HOLMS SL Operating Instructions Manual

Hydraulic sweeper roller 2.0 m/2.2 m/2.5 m/2.8 m
Hide thumbs Also See for SL:
Table of Contents

Advertisement

Quick Links

Download this manual
Operating instructions
SL
Hydraulic sweeper roller
2.0 m/2.2 m/2.5 m/2.8 m
Applicable from machine no.: 21252
Box 924 S-591 29 Motala Sweden
+46 141 22 41 00
+46 141 22 41 90
Original language: Swedish
© HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 161223.
English

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HOLMS SL

Summary of Contents for HOLMS SL

  • Page 1 Hydraulic sweeper roller 2.0 m/2.2 m/2.5 m/2.8 m Applicable from machine no.: 21252 Box 924 S-591 29 Motala Sweden +46 141 22 41 00 +46 141 22 41 90 Original language: Swedish © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 161223. English...

  • Page 3: Table Of Contents

    Operating instructions ..........15 Operator settings ..........16 Operation ............18 Sprinkler system (extra equipment) ....19 Service and maintenance...........22 After operation ..........22 Lubrication ............22 Replacing the brush ..........22 Replacing the Swish brush.........27 Tip ..............27 Index................28 © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 161223.

  • Page 4: Warning Labels

    There are several specific warning labels on this product; see the descriptions below. Make sure that you understand the implications of these labels before using the product. Clean/replace warning labels if they are illegible or are missing. Contact you Holms dealer if you require new labels.
  • Page 5 Use the marked loops when transporting the tool (warning label 1530056) When transporting the tool, use the marked loops to secure the tool during transit. © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 161223.
  • Page 6 Use approved lifting devices only. Risk of crushing - mind your hands (warning label 1530060) Mind your hands and keep them away from this area whilst the tool is in use. © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 161223.

  • Page 7: Safety

    The operator is responsible for ensuring that: bolted joints are tightened. the machine is not used or handled incorrectly. all warning labels on the machine are legible. © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 161223.
  • Page 8 MATERIAL DAMAGE RESULTING FROM THE USE OF NON APPROVED SPARE PARTS OR MODIFICATIONS When ordering spare parts, or otherwise contacting Holms or your local dealer, always specify the machine type and its serial number. (Specified on the product’s machine plate.)

  • Page 9: Product Data

    Centre of gravity, dimension B with sprinkler system 600 l, full (mm) Max. oil flow (litres/min) a. All weights and dimensions are for standard model without attachment. For extra equipment, please contact Holms for further information. 1.Centre of gravity © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 161223.

  • Page 10: Machine Plate

    Serial No. • Year of manufacture • Weight • code of the person who assembled the tool (Assembler) • code of the person who checked the tool on delivery (Checked). 2.Machine plate © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 161223.

  • Page 11: Product Description

    The standard-design sweeper roller has a polythene (plastic) splash guard. Extra equipment 3.Electrohydraulic There is a range of extra equipment available for SL: • Sprinkler system with 400 or 600-litre tank, complete with pump, tank and spraying ramp. Electrohydraulic angling allows turning of the roller while on the move, and the machine only requires a single hydraulic function.
  • Page 12 © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 161223.

  • Page 13: Transport And Storage

    When transporting the tool, use the marked loops to secure the tool during transit. 5.Lifting eye Storage Park on supports to avoid damage to the brush. If your tool has a sprinkler system, remember to empty it before storing. © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 161223.
  • Page 14 © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 161223.

  • Page 15: Operating Instructions

    Remove the supports. 4. Check the tilt angle (the correct tilt angle is when the centre attachment on the sweeper roller is vertical. (Check with a spirit level, if necessary). Adjust the tilt © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 161223.

  • Page 16: Operator Settings

    5. Start the sweeper roller via the third hydraulic function or via the hydraulic motor circuit. When angling a sweeper roller using electrohydraulic angling, the roller must be in contact with the ground. 10.Tilt indicator © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 161223.
  • Page 17 Lower the attachment, to relieve pressure on the springs, before making any adjustments. 4. Reduce the ground pressure by lowering the 12.Supports in parking adjustment lever. 5. Increase the ground pressure by raising the adjustment lever (figure 11). © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 161223.

  • Page 18: Operation

    Disconnection from carrier without own lifting device Before disconnection the roller must be in line with the angling cylinder and any lateral movement. © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 161223.

  • Page 19: Sprinkler System (Extra Equipment)

    3–5 minutes for a short period. If the jets and system freeze up, the best way to defrost them is either with water or by storing the equipment somewhere warmer than 0 degrees Celsius. © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 161223.
  • Page 20 (read more about this on the Service and maintenance tab). Remember to rinse off the sweeper roller with fresh water at the end of shifts to reduce the amount of corrosion. © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 161223.
  • Page 21 © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 161223.

  • Page 22: Service And Maintenance

    (figure 20). 19.Removal of fixing screws Risk of crushing. 4. Unfold the roller brush from the bar tube and slide the roller off the carrier housing at the other end. 20.Removal of end © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 161223.
  • Page 23 12. Fit the second clamping ring. 23.The clamping ring pin in the groove on the brush core. 24.Spacer ring © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 161223.
  • Page 24 3. Fit the four fixing screws on the end. See figure 27. pins 4. Fit the attachments for the hydraulic hoses on the bar tube. 26.Fitting the end 27.Fixing screws for end © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 161223.
  • Page 25 5. Check that all of the jets are pointing towards the Nozzle for dust control roller for dust control or downwards for salt spreading. Nozzle for salt spreading Make sure the jet is facing the right way Bottom part of nozzle © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 161223.
  • Page 26 © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 161223.

  • Page 27: Replacing The Swish Brush

    7. Lock the catch, see figure 29. 8. Turn the outer stop to its locked position, see figure 29.Catch 30.Open Lubricating the tracks with soap or the like will simplify brush replacement. 31.Replacing the 32.Locked position © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 161223.

  • Page 28: Index

    4 extra equipment 11 quick coupling drive hoses 15 fitting roller brush 24 quick couplings 19 fixing screws reducing end 22 ground pressure 17 gate 16 removal roller brush 22 © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 161223.
  • Page 29 16 transport 13 types of brush 11 universal electrical cabling 11 vertical position 16 warning labels 7 clean/replace 4 warning symbols 7 weight with sprinkler system 9 width 9 working width 9 © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 161223.
