Operator panel

The operator panel has four indicator lights and an operator button.
Operator button
Each time you press the operator button, the carousel rotates to the next bin.
Operator panel
The indicator lights on the operator panel provide the following operational information:
Name
Carousel
Present
Active
Power
Fault
110656_I
Identify the parts of the AutoPrinter
Functionality
The carousel present indicator light illuminates when the
carousel is absent.
The active indicator light illuminates when the computer is
communicating with the AutoPrinter.
The power indicator light illuminates when the AutoPrinter is
powered on.
The fault indicator light, located on the operator button,
illuminates if an error is detected.
