iDataLink maestroRR Install Manual
  1. Manuals
  2. Brands
  3. iDataLink Manuals
  4. Automobile Accessories
  5. Maestro RR
  6. Install manual

iDataLink maestroRR Install Manual

Hide thumbs Also See for maestroRR:

Advertisement

Quick Links

Download this manual
SELECT VEHICLE
PRINT PAGES NEEDED
HOW TO USE THIS INSTALL GUIDE
1
Open the Bookmarks menu and find your vehicle OR scroll
down until you find the install guide for your vehicle.
2
Print only the pages for your vehicle using the advanced
options in the Print menu.
3
Install your Maestro RR according to the guide for your vehicle.
Pressing the printer icon or "quick printing" this document will print
NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certifi ed technician. Logos and trademarks used here in
are the properties of their respective owners.
WARNING
all of the guides in this compilation.

Advertisement

loading
Need help?

Need help?

Do you have a question about the maestroRR and is the answer not in the manual?

Questions and answers

Related Manuals for iDataLink maestroRR

Summary of Contents for iDataLink maestroRR

  • Page 1 SELECT VEHICLE PRINT PAGES NEEDED HOW TO USE THIS INSTALL GUIDE Open the Bookmarks menu and find your vehicle OR scroll down until you find the install guide for your vehicle. Print only the pages for your vehicle using the advanced options in the Print menu.
  • Page 2 5 incH display witHout apple carplay or android auto, witHout aMp RETAINS STEERING WHEEL CONTROLS, BACKUP CAMERA, GAUGES, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRN-RR-HK3 Installation Harness Radar Installation Guides...
  • Page 3 Hyundai accent 5 incH display witHout apple carplay or android auto, witHout aMp 2018-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 4 AUX cable into the AUX In on the aftermarket radio. If the vehicle has no RSE, isolate (tape) the 3.5mm jack and secure it out of the way. Note: On Pioneer radio, ensure that there is nothing plugged into the W/R port. Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 5 SPDIF POWER POWER N.C. SANTA FE SANTA FE SPORT ONLY SPORT ONLY N.C. STEP 3 STEP 4 OBDII CONNECTOR MAESTRO RR2 MODULE HK3 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 6 Illumination Orange Orange/White Orange/White Orange Reverse Light Purple/White Orange/White Purple/White Purple/White Purple/White E-Brake Lt Green Yellow/Blue Lt Green Lt Green Lt Green VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 7 Phone: 1-866-427-2999 Email: maestro.support@idatalink.com Web: maestro.idatalink.com/support add www.12voltdata.com/forum/ IMPORTANT: To ensure proper operation, the aftermarket radio needs to have the latest fi rmware from the manufacturer. Please visit the radio manufacturer’s website and look for any updates pertaining to your radio.
  • Page 8 RETAINS STEERING WHEEL CONTROLS, BACKUP CAMERA, GAUGES, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRN-RR-HK3 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 9 Hyundai accent witH apple carplay or android auto, witHout aMp 2018-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 10 AUX cable into the AUX In on the aftermarket radio. If the vehicle has no RSE, isolate (tape) the 3.5mm jack and secure it out of the way. Note: On Pioneer radio, ensure that there is nothing plugged into the W/R port. Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 11 SPDIF POWER POWER N.C. SANTA FE SANTA FE SPORT ONLY SPORT ONLY N.C. BLACK STEP 3 MAESTRO RR2 MODULE CONNECT TO RR2 HK3 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 12 Illumination Orange Orange/White Orange/White Orange Reverse Light Purple/White Orange/White Purple/White Purple/White Purple/White E-Brake Lt Green Yellow/Blue Lt Green Lt Green Lt Green VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 13 Phone: 1-866-427-2999 Email: maestro.support@idatalink.com Web: maestro.idatalink.com/support add www.12voltdata.com/forum/ IMPORTANT: To ensure proper operation, the aftermarket radio needs to have the latest fi rmware from the manufacturer. Please visit the radio manufacturer’s website and look for any updates pertaining to your radio.
  • Page 14 5 incH display witHout apple carplay or android auto, witHout aMp RETAINS STEERING WHEEL CONTROLS, BACKUP CAMERA, GAUGES, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRN-RR-HK3 Installation Harness Radar Installation Guides...
