OPERATOR INSTRUCTION
HOLMS 300 / 300L
Pick-up sweeper
Serial No:
300 - 2,0 - 2000
300 - 2,0 - 4000
300 - 2,2 - 2000
300 - 2,2 - 4000
300 - 2,5 - 2000
300 - 2,5 - 4000
300L - 2,5 - 2000
300L - 2,5 - 4000
300L - 3,0 - 2000
300L - 3,0 - 4000
From serial No: 5020
Box 924 S-591 29 Motala Tel +46 141 - 22 41 00 Fax +46 141 - 22 41 90
© HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 4/4/06

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 300L and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HOLMS 300L

Summary of Contents for HOLMS 300L

  • Page 1 300L - 3,0 - 2000 300L - 3,0 - 4000 From serial No: 5020 Box 924 S-591 29 Motala Tel +46 141 - 22 41 00 Fax +46 141 - 22 41 90 © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 4/4/06...

  • Page 2: Table Of Contents

    Dismounting of sweeper roll (hydraulic flow, stability etc.) Change of brushes When ordering spare parts or by other contacts with Holms Mounting of sweeper roll or your local dealer, always inform about the attachment type and series No. This number you will find on the ma- chine plate.

  • Page 3: Product Facts

    340mm* 340mm* (empty) Max oilflow (l/min) 130/200 130/200 130/200 130/200 130/200 2000/4000 motors Max returnpressure (Bar) 140/105 140/105 140/105 140/105 140/105 2000/4000 motors *) With VME 4000 bracket. 1. Centre of gravity © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 4/4/06...

  • Page 4: Generally

    HOLMS INDUSTRI AB MOTALA SWEDEN Generally Holms 300 is a pick up sweeper adapted to front mounting on wheel loaders or tractors. The sweeper operates with two direct acting hydraulic motors which can be delivered in two sizes, 2000 motors (195 cm³) made for an oil flow of 40-130 l/min, or 4000...

  • Page 5: Operator Instruction

    - Lower the machine towards the ground until the waste- container is 10-15 cm above the ground. Loosen the height 5. Tilt indicator indicator adjusting screw, picture 4, and move the indicator until the yellow markers are in line. © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 4/4/06...

  • Page 6: Setting Of Ground Pressure

    This is important, otherwise the sweeper can be damaged by the loader arms. 3. Loosen the hydraulic quick couplings and the electric cable harness. © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 4/4/06...

  • Page 7: Dust Control

    7. Water filter Side brush (extra equipment) Holms 300 / 300L can be equipped with an extra side brush to obtain even better result close to kerbstones etc. It can be mounted on the left or the right side. When the side brush is not used, lift it up and lock it with the pin, see picture 9.

  • Page 8: Maintenance

    5. Lift up the machine and take away the sweeper roll. Do not make any modifications, changes, rebuilt work etc. which are not approved by Holms Industri AB. We also ask you to pay attention to spare parts not approved by us.

  • Page 9: Change Of Brushes

    2,5 m - 17 pcs 3,0 m - 17 pcs 3,0 m - 32 pcs 3,0 m - 17 pcs Finish with a Finish with a brush element brush element ATTENTION! No distance ring © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 4/4/06...

  • Page 10: Mounting Of Sweeper Roll

    4. Mount the four gable side bolts. Make sure not to clamp any brush straws. 5. Mount the hydraulic hose bracket on the bar tube. 18. Gable side bolts 19. Bracket for hydraulic hoses © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 4/4/06...

This manual is also suitable for:

300
