Cooper Lighting Portfolio 841 Specification Sheet

Dimensions Length Width
Standard Housing 13-1/2" 17"
Chicago Plenum 13-1/2" 17"
HOUSING
H7443T=Directional Par Lamp
H7443TCP=Directional Par Lamp, Chicago Plenum
TRIM
9471=Self Flanged
9473=Metal Trim Ring, White
4-7/16"
5-3/4"
4-7/16"
5-3/4"
4" Low Voltage Directional
Height Cutout
7-1/4"
5-1/8"
7-1/4"
downlighting in sloped ceilings or
Lockable 358° rotation and 35° tilt
with center beam optics provides
full output with no flashback.
OPTIONS
DR
Specify Wattage
FINISH
LI=Low Iridescent Clear
H=Haze
WMH=Warm Haze
G=Gold
WH=Wheat
B=Black
W=Gloss White
GP=Graphite
GPH=Graphite Haze
K=Cognac
KH=Cognac Haze
BB=Black Baffle (9473 only)
WB=White Baffle (9473 only)
Ordering Example
Housing, Trim, Accessories and Lamps ordered as separate line items.
PAR16/20/30
Open directional for vertical
for accent/display lighting.
=DeRated Wattage Label,
*
Housing
H7443T
PORTFOLIO
ACCESSORIES
H277=Step Down Transformer, 300VA Max
HB26=C Channel Bar Hanger, 26" Long, Pair
HB50=C Channel Bar Hanger, 50" Long, Pair
RMB22=Wood Joist Bar Hanger, 22" Long, Pair
FK5=Field Installed Fuse Kit, 5 Amp
L200 Series=Optical Lenses for PAR Lamps,
use with LC30 Lens Clip
LC30=Lens Holder for PAR30 Lamps
and L200 Series Lens
OPTIONS
WF=White
PAR16/PAR20/PAR30 75W Max
Painted Flange
(Self Flanged
only)
Trim Accessories
9471LIWF
COOPER LIGHTING
™
HOUSING
4"
H7443T
TRIM
Angle Cut
HB26
841
