Cooper Lighting PORTFOLIO 844 Specification Sheet

PORTFOLIO
HOUSING
4"
H7404T
H7482T
HOUSING
H7404T=Ellipsoidal A lamp Incandescent
H7404TCP=Ellipsoidal A lamp Incandescent,
Chicago Plenum
H7482T=Ellipsoidal T4 Quartz Incandescent
H7482TCP=Ellipsoidal T4 Quartz Incandescent,
Chicago Plenum
TRIM
Open Downlight
A19/21/23 150W Max
Open Downlight
Quartz T4 E11 250W
Ordering Example
Housing, Trim, Accessories and Lamps ordered as separate line items.
844
COOPER LIGHTING
™
4" Ellipsoidal
A19/21/23
T4Q E11
Ellipsoidal downlight available with high wattage T4 E11 quartz
for higher light levels in taller ceilings or A lamp for minimal
cone brightness. Narrow to Wide distribution is dependent
upon socket position. Can be lamped from above.
OPTIONS
DR =DeRated Wattage Label,
*
Specify Wattage
TRIM FINISH
1451=Self Flanged LI=Low Iridescent Clear
1450=Molded Trim Ring, H=Haze
White WMH=Warm Haze
G=Gold
WH=Wheat
B=Black
W=Gloss White
GP=Graphite
TRIM FINISH
1451=Self Flanged LI=Low Iridescent Clear
1450=Molded Trim Ring, H=Haze
White WMH=Warm Haze
G=Gold
WH=Wheat
B=Black
W=Gloss White
GP=Graphite
Height varies with socket position; see reflector line drawing below for overall
fixture height. Add 1/2" height for Chicago Plenum option.
GPH=Graphite Haze
K=Cognac
KH=Cognac Haze
BA=Black Baffle
(1450 only)
WB=White Baffle
(1450 only)
GPH=Graphite Haze
K=Cognac
KH=Cognac Haze
BA=Black Baffle
(1450 only)
WB=White Baffle
(1450 only)
Housing Trim
H7404T 1450LI
Dimensions Length Width
Standard Housing 11-3/4" 14-3/8"
Chicago Plenum 11-3/4" 14-3/8"
ACCESSORIES
H277=Step Down Transformer, 300VA Max
HB26=C Channel Bar Hanger, 26" Long, Pair
HB50=C Channel Bar Hanger, 50" Long, Pair
RMB22=Wood Joist Bar Hanger, 22" Long, Pair
HSA4=Slope Adapter for 4" Aperture Housings,
Specify Slope
TRM4= Metal Trim Ring, Specify Finish
TRR4=Rimless Trim Ring, White
*
FK5=Field Installed Fuse Kit, 5 Amp
*Not compatible with Self Flange
OPTIONS
A23 = 11-1/4"
WF=White
A21 = 10-5/8"
Painted Flange
A19 = 9-3/4"
(Self Flanged
only)
OPTIONS
WF=White
Painted Flange
(Self Flanged
only)
Accessories
HB26
Height Cutout
H
5-1/8"
H
*
4-7/16"
5-3/4"
14-5/8"
4-7/16"
5-3/4"
