APFWKGSM GSM Wireless Alarm Operating Manual
APFWKGSM – GSM WIRELESS ALARM
OPERATING Manual
SAFETY
Before proceeding with the installation, please note the following safety warnings:
DO NOT connect the mains supply directly to the products, this will cause permanent damage to
the products.
Control panel is for indoor use only. Avoid mounting location which can expose this product to splashing or
dripping liquid.
Always follow the manufacturer's advice when using any tools power tools, ladder/steps,. using steps or
ladders, and wear suitable protective equipment (e.g. safety goggles) when drilling holes, etc. The use of ear
protectors are advisable when working in close proximity to the Control Panel's Siren when the front panel
cover is removed due to the high sound level produced. Before drilling holes in walls, check for hidden
electricity cables and water pipes. The use of a cable/pipe locator is advisable if in doubt. Batteries (battery
pack or batteries installed) should not be exposed to excessive heat. Danger of damage to the unit may occur
if battery is incorrectly replaced. Replace only with the same or equivalent type. (Do not mix batteries type).
IMPORTANT – Please read this manual carefully, in full, before commencing
Installation. You will find installation easier if you follow these steps in the
sequence shown.
POWER
APFWKGSM Manual Rev01
- 1 -
