- Page 1 Operator instruction Hydraulic sweeper 2,5/3,0/3,5m From serial No: 6261. Box 924 S-591 29 Motala Sweden + 46 141-22 41 00 + 46 141-22 41 90 © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 060406.
-
Page 2: Table Of Contents
Disconnecting from carrier without its own lift ....8 Maintenance ............... 9 After running ..............9 Lubrication................. 9 Change of brushes..........9-10 Dismounting of sweeper............ 9 Change of brushes ............9-10 Mounting of sweeper roll ..........10 © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 060406. -
Page 3: Foreword
• Ensure that the carrier is in the correct condition for operation (hydraulics, stability etc.). When ordering spare parts, or during any other contact with Holms or your local dealer, always give the machine's type and serial number (located on the machine identification plate). -
Page 4: Product Facts
Centre of gravity, A in sketch incl. sprinkling system filled (mm) Centre of gravity, A in sketch incl. sprinkling system filled (mm) Max oil flow (l/min) *) All measures and weights are excl. hooks. 1. Centre of gravity © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 060406. -
Page 5: General Information
Generally about the sweeper The Sweeper SH standard design is adapted to front mounting on wheel loaders. Attachment brackets are also available for other applications such as trucks and agriculture tractors. SH operates with two directacting hydraulic motors designed for an oil flow of 70-200 l/min. -
Page 6: Operator Instruction
8. Check that the sweeper rotates in the correct direction. If it rotates 5. Spacer between gate and bracket wrongly in closed position, shift closed position of the lever or shift the tion. quick couplings for the hydraulic motor func © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 060406. -
Page 7: Sweeper Setting Height And Tilt
The sweeper oper- ates with even pressure over its whole width (dia.10). 9. Adjusting grip Attention! Do not use the loader height and tilting function for ground pressure adjustment. © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 060406. -
Page 8: Disconnecting From Carrier With Standard Bracket
3. Lower the sweeper's gate to the lowest position with the lift cylinder. Warning! Make sure the system has no pressure 13. Supports in parking position before loosening the quick couplings. 4. Loosen the quick couplings and any electrical cabling. © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 060406. -
Page 9: Maintenance
3. Lift the sweeper roll in vertical position by using a traverse 17. Removing the gable side crane or similar equipment. 4. Lift up the roll from the floor and pull down the brush sections and the distance rings. Lower the sweeper roll. © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 060406. -
Page 10: Mounting Of Sweeper Roll
The easiest thing is to empty the tank first and then run the pump dry for 20-30 seconds. When emptying the tank, remove the hose coupling from the tank. © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 060406.
