FrSky Neuron 60 Instruction Manual

Instruction Manual for ESC Neuron 40/60/80
Introduction
Thank you for purchasing FrSky ESC Neuron 40/60/80. The ESC has high performance processor. The SBEC
voltage can be adjusted through LUA (FrOS & OpenTX Supported) or through FreeLink App with Airlink S. The
Neuron ESC is encased in a CNC aluminum protective shell which also aids in heat dissipation. In order to fully
enjoy the benefits of the products, please read the instruction manual carefully and set up the device as described below.
Overview
59
40/60/80
Specifications
Model Name Size (L×W×H) Weight
Neuron 40 59*33*17mm 58g
Neuron 60 59*33*17mm 58g
Neuron 80 58g
59*33*17mm
Maximum supported speeds:
D Erpm M
Dshot at 8kHz 470k Multishot at 8kHz
Dshot at 16kHz 420k Multishot at 16kHz
Dshot at 32kHz 310k Multishot at 32kHz
Dshot at 16kHz with sine 280k
Features
• Smart Port enabled
Telemetry data for ESC: Voltage, Current (Resolution
125mA, Precision ±2%), RPM, Power Consumption,
Temperature.
Telemetry data for SBEC: Output Voltage,
Current (Resolution 50mA, Precision ±2%)
Connection Diagram
Motor
Battery
Warning:
Please DO NOT connect BEC to any devices with power supply.
FrSky Electronic Co., Ltd www.frsky-rc.com
Add:F-4,Building C, Zhongxiu Technology Park, No.3 Yuanxi Road, Wuxi, 214125, Jiangsu, China Technical Support: sales4tech@gmail.com
GND
33 BEC 5~8.4V
S.Port
PWM
Right
LiPo cells SBEC Cont. Current Peak Current
3~6S 5~8.4V 40A
3~6S 5~8.4V 60A
3~6S 5~8.4V 80A
Erpm P Erpm Regular pwm input signal
510k Proshot at 8kHz 480k Regular at 8kHz
450k Proshot at 16kHz 430k Regular at 16kHz
420k Proshot at 32kHz 330k Regular at 32kHz
• High performance 32-bit micro-processor
• Over-temperature and over-current protection
• SBEC Supports 7A@5~8.4V (adjusted through
LUA or through FreeLink App with Airlink S)
40/60/80
Receiver
ESC
Contact us : frsky@frsky-rc.com
Programming parameters
FrSky
ESC Neuron 40/60/80
not included in the package.Users could buy BLHeli USB Linker on your own.
The connection diagram is below.
Never connect the 5V output from USB adapter to ESC, or ESC will not work normally.
The configuration method based on the operation manual for BLHeli_32 ARM is only for reference. For more
detailed information, please refer to the original BLHeli manual carefully. Due to firmware update or other
reasons, the descriptions for functions may differ, so please take the official BLHeli manual as standard.
60A
100A
120A
Erpm
510k
450k
420k
Add:F-4,Building C, Zhongxiu Technology Park, No.3 Yuanxi Road, Wuxi, 214125, Jiangsu, China Technical Support: sales4tech@gmail.com
Instruction Manual for ESC Neuron 40/60/80
supports programming parameters through USB Adapter. USB Adapter is
GND
5V
S
Neuron XX
Rampup Power can be set to relative values from 3% to 150%. 3% is the
minimum power to start the engine and 150% is the maximum power to
operate the motor normally.
Temperature protection can be disabled or enabled and temperature
threshold can be programmed. The measured maximum temperature is
different because the hardware are not the same.
