HOLMS SL Operator Instructions Manual

Hydraulic sweeper 2,0/2,2/2,5m
Hide thumbs Also See for SL:
Table of Contents

Advertisement

Quick Links

Download this manual
Operator instruction
SL
Hydraulic sweeper
2,0/2,2/2,5m
From serial No: 5109.
Box 924 S-591 29 Motala Sweden
+ 46 141-22 41 00
+ 46 141-22 41 90
© HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 060406.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HOLMS SL

Summary of Contents for HOLMS SL

  • Page 1 Operator instruction Hydraulic sweeper 2,0/2,2/2,5m From serial No: 5109. Box 924 S-591 29 Motala Sweden + 46 141-22 41 00 + 46 141-22 41 90 © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 060406.

  • Page 2: Table Of Contents

    Content Foreword ..........3 Product facts........... 4 Generally about the sweeper....5 Extra equipment ........5 Operator instruction ......6-7 Connecting to carrier....6 Sweeper setting height and tilt....6 Setting of ground pressure....6-7 Sweeping....7 Disconnecting from carrier....7 Maintenance ...........

  • Page 3: Foreword

    This number you will find on the ga- ble of the motor. Do not make any modifications, changes, rebuilt work etc. which are not approved by Holms Industri AB. We also ask you to pay attention to spare part not approved by us.

  • Page 4: Product Facts

    Model SL 2,0 SL 2,2 SL 2,5 Working width (m) Max width (m) Max height (m) Working width at 30° angling (m) Weight with std. brushes (kg) Added weight with compl. sprinkling system, empty tank (kg) Centre of gravity, A in sketch (mm)

  • Page 5: Generally About The Sweeper

    Generally about the sweeper The SL sweeper is made for small wheel loaders and tractors mounted in the front or rear of the machine. SL operates with two direct acting hydraulic motors designed for an oil flow of 40-130 l/min.

  • Page 6: Operator Instruction

    Operating instruction Connecting to carrier 1. Connect the sweeper to the loader attachment bracket. See loader instruction manual. 2. Connect the driving hose quick couplings to the 3:rd hydraulic function outlet or to the loader hydraulic motor out- let. 3. Connect the angling cylinder quick coupling to the 4:th hy- draulic function outlet.

  • Page 7: Sweeping

    1. Set the sweeper height and tilt. 2. Let the sweeper rotate a short while against the ground. 3. Measure the clean-swept stripe, it shall normally be ca 10 Warning! Always lower the attachment so the springs are relieved before making any adjustments. 8.

  • Page 8: Maintenance

    Maintenance After running • Wash the sweeper, which increases the life-time and makes it easier to detect eventual leakage or other defects. • Inspect the sweeper concerning damages on hoses, brush protectors, leaf spring or framework. Also check eventual oil leakage. Lubrication 12.

  • Page 9: Change Of Brushes

    Change of brushes 1. Loosen the screws and take away the sweeper roll end ring. 2. Put shackels in the two holes for the brush core mounting- screws and put a lifting wire loop through the shackles. 3. Lift the sweeper roll in vertical position by using a traverse crane or similar equipment.

  • Page 10: Mounting Of Sweeper Roll

    Mounting of sweeper roll 1. Put the sweeper roll on the fixed gable side carrier housing. 2. Put the gable side with the hydraulic motor and carrier housing on the two guide pins. See picture 21. Attention! Avoid clamping. 20. Mounted sweeper roll 3.
