Type Ii Dome Camera

    Network Dome Camera· Quick Operation Guide Table 1-1 Description of Overview (1~2) Description Description Black Liner Reset Bubble Power Cable Mounting Base 10/100M Self-adaptive Ethernet Interface SD Card Slot Lens Video Out Interface Audio/ Alarm Cables Overview of Type II Dome Camera Figure 1-3 Overview of Type II Dome Camera...
  • Page 11 Network Dome Camera· Quick Operation Guide Table 1-2 Description of Type II Dome Camera Description Description Bubble 10/100M Self-adaptive Ethernet Interface SD Card Slot Lens Video Out Interface Audio/Alarm Cables Reset Mounting Base Power Cable ● The most distinguish difference between type I and type II dome camera is type II dome camera has an internal PT (Pan and Tilt) control unit, and you can adjust the pan and tilt angle of the camera from the client software or via web browser.

  • Page 12: Installation

    Network Dome Camera· Quick Operation Guide Installation Before you start: ● Make sure the device in the package is in good condition and all the assembly parts are included. ● Make sure all the related equipment is power-off during the installation.

  • Page 13: Installation Of Type I Dome Camera

    Network Dome Camera· Quick Operation Guide ● Make sure that there is no reflective surface too close to the camera lens. The IR light from the camera may reflect back into the lens causing reflection. ● The foam ring around the lens must be seated flush against the inner surface of the bubble to isolate the lens from the IR LEDS.
  • Page 14 Network Dome Camera· Quick Operation Guide Figure 2-2 Install the Mounting Base 3. Connect the corresponding power cable, network cable, audio and alarm cables. 4. Install the dome drive to the mounting base. Dome Drive Figure 2-3 Install the Dome Drive 5.
  • Page 15 Network Dome Camera· Quick Operation Guide Loosen the lock screw besides the lens. Hold the plastic plate and rotate the camera to adjust the panning angle [0~350°]. Push the lens forward and backward to adjust the tilting angle [0~80°] Rotate the lens to adjust the azimuth angle of the camera [0~350°] Tighten the lock screw.
  • Page 16 Network Dome Camera· Quick Operation Guide Adjust the No.1 Focus Lever (F~N) to obtain a perfect image on the monitor. Set the iris type as MANUAL if the environment has a good and stable illumination, and set the iris type as AUTO if the environment has a strong and changeable illumination.

  • Page 17: Installation Of Type Ii Dome Camera

    Network Dome Camera· Quick Operation Guide Figure 2-6 Install the Black Liner and Bubble Figure 2-7 Complete the Installation Installation of Type II Dome Camera Steps: 1. Drill the screw holes and the cable hole according to the supplied drill template.
  • Page 18 Network Dome Camera· Quick Operation Guide Drill Tempalte Hole A: for cables routed Screw Hole 3: for through the ceiling Mounting Base Code: 190600839 Figure 2-8 Drill Template 2. Install the mounting base to the ceiling with the supplied screws. Figure 2-9 Install the Mounting Base 3.
  • Page 19 Network Dome Camera· Quick Operation Guide 4. Install the dome drive to the mounting base. Figure 2-10 Install the Dome Drive The surveillance angle of the camera is well- adjusted by default. If the pan and tilt angle is required to adjusted according to the different installation environment, you can view the camera after the installation is completed.
  • Page 20 Network Dome Camera· Quick Operation Guide Figure 2-12 Install the Bubble...

  • Page 21: Setting The Network Camera Over The Lan

    Network Dome Camera· Quick Operation Guide Setting the Network Camera over the Purpose: To view and configure the camera via LAN (Local Area Network), you need to connect the network camera in the same subnet with your PC. Then, install the SADP or PCNVR software to search and change the IP of network camera.
  • Page 22 Network Dome Camera· Quick Operation Guide  Use PCNVR software and to list the online devices. Please refer to the user manual of PCNVR client software for detailed information. 2. Change the IP address and subnet mask to the same subnet as of your PC.
  • Page 23 Network Dome Camera· Quick Operation Guide Figure 3-2 Search Online Devices Device can be searched and displayed in the list in 15 seconds after it goes online; it will be removed from the list in 45 seconds after it goes offline. Search online devices manually: You can also click to refresh the online device...
  • Page 24 Network Dome Camera· Quick Operation Guide You can click on each column heading to order the information; you can click to show the device table and hide the network parameter panel on the right side, or click to show the network parameter panel. ...
  • Page 25 Network Dome Camera· Quick Operation Guide Figure 3-4 Modify Network Parameters 3. Enter the IP address of network camera in the address field of the web browser to view the live video.  The default value of the IP address is “192.0.0.64”. The default user name is “admin”, and password is “12345”.

  • Page 26: Accessing Via Web Browser

    Network Dome Camera· Quick Operation Guide Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version / Vista / Win7 / Server 2003 / Server 2008 32bits CPU: Intel Pentium IV 3.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 6.0 and above version, Apple Safari...
  • Page 27 Network Dome Camera· Quick Operation Guide Figure 4-1 Login Interface 5. Install the plug-in before viewing the live video and managing the camera. Please follow the installation prompts to install the plug-in. You may have to close the web browser to finish the installation of the plug-in.
  • Page 28 Network Dome Camera· Quick Operation Guide Figure 4-2 Download Plug-in...
  • Page 29 Network Dome Camera· Quick Operation Guide Figure 4-3 Install Plug-in Figure 4-4 Install Plug-in...
  • Page 30 Network Dome Camera· Quick Operation Guide 6. Reopen the web browser after the installation of the plug-in and repeat the above steps 2-4 to login. For detailed instructions of further configuration, please refer to the user manual of network camera.
  • Page 31 Network Dome Camera· Quick Operation Guide...