  • Page 15 Hyundai elantra 5 incH display witHout apple carplay or android auto, witHout aMp 2019-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 16 AUX cable into the AUX In on the aftermarket radio. If the vehicle has no RSE, isolate (tape) the 3.5mm jack and secure it out of the way. Note: On Pioneer radio, ensure that there is nothing plugged into the W/R port. Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 17 SPDIF POWER POWER N.C. SANTA FE SANTA FE SPORT ONLY SPORT ONLY N.C. STEP 3 STEP 4 OBDII CONNECTOR MAESTRO RR2 MODULE HK3 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 18 Illumination Orange Orange/White Orange/White Orange Reverse Light Purple/White Orange/White Purple/White Purple/White Purple/White E-Brake Lt Green Yellow/Blue Lt Green Lt Green Lt Green VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 19 Phone: 1-866-427-2999 Email: maestro.support@idatalink.com Web: maestro.idatalink.com/support add www.12voltdata.com/forum/ IMPORTANT: To ensure proper operation, the aftermarket radio needs to have the latest fi rmware from the manufacturer. Please visit the radio manufacturer’s website and look for any updates pertaining to your radio.
  • Page 20 Hyundai Elantra Gt witH applE Carplay or android auto, witH aMp RETAINS STEERING WHEEL CONTROLS, BACKUP CAMERA, GAUGES, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRN-RR-HK3 Installation Harness Radar Installation Guides ACC-RR-SPDIF...
  • Page 21 Hyundai elantra Gt witH apple carplay or android auto, witH aMp 2018-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 22 • Plug the aftermarket radio harnesses into the aftermarket radio. • Plug the backup camera RCA into the aftermarket radio’s backup camera input (if applicable). • Plug the Data cable to the data port of the aftermarket Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 23 SANTA FE SANTA FE SPORT ONLY SPORT ONLY N.C. N.C. SPDIF1 SPDIF1 N.C. STEP 3 BLACK MAESTRO RR2 MODULE CONNECT TO RR2 HK3 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 24 Illumination Orange Orange/White Orange/White Orange Reverse Light Purple/White Orange/White Purple/White Purple/White Purple/White E-Brake Lt Green Yellow/Blue Lt Green Lt Green Lt Green VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 25 Phone: 1-866-427-2999 Email: maestro.support@idatalink.com Web: maestro.idatalink.com/support add www.12voltdata.com/forum/ IMPORTANT: To ensure proper operation, the aftermarket radio needs to have the latest fi rmware from the manufacturer. Please visit the radio manufacturer’s website and look for any updates pertaining to your radio.
  • Page 26 RETAINS STEERING WHEEL CONTROLS, BACKUP CAMERA, GAUGES, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRN-RR-HK3 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 27 Hyundai elantra Gt witH apple carplay or android auto, witHout aMp 2018-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 28 AUX cable into the AUX In on the aftermarket radio. If the vehicle has no RSE, isolate (tape) the 3.5mm jack and secure it out of the way. Note: On Pioneer radio, ensure that there is nothing plugged into the W/R port. Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 29 SPDIF POWER POWER N.C. SANTA FE SANTA FE SPORT ONLY SPORT ONLY N.C. BLACK STEP 3 MAESTRO RR2 MODULE CONNECT TO RR2 HK3 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 30 Illumination Orange Orange/White Orange/White Orange Reverse Light Purple/White Orange/White Purple/White Purple/White Purple/White E-Brake Lt Green Yellow/Blue Lt Green Lt Green Lt Green VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 31 Phone: 1-866-427-2999 Email: maestro.support@idatalink.com Web: maestro.idatalink.com/support add www.12voltdata.com/forum/ IMPORTANT: To ensure proper operation, the aftermarket radio needs to have the latest fi rmware from the manufacturer. Please visit the radio manufacturer’s website and look for any updates pertaining to your radio.
  • Page 32 Hyundai Elantra witH applE Carplay or android auto, witH aMp RETAINS STEERING WHEEL CONTROLS, BACKUP CAMERA, GAUGES, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRN-RR-HK3 Installation Harness Radar Installation Guides ACC-RR-SPDIF...
