ANPR Network Bullet Camera
Quick Start Guide
UD04143B
0

Advertisement

Table of Contents
loading

Related Manuals for HIKVISION DS-2CD4A26FWD-IZSP

Summary of Contents for HIKVISION DS-2CD4A26FWD-IZSP

  • Page 1 ANPR Network Bullet Camera Quick Start Guide UD04143B...
  • Page 2 Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”). This user manual (hereinafter referred to be “the Manual”) cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision.
  • Page 3 LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS.
  • Page 4 Network Bullet Camera·Quick Start Guide IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER PREVAILS. Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
  • Page 5 Network Bullet Camera·Quick Start Guide This product and - if applicable - the supplied accessories too are marked with "CE" and comply therefore with the applicable harmonized European standards listed under the EMC Directive 2014/30/EU, the RoHS Directive 2011/65/EU. 2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union.
  • Page 6 Network Bullet Camera·Quick Start Guide Warning This is a class A product. In a domestic environment this product may cause radio inter-ference in which case the user may be required to take adequate measures. Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss.
  • Page 7 Network Bullet Camera·Quick Start Guide ● In the use of the product, you must be in strict compliance with the electrical safety regulations of the nation and region. Please refer to technical specifications for detailed information. ● Input voltage should meet both the SELV (Safety Extra Low Voltage) and the Limited Power Source with 12 VDC according to the IEC60950-1 standard.
  • Page 8 Network Bullet Camera·Quick Start Guide malfunction), and affect the endurance of sensor at the same time. ● The sensor may be burned out by a laser beam, so when any laser equipment is in using, make sure that the surface of sensor will not be exposed to the laser beam.
  • Page 9 Network Bullet Camera·Quick Start Guide responsibility for problems caused by unauthorized repair or maintenance.)

  • Page 10: Table Of Contents

    Network Bullet Camera·Quick Start Guide Table of Contents 1 Appearance Description ............... 10 Type I ................10 Type II ................11 2 Installation ..................14 Memory Card Installation ..........14 Direct Mounting ............15 Mounting with a Junction Box ........18 Mounting with a Gang Box ..........

  • Page 11: Appearance Description

    Network Bullet Camera·Quick Start Guide 1 Appearance Description This camera series has two appearance types. Type I The overview of the Type I bullet camera is shown below. Figure 1-1 Overview of Type I Camera Table 1-1 Description of Type I Camera Description Photoresistor Lens...
  • Page 12 Network Bullet Camera·Quick Start Guide Description 3-axis Bracket RJ45 Network Interface Power Cord (12 VDC) Alarm Input and Output Interface Audio Output Interface Audio Input Interface Reset Button Memory Card Slot Serial Port Note: The items marked with the "*" are only supported by certain ...
  • Page 13 Network Bullet Camera·Quick Start Guide Figure 1-2 Overview of Type II Camera Table 1-2 Description of Type II Camera Description Photoresistor Lens Sun Shield 3-axis Bracket RJ45 Network Interface Power Cord (12 VDC) Alarm Input and Output Interface...
  • Page 14 Network Bullet Camera·Quick Start Guide Description Audio Output Interface Audio Input Interface Reset Button Memory Card Slot Serial Port Note: The items marked with the "*" are only supported by certain  camera models. Press RESET about 10s when the camera is powering on or ...

  • Page 15: Installation

    Network Bullet Camera·Quick Start Guide 2 Installation Before you start: ● Make sure the device in the package is in good condition and all the assembly parts are included. ● The standard power supply is 12 VDC, please make sure your power supply matches with your camera.

  • Page 16: Direct Mounting

    Network Bullet Camera·Quick Start Guide Slot Cover Figure 2-1 Remove Card Cover 2. Insert the memory card into the memory card slot. Memory Card Figure 2-2 Insert the Card 3. (Optional) To unmount the memory card, push to get it ejected. 4.
  • Page 17 Network Bullet Camera·Quick Start Guide Steps: 1. Drill 4 screw holes (hole 1 on drill template) and the cable hole in the ceiling/wall. Figure 2-3 Drill Template 2. Fix the camera to the wall/ceiling with the supplied screws. Note: Insert the expansion screws first if the camera is mounted to the cement wall/ceiling.
  • Page 18 Network Bullet Camera·Quick Start Guide Ceiling Wall Figure 2-4 Install the Camera 3. Adjust the surveillance angle. 1). Loosen No.1 lock screw to adjust the tilt angle [0 ° to 100°]. 2). Loosen No.2 lock screw to adjust the pan angle [0° to 360°]. 3).

