Nitto Kohki MYTON MLG-70 Instruction Manual

Pneumatic angle grinder

Advertisement

Quick Links

PNEUMATIC ANGLE GRINDER
Please read this manual carefully before you attempt to use
your tool so that you may use it properly and safely.
MYTON
PROFESSIONAL TOOL
Rated Air Pressure
Air Consumption
Rated Speed(No Load)
Depressed Center
Grinding Wheel
Mass(Weight)
Sound Pressure Level
Sound Power Level
Vibration Level
Thread size of Air Inlet
Due to continuous product development/improvement the specifications and
configurations in this document are subject to change without prior notice.
Keep the manual handy – so you can use it whenever necessary.
Model MLG-70
Specifications
Model
MPa
3
(No Load)
m
/min
3
(Full Load)
m
/min
-1
min
(r/min)
Diameter
mm(inch)
Hole
mm(inch)
dB(A)
dB(A)
Body
m/s
Handle
m/s
Manufactured by :
NITTO KOHKI Co., Ltd.
2-9-4, Nakaikegami, Ohta-ku,
Tokyo, 146-8555, Japan
Tel : 81-(3)-3755-1111
Fax : 81-(3)-3753-8791
MLG-70
0.6
0.7
1.3
7,600
180(7)
22(7/8)
kg
2.5
89
100
2
2.5
2
4.7
Rc3/8
Original Instructions
