Operating instructions
Holms Dustbuster
Pick-up sweeper
Applicable from machine no.: 20916
Box 924 SE-591 29 Motala Sweden
+46 141 22 41 00
+46 141 22 41 90
Original language: Swedish
© HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 160429.
English

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Dustbuster and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HOLMS Dustbuster

Summary of Contents for HOLMS Dustbuster

  • Page 1 Operating instructions Holms Dustbuster Pick-up sweeper Applicable from machine no.: 20916 Box 924 SE-591 29 Motala Sweden +46 141 22 41 00 +46 141 22 41 90 Original language: Swedish © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 160429. English...

  • Page 3: Table Of Contents

    Emptying the refuse collector......13 Disconnection from carrier ........13 Sprinkler............13 Side brush (accessory) ........14 Maintenance...............15 After operation ..........15 Replacing the brush .......... 15 Other service............. 18 Index................19 © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 160429.

  • Page 4: Warning Labels

    There are several specific warning labels on this product; see the descriptions below. Make sure that you understand the implications of these labels before using the product. Clean/replace warning labels if they are illegible or are missing. Contact you Holms dealer if you require new labels.
  • Page 5 Use the marked loops when transporting the tool (warning label 1530056) When transporting the tool, use the marked loops to secure the tool during transit. © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 160429.
  • Page 6 Use approved lifting devices only. Risk of crushing - mind your hands (warning label 1530060) Mind your hands and keep them away from this area whilst the tool is in use. © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 160429.

  • Page 7: Safety

    The machine is not used or handled incorrectly. That any warning labels on the machine are legible. Unauthorised persons do not use the machine or remain within the machine’s working area during its operation or maintenance. © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 160429.
  • Page 8 MATERIAL DAMAGE RESULTING FROM THE USE OF NON APPROVED SPARE PARTS OR MODIFICATIONS When ordering spare parts, or otherwise contacting Holms or your local dealer, always specify the machine type and its serial number. (Specified on the product’s machine plate.)

  • Page 9: Product Data

    Additional weight with side brush (kg) Max. oil flow (litres/min) Centre of gravity, dimension A (without side brush) (mm) Centre of gravity, dimension B (without side brush) (mm) Additional weight with dust kit 1.Centre of gravity © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 160429.

  • Page 10: Transport And Storage

    Storage When storing, remember to drain the spray system. Make sure that the machine is lubricated; there are five lubrication points. See figure 16 and figure 17 on page 19. © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 160429.

  • Page 11: Product Description

    This minimises brush wear and contact against inclines and uneven surfaces. In the standard version, Holms Dustbuster is fitted with a water tank and an electric water pump. The machine’s attachment hooks are secured with screws, which enables lateral displacement and simplifies switching between different hook types.
  • Page 12 Holms Dustbuster © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 160429.

  • Page 13: Operating Instructions

    4. Readjust the tilt where appropriate as per item 2. 4.Yellow markings on support wheel set Operate carefully in transport position on uneven surfaces, to avoid exposing the sweeper to undue strain. © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 160429.

  • Page 14: Emptying The Refuse Collector

    The easiest thing is to empty the tank first and then run the pump dry for 20-30 seconds. When emptying the tank, the hose on the tank can be disconnected using a quick-coupling. © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 160429.

  • Page 15: Side Brush (Accessory)

    Holms Dustbuster Side brush Holms Dustbuster can be fitted with a side brush for more efficient sweeping up against kerbs, etc. It can be fitted on the right or left side. The brush is automatically extended/retracted when started/stopped. Connection of side brush See “Connection"...

  • Page 16: Maintenance

    Clamp plate for slewing brackets a risk of damaging them. 11.Removing the motor 5. Lift up the machine and remove the roller. © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 160429.
  • Page 17 8. To “cover” the entire core it may be necessary to use double brushes without spacer ring on the end so that the right length will be obtained. 9. Refit the end ring using the two split pins. See figure © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 160429.
  • Page 18 15. This is due to the holes for the pins being rifled to prevent the pins from rotating. 15.Fitting/removing the bearing pins © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 160429.

  • Page 19: Other Service

    Inspect the hydraulic hoses. Damaged hoses can cause leaks. Exercise care when working where hydraulic oil may be present. Contact with the skin may cause an allergic reaction. 17.Lubrication point 18.Refitting of hoses © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 160429.
  • Page 20 Holms Dustbuster © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 160429.

  • Page 21: Index

    9 water filters 13 oil leakage 15 water pump 11 operating width 9 water tank 11 volume 9 side brush 14 weight 9 product data 4 width 9 product description 11 © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 160429.