  • Page 19: Mounting With A Junction Box

    Network Bullet Camera·Quick Start Guide Figure 2-6 Supplied Wrench 4. (Optional) Install the water-proof jacket for network interface. Refer to Section 2.5 Network Cable Water-proof Jacket Installation (Optional). Note: It is recommended to adopt the water-proof jacket (supplied) for the network interface, especially when the camera is installed outdoor.
  • Page 20 Network Bullet Camera·Quick Start Guide Figure 2-7 Dimension of Junction Box Steps: 1. Paste the drill template to desired mounting place. Drill the screw hole and cable hole according to the supplied drill template (shown as Figure 2-3). 2. Align the screw holes of the junction box to the drill template, and fix the junction box to the wall with screws.

  • Page 21: Mounting With A Gang Box

    Network Bullet Camera·Quick Start Guide Junction Box Drill Template Safety Rope Figure 2-8 Installation with a Junction Box Mounting with a Gang Box Before You Start: An adapter plate should be purchased separately if you mount the camera to a gang box. Steps: 1.

  • Page 22: Network Cable Water-Proof Jacket Installation (Optional)21

    Network Bullet Camera·Quick Start Guide Adapter Plate Figure 2-9 Installation with a Gang Box Network Cable Water-proof Jacket Installation (Optional) Purpose: If the camera is installed outdoor, you can adapt the water-proof accessory for the network cable after the camera is secured on the installation surface.
  • Page 23 Network Bullet Camera·Quick Start Guide Table 2-1 Components Components Camera’s Network Interface Socket O-Type Gasket Network Plug Waterproof Endcap Waterproof Rubber Gasket Lock Nut Network Cable from Router/Switch Steps: Feed the plugless network cable ⑦ through the lock nut ⑥, waterproof rubber gasket ⑤...
  • Page 24 Network Bullet Camera·Quick Start Guide Insert the water-proof rubber gasket ⑤ into the waterproof endcap ④, and secure lock nut ⑥ with the water-proof endcap ④. Align the snap on the water-proof endcap ④ with the notch on the camera’s network interface socket ①, and then secure the water-proof endcap ④...

  • Page 25: Setting The Network Camera Over The Lan

    Network Bullet Camera·Quick Start Guide 3 Setting the Network Camera over the Note: You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection.

  • Page 26: Activating The Camera

    Network Bullet Camera·Quick Start Guide Activating the Camera You are required to activate the camera first by setting a strong password for it before you can use the camera. Activation via Web Browser, Activation via SADP, and Activation via Client Software are all supported. We will take activation via SADP software and Activation via Web Browser as examples to introduce the camera activation.
  • Page 27 Network Bullet Camera·Quick Start Guide Figure 3-3 Activation Interface(Web) 3. Create a password and input the password into the password field. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.

  • Page 28: Activation Via Sadp Software

    Network Bullet Camera·Quick Start Guide 3.2.2 Activation via SADP Software SADP software is used for detecting the online device, activating the camera, and resetting the password. Get the SADP software from the supplied disk or the official website, and install the SADP according to the prompts. Follow the steps to activate the camera, please refer to the User Manual of Network Camera for other two activation methods.

  • Page 29: Modifying The Ip Address

    Network Bullet Camera·Quick Start Guide Note: The SADP software supports activating the camera in batch. Please refer to the user manual of SADP software for details. 3. Create a password and input the password in the password field, and confirm the password. STRONG PASSWORD RECOMMENDED–...
  • Page 30 Network Bullet Camera·Quick Start Guide Steps: 1. Run the SADP software. 2. Select an active device. Note: Please refer to Chapter 3.2 to activate the camera if the camera is inactive. 3. Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the checkbox of Enable DHCP.

  • Page 31: Accessing Via Web Browser

    Network Bullet Camera·Quick Start Guide 4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version CPU: 2.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 8.0 and above version, Apple Safari 5.0.2 and above version, Mozilla Firefox 5.0 and above version and Google Chrome 18 and above version Steps:...
  • Page 32 Network Bullet Camera·Quick Start Guide 4. Click Login. Figure 4-1 Login Interface 5. Install the plug-in before viewing the live video and managing the camera. Please follow the installation prompts to install the plug-in. Note: You may have to close the web browser to finish the plug-in installation.
