Installation Instructions and Instructions for Use
These instructions must be read
prior to installation
Over-glass and under-glass awning SOLEYA/SOLEYA protect
Operating guidelines
Installation Instructions and Instructions for Use
Preliminary remarks HELLA
Over-glass and under-glass awning
SOLEYA/SOLEYA protect
With this HELLA product you have opted for a high-quality product with a most up-to-date
technology that can nevertheless be easily installed and operated. In these instructions we
describe the basic installation, commissioning and use.
For authorized specialist staff
For the consumer (user)
The following symbols will assist you with the installation or use and require a safety-
conscious conduct:
Attention!
This symbol indicates instructions that, if disregarded, can put the
user in danger.
Attention!
This symbol indicates instructions that, if disregarded, can potentially
result in damage to the product.
This symbol indicates instructions for use or helpful information.
This symbol requires you to act.
Attention!
This symbol indicates a risk of injury or danger to life due to an
electric shock.
This symbol indicates parts of the product, for which you will find
important information in these installation instructions.
Subject to technical modifications. - Date of Issue March/2021
and use!
Installation Instructions and Instructions for Use

Table of Contents

Preliminary remarks HELLA Over-glass and under-glass awning SOLEYA/SOLEYA protect
............................................................................................................................................. 1
General notes ....................................................................................................................... 2
CE Identification SOLEYA .................................................................................................... 3
CE Identification SOLEYA protect ........................................................................................ 4
Safety instructions ................................................................................................................ 5
Designated use .................................................................................................................... 9
Servicing, maintenance and repair ..................................................................................... 10
Operating guidelines........................................................................................................... 13
Before installation ............................................................................................................... 14
Overview: Tools for the installation ..................................................................................... 15
Overview SOLEYA/SOLEYA protect - under-glass ............................................................ 16
Under-glass mounting brackets overview ........................................................................... 17
Mounting SOLEYA/SOLEYA protect - under-glass ............................................................ 21
Adjusting the Underglass Awning ....................................................................................... 45
Overview SOLEYA/SOLEYA protect - over-glass .............................................................. 47
Over-glass mounting brackets overview ............................................................................. 48
Mounting SOLEYA/SOLEYA protect - over-glass .............................................................. 50
Aligning the over-glass awning ........................................................................................... 73
Installation/wiring LED ........................................................................................................ 75
Malfunctions ....................................................................................................................... 78
Wiring diagram for motors with ONYX.CONNECTOR ........................................................ 81
Wiring diagram for motors with ONYX.NODE .................................................................... 82
Wiring diagram for motors with Somfy io ............................................................................ 83
Wiring diagram for motors with switch operation ................................................................ 84
Wiring diagram for LED lighting ONYX/Somfy io ................................................................ 85
Operating instructions and configuration with ONYX .......................................................... 86
Activation guidelines for electric drives ............................................................................... 88
Commissioning/functional check ........................................................................................ 89
Removal ............................................................................................................................. 90
Handing over report (for the fitter) ...................................................................................... 91
Handing over report (for the user) ...................................................................................... 92
Installation Instructions and Instructions for Use
General notes
Questions
In case of questions concerning the installation or the use of your product, please
consult your authorized specialist shop.
Spare parts/repairs
Spare parts are available at your HELLA specialist shop. Only spare parts that are
approved by HELLA are allowed to be used.
Warranty/guarantee
Precondition for warranty and guarantee is a correct and regular maintenance of the sun
protection device (at least once a year).
Warranty claims are subject to statutory limitation periods. Service parts are excluded
from the warranty; the same applies for changes in colour and changes in
characteristics caused by UV radiation.
Liability
In case of non-observance of the directions and information given in these instructions
and in case of improper operation or unintended use, the manufacturer shall not accept
any warranty claims concerning any damage to the product. In these cases the liability
for consequential damage to any parts or persons is ruled out as well.
Legal notes
The graphs and texts of these instructions were carefully prepared. We cannot be held
liable for any errors and their potential consequences! Subject to technical modifications
to the product and to these instructions! These instructions include copyrighted
information. All rights reserved! The listed product or brand names are trademarks of the
respective owners.
1
2
Subject to technical modifications. - Date of Issue March/2021