  • Page 33 Hyundai elantra witH apple carplay or android auto, witH aMp 2017-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 34 • Plug the aftermarket radio harnesses into the aftermarket radio. • Plug the backup camera RCA into the aftermarket radio’s backup camera input (if applicable). • Plug the Data cable to the data port of the aftermarket Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 35 SANTA FE SANTA FE SPORT ONLY SPORT ONLY N.C. N.C. SPDIF1 SPDIF1 N.C. STEP 3 BLACK MAESTRO RR2 MODULE CONNECT TO RR2 HK3 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 36 Illumination Orange Orange/White Orange/White Orange Reverse Light Purple/White Orange/White Purple/White Purple/White Purple/White E-Brake Lt Green Yellow/Blue Lt Green Lt Green Lt Green VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 37 Phone: 1-866-427-2999 Email: maestro.support@idatalink.com Web: maestro.idatalink.com/support add www.12voltdata.com/forum/ IMPORTANT: To ensure proper operation, the aftermarket radio needs to have the latest fi rmware from the manufacturer. Please visit the radio manufacturer’s website and look for any updates pertaining to your radio.
  • Page 38 RETAINS STEERING WHEEL CONTROLS, BACKUP CAMERA, GAUGES, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRN-RR-HK3 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 39 Hyundai elantra witH apple carplay or android auto, witHout aMp 2017-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 40 AUX cable into the AUX In on the aftermarket radio. If the vehicle has no RSE, isolate (tape) the 3.5mm jack and secure it out of the way. Note: On Pioneer radio, ensure that there is nothing plugged into the W/R port. Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 41 SPDIF POWER POWER N.C. SANTA FE SANTA FE SPORT ONLY SPORT ONLY N.C. BLACK STEP 3 MAESTRO RR2 MODULE CONNECT TO RR2 HK3 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 42 Illumination Orange Orange/White Orange/White Orange Reverse Light Purple/White Orange/White Purple/White Purple/White Purple/White E-Brake Lt Green Yellow/Blue Lt Green Lt Green Lt Green VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 43 Phone: 1-866-427-2999 Email: maestro.support@idatalink.com Web: maestro.idatalink.com/support add www.12voltdata.com/forum/ IMPORTANT: To ensure proper operation, the aftermarket radio needs to have the latest fi rmware from the manufacturer. Please visit the radio manufacturer’s website and look for any updates pertaining to your radio.
  • Page 44 RETAINS STEERING WHEEL CONTROLS, BACKUP CAMERA, GAUGES, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRN-RR-HK3 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 45 Hyundai santa Fe sport witH apple carplay or android auto, witHout aMp 2017-2018 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 46 • If the vehicle has Rear Seat Entertainment, plug the RSE/ AUX cable into the AUX In on the aftermarket radio. If the vehicle has no RSE, isolate (tape) the 3.5mm jack and Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 47 POWER N.C. N.C. SPDIF2 SPDIF2 SANTA FE SANTA FE SPORT ONLY SPORT ONLY STEP 3 OBDII CONNECTOR STEP 4 MAESTRO RR2 MODULE HK3 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 48 Illumination Orange Orange/White Orange/White Orange Reverse Light Purple/White Orange/White Purple/White Purple/White Purple/White E-Brake Lt Green Yellow/Blue Lt Green Lt Green Lt Green VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 49 Phone: 1-866-427-2999 Email: maestro.support@idatalink.com Web: maestro.idatalink.com/support add www.12voltdata.com/forum/ IMPORTANT: To ensure proper operation, the aftermarket radio needs to have the latest fi rmware from the manufacturer. Please visit the radio manufacturer’s website and look for any updates pertaining to your radio.
  • Page 50 Hyundai Santa Fe witH apple Carplay or android auto, witH aMp RETAINS STEERING WHEEL CONTROLS, BACKUP CAMERA, GAUGES, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRN-RR-HK3 Installation Harness Radar Installation Guides ACC-RR-SPDIF...
  • Page 51 Hyundai santa Fe witH apple carplay or android auto, witH aMp 2016-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 52 • Plug the aftermarket radio harnesses into the aftermarket radio. • Plug the backup camera RCA into the aftermarket radio’s backup camera input (if applicable). • Plug the Data cable to the data port of the aftermarket Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 53 SANTA FE SANTA FE SPORT ONLY SPORT ONLY N.C. N.C. SPDIF1 SPDIF1 N.C. STEP 3 BLACK MAESTRO RR2 MODULE CONNECT TO RR2 HK3 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 54 Illumination Orange Orange/White Orange/White Orange Reverse Light Purple/White Orange/White Purple/White Purple/White Purple/White E-Brake Lt Green Yellow/Blue Lt Green Lt Green Lt Green VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 55 Phone: 1-866-427-2999 Email: maestro.support@idatalink.com Web: maestro.idatalink.com/support add www.12voltdata.com/forum/ IMPORTANT: To ensure proper operation, the aftermarket radio needs to have the latest fi rmware from the manufacturer. Please visit the radio manufacturer’s website and look for any updates pertaining to your radio.
