Instruction Manual
The ULT-V2 plug-in style vehicle loop detector senses metallic objects near an induction loop.
This vehicle detector may be used in center, reverse and exit loop positions. The ULTRAMETER™ display
allows for easy set-up by displaying the optimum sensitivity for detecting a vehicle near the loop while
ignoring interference. Ten sensitivity settings allow for fine adjustment of the detection level.
The ULT-V2 features a user configurable Output B for fail safe/secure, pulse on entry/exit or presence.
Four frequency settings provide flexibility in preventing crosstalk in multi-loop applications.
Cautions and Warnings
This product is an accessory or part of a system. Install the ULT-V2 according to
instructions from the gate or door operator manufacturer. Comply with all applicable
codes and safety regulations.
Specifications
Power
Draw Current
Loop Frequency
Loop Inductance Range
Surge Protection
Operating Temperature
Connector
Dimensions (L x W x H)
Ordering Information
ULT-V2
•
PR-XX
•
TSTL
•
EMX Industries, Inc.
ULT-V2_Rev2.1_072220
ULT-V2
™
Plug-In Vehicle Loop Detector
Plug-in vehicle loop detector (included)
Lite preformed loop (XX – specify size)
Test loop, troubleshooting tool
Tech support: 216-518-9889
technical@emxinc.com
12-24 VDC
15 mA
4 settings (low, med-low, med-hi, high)
20-2000 µH (Q factor ≥ 5)
Loop circuitry protected by surge suppressors
-40º to 180ºF (-40º to 82ºC) 0 to 95% relative humidity
10 pin female
3.0" (76 mm) x 0.9" (22 mm) x 2.75" (70 mm)
TM
1/6
