INSTRUCTION
MANUAL
[Specifications]
Maximum operating pressure
Air consumption (No load)
Rated speed (No load)
Depressed Center Grinding Wheel outer diameter
Depressed Center Grinding Wheel hole diameter
Mass (weight)
Sound pressure level *1
Sound power level *1
Vibration level *2
Thread size of Air Inlet
Based on the ISO15744 measurement standard.
*1
*2 Based on the 3 axes combined value measurement standard of the
ISO28927-1 of the hand-held tool frequency correction vibration
acceleration effective value.
Please read manual carefully before you attempt to use your tool so that you may use it
properly and safely.
Keep the manual handy - so you can use it whenever necessary.
document are subject to change without prior notice.
Manufactured by.
NITTO KOHKI CO., LTD.
Professional tool
Model: MYG-50
The end tool in the drawing is not included with the tool.
Model
Tel : +81-3-3755-1111 Fax : +81-3-3753-8791
Pneumatic Grinder
MYG-50
MPa
0.6
m
3
/min
0.70
min
-1
11000
mm (inch)
125 (5")
mm (inch)
22.2 (7/8")
kg
2.5
dB (A)
92
dB (A)
103
4.5 (Main unit)
m/s
2
4.2 (Side Handle)
Rc 3/8
(Original Instructions)
TQ15279-0 12/2017