  • Page 56 RETAINS STEERING WHEEL CONTROLS, BACKUP CAMERA, GAUGES, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRN-RR-HK3 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 57 Hyundai santa Fe witH apple carplay or android auto, witHout aMp 2016-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 58 AUX cable into the AUX In on the aftermarket radio. If the vehicle has no RSE, isolate (tape) the 3.5mm jack and secure it out of the way. Note: On Pioneer radio, ensure that there is nothing plugged into the W/R port. Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 59 SPDIF POWER POWER N.C. SANTA FE SANTA FE SPORT ONLY SPORT ONLY N.C. BLACK STEP 3 MAESTRO RR2 MODULE CONNECT TO RR2 HK3 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 60 Illumination Orange Orange/White Orange/White Orange Reverse Light Purple/White Orange/White Purple/White Purple/White Purple/White E-Brake Lt Green Yellow/Blue Lt Green Lt Green Lt Green VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 61 Phone: 1-866-427-2999 Email: maestro.support@idatalink.com Web: maestro.idatalink.com/support add www.12voltdata.com/forum/ IMPORTANT: To ensure proper operation, the aftermarket radio needs to have the latest fi rmware from the manufacturer. Please visit the radio manufacturer’s website and look for any updates pertaining to your radio.
  • Page 62 Hyundai Sonata witH apple Carplay or android auto, witH aMp RETAINS STEERING WHEEL CONTROLS, BACKUP CAMERA, GAUGES, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRN-RR-HK3 Installation Harness Radar Installation Guides ACC-RR-SPDIF...
  • Page 63 Hyundai sonata witH apple carplay or android auto, witH aMp 2017-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 64 21 pin connector to the RR2. STEP 3 • Connect all the harnesses from the rHK3 to the Maestro RR2 module. • Plug the Data Cable into the BLACK 4 pin port of the RR2. Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 65 TO AUDIO/CLIMATE SPDIF1 SPDIF1 N.C. PANEL GRAY TO USB ADAPTER UHK1 OR UHK2 STEP 3 BLACK MAESTRO RR2 MODULE CONNECT TO RR2 HK3 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 66 Illumination Orange Orange/White Orange/White Orange Reverse Light Purple/White Orange/White Purple/White Purple/White Purple/White E-Brake Lt Green Yellow/Blue Lt Green Lt Green Lt Green VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 67 Phone: 1-866-427-2999 Email: maestro.support@idatalink.com Web: maestro.idatalink.com/support add www.12voltdata.com/forum/ IMPORTANT: To ensure proper operation, the aftermarket radio needs to have the latest fi rmware from the manufacturer. Please visit the radio manufacturer’s website and look for any updates pertaining to your radio.
  • Page 68 RETAINS STEERING WHEEL CONTROLS, BACKUP CAMERA, GAUGES, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRN-RR-HK3 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 69 Hyundai sonata witH apple carplay or android auto, witHout aMp 2017-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 70 • Plug the Data Cable into the BLACK 4 pin port of the RR2. STEP 4 • Plug the aftermarket radio harnesses into the aftermarket radio. • Plug the backup camera RCA into the aftermarket radio’s Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 71 SANTA FE SPORT ONLY SPORT ONLY N.C. GRAY TO USB ADAPTER UHK1 OR UHK2 BLACK STEP 3 MAESTRO RR2 MODULE CONNECT TO RR2 HK3 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 72 Illumination Orange Orange/White Orange/White Orange Reverse Light Purple/White Orange/White Purple/White Purple/White Purple/White E-Brake Lt Green Yellow/Blue Lt Green Lt Green Lt Green VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 73 Phone: 1-866-427-2999 Email: maestro.support@idatalink.com Web: maestro.idatalink.com/support add www.12voltdata.com/forum/ IMPORTANT: To ensure proper operation, the aftermarket radio needs to have the latest fi rmware from the manufacturer. Please visit the radio manufacturer’s website and look for any updates pertaining to your radio.
