Challenger SE801 Installation And Operating Instructions Manual

FCC ID: FU5SE801
SE801 Solar-powered Wirefree Siren & Strobe
This featured product can work with a series of
Everspring control panel, such as SC801, SC811 or
SC821, operating at 868MHz or 923MHz.
The Siren is housed within a tough polycarbonate
housing. This housing provides full protection
against adverse weather conditions.
A LED/Strobe unit is built into the siren to act as a
visible deterrent/indication that the system is active.
The Strobe LEDs will slowly and alternately flash
whether the system is armed or disarmed. However,
during an alarm condition the Strobe LEDs will flash
rapidly.
The Siren is powered
rechargeable sealed lead acid battery.
Panel mounted on the top of the housing charges the
battery during daylight hours. During darkness, only
a small amount of energy is required to operate the
Siren unit. A 9V PP3 Alkaline battery is supplied in
the Siren to boost the initial power to the unit when
the system is first activated until the Solar Panel
charges the main battery.
An integral anti-tamper switch provides additional
security protection to the Siren and will immediately
generate a full alarm should any unauthorized
attempt be made to interfere with and remove the
siren cover.
POSITIONING THE SIREN &
STROBE
The Siren should be located as high as possible in a
prominent position so that it can be easily seen and
heard. The Siren should be mounted on a sound
flat surface so that the rear tamper switch is not
activated when mounted. Ensure that the tamper
switch does not fall into the recess between brick
courses as this could prevent the switch from closing
and give a permanent tamper signal.
To provide the optimum amount of daylight to the
Solar Panel, you should ideally mount the Siren on a
south facing wall. However, an easterly or westerly
position will suffice.
Installation and Operating Instructions
by a high capacity
A Solar
Although the Siren is designed to work on any aspect
wall, for optimum performance you should refrain
from sitting the unit on a north facing wall, where
possible.
WEST
Shadows cast by neighbouring walls, trees and roof
overhangs should also be avoided. If the Siren is to
be mounted below the eaves, it should be positioned
a distance of at least twice the width of the eaves
overhang below the eaves.
winter the sun is lower in the sky and you should
avoid winter shadows where possible.
The Siren & Strobe contains sophisticated radio
receiver. However, reception of radio signals can be
affected by the presence of metallic objects within the
vicinity of the Siren.
mount the Siren a minimum distance of 1m away
from any external or internal metalwork, (i.e.
drainpipes, gutters, radiators, mirrors etc).
1
NORTH
Avoid if
Possible
SOUTH
Remembers that in
It is therefore important to
EAST