  • Page 74 Hyundai Tucson wiTH apple carplay or android auTo, wiTH aMp RETAINS STEERING WHEEL CONTROLS, BACKUP CAMERA, GAUGES, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRN-RR-HK3 Installation Harness Radar Installation Guides ACC-RR-SPDIF...
  • Page 75 Hyundai tucson witH apple carplay or android auto, witH aMp 2019-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 76 • Plug the aftermarket radio harnesses into the aftermarket radio. • Plug the backup camera RCA into the aftermarket radio’s backup camera input (if applicable). • Plug the Data cable to the data port of the aftermarket Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 77 SANTA FE SANTA FE SPORT ONLY SPORT ONLY N.C. N.C. SPDIF1 SPDIF1 N.C. STEP 3 BLACK MAESTRO RR2 MODULE CONNECT TO RR2 HK3 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 78 Illumination Orange Orange/White Orange/White Orange Reverse Light Purple/White Orange/White Purple/White Purple/White Purple/White E-Brake Lt Green Yellow/Blue Lt Green Lt Green Lt Green VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 79 Phone: 1-866-427-2999 Email: maestro.support@idatalink.com Web: maestro.idatalink.com/support add www.12voltdata.com/forum/ IMPORTANT: To ensure proper operation, the aftermarket radio needs to have the latest fi rmware from the manufacturer. Please visit the radio manufacturer’s website and look for any updates pertaining to your radio.
  • Page 80 RETAINS STEERING WHEEL CONTROLS, BACKUP CAMERA, GAUGES, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRN-RR-HK3 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 81 Hyundai tucson witH apple carplay or android auto, witHout aMp 2017-20218 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 82 AUX cable into the AUX In on the aftermarket radio. If the vehicle has no RSE, isolate (tape) the 3.5mm jack and secure it out of the way. Note: On Pioneer radio, ensure that there is nothing plugged into the W/R port. Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 83 SPDIF POWER POWER N.C. SANTA FE SANTA FE SPORT ONLY SPORT ONLY N.C. STEP 3 STEP 4 OBDII CONNECTOR MAESTRO RR2 MODULE HK3 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 84 Illumination Orange Orange/White Orange/White Orange Reverse Light Purple/White Orange/White Purple/White Purple/White Purple/White E-Brake Lt Green Yellow/Blue Lt Green Lt Green Lt Green VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 85 Phone: 1-866-427-2999 Email: maestro.support@idatalink.com Web: maestro.idatalink.com/support add www.12voltdata.com/forum/ IMPORTANT: To ensure proper operation, the aftermarket radio needs to have the latest fi rmware from the manufacturer. Please visit the radio manufacturer’s website and look for any updates pertaining to your radio.
  • Page 86 RETAINS STEERING WHEEL CONTROLS, BACKUP CAMERA, GAUGES, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRN-RR-HK3 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 87 Hyundai tucson witH apple carplay or android auto, witHout aMp 2019-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 88 AUX cable into the AUX In on the aftermarket radio. If the vehicle has no RSE, isolate (tape) the 3.5mm jack and secure it out of the way. Note: On Pioneer radio, ensure that there is nothing plugged into the W/R port. Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 89 SPDIF POWER POWER N.C. SANTA FE SANTA FE SPORT ONLY SPORT ONLY N.C. BLACK STEP 3 MAESTRO RR2 MODULE CONNECT TO RR2 HK3 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 90 Illumination Orange Orange/White Orange/White Orange Reverse Light Purple/White Orange/White Purple/White Purple/White Purple/White E-Brake Lt Green Yellow/Blue Lt Green Lt Green Lt Green VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 91 Phone: 1-866-427-2999 Email: maestro.support@idatalink.com Web: maestro.idatalink.com/support add www.12voltdata.com/forum/ IMPORTANT: To ensure proper operation, the aftermarket radio needs to have the latest fi rmware from the manufacturer. Please visit the radio manufacturer’s website and look for any updates pertaining to your radio.
  • Page 92 Kia Forte with apple Carplay or android auto, with aMp RETAINS STEERING WHEEL CONTROLS, BACKUP CAMERA, GAUGES, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRN-RR-HK3 Installation Harness Radar Installation Guides ACC-RR-SPDIF...
  • Page 93 Kia Forte witH apple carplay or android auto, witH aMp 2019-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 94 • Plug the aftermarket radio harnesses into the aftermarket radio. • Plug the backup camera RCA into the aftermarket radio’s backup camera input (if applicable). • Plug the Data cable to the data port of the aftermarket Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 95 SANTA FE SANTA FE SPORT ONLY SPORT ONLY N.C. N.C. SPDIF1 SPDIF1 N.C. STEP 3 BLACK MAESTRO RR2 MODULE CONNECT TO RR2 HK3 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 96 Illumination Orange Orange/White Orange/White Orange Reverse Light Purple/White Orange/White Purple/White Purple/White Purple/White E-Brake Lt Green Yellow/Blue Lt Green Lt Green Lt Green VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 97 Phone: 1-866-427-2999 Email: maestro.support@idatalink.com Web: maestro.idatalink.com/support add www.12voltdata.com/forum/ IMPORTANT: To ensure proper operation, the aftermarket radio needs to have the latest fi rmware from the manufacturer. Please visit the radio manufacturer’s website and look for any updates pertaining to your radio.
  • Page 98 RETAINS STEERING WHEEL CONTROLS, BACKUP CAMERA, GAUGES, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRN-RR-HK3 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 99 Kia Forte witH apple carplay or android auto, witHout aMp 2017-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 100 AUX cable into the AUX In on the aftermarket radio. If the vehicle has no RSE, isolate (tape) the 3.5mm jack and secure it out of the way. Note: On Pioneer radio, ensure that there is nothing plugged into the W/R port. Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 101 SPDIF POWER POWER N.C. SANTA FE SANTA FE SPORT ONLY SPORT ONLY N.C. BLACK STEP 3 MAESTRO RR2 MODULE CONNECT TO RR2 HK3 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 102 Illumination Orange Orange/White Orange/White Orange Reverse Light Purple/White Orange/White Purple/White Purple/White Purple/White E-Brake Lt Green Yellow/Blue Lt Green Lt Green Lt Green VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 103 Phone: 1-866-427-2999 Email: maestro.support@idatalink.com Web: maestro.idatalink.com/support add www.12voltdata.com/forum/ IMPORTANT: To ensure proper operation, the aftermarket radio needs to have the latest fi rmware from the manufacturer. Please visit the radio manufacturer’s website and look for any updates pertaining to your radio.
  • Page 104 Kia Optima with apple Carplay Or andrOid autO, with amp RETAINS STEERING WHEEL CONTROLS, BACKUP CAMERA, GAUGES, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRN-RR-HK3 Installation Harness Radar Installation Guides ACC-RR-SPDIF...
  • Page 105 Kia optiMa witH apple carplay or android auto, witH aMp 2017-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 106 • Plug the aftermarket radio harnesses into the aftermarket radio. • Plug the backup camera RCA into the aftermarket radio’s backup camera input (if applicable). • Plug the Data cable to the data port of the aftermarket Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 107 SANTA FE SANTA FE SPORT ONLY SPORT ONLY N.C. N.C. SPDIF1 SPDIF1 N.C. STEP 3 BLACK MAESTRO RR2 MODULE CONNECT TO RR2 HK3 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 108 Illumination Orange Orange/White Orange/White Orange Reverse Light Purple/White Orange/White Purple/White Purple/White Purple/White E-Brake Lt Green Yellow/Blue Lt Green Lt Green Lt Green VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 109 Phone: 1-866-427-2999 Email: maestro.support@idatalink.com Web: maestro.idatalink.com/support add www.12voltdata.com/forum/ IMPORTANT: To ensure proper operation, the aftermarket radio needs to have the latest fi rmware from the manufacturer. Please visit the radio manufacturer’s website and look for any updates pertaining to your radio.
  • Page 110 RETAINS STEERING WHEEL CONTROLS, BACKUP CAMERA, GAUGES, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRN-RR-HK3 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 111 Kia optiMa witH apple carplay or android auto, witHout aMp 2017-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 112 AUX cable into the AUX In on the aftermarket radio. If the vehicle has no RSE, isolate (tape) the 3.5mm jack and secure it out of the way. Note: On Pioneer radio, ensure that there is nothing plugged into the W/R port. Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 113 SPDIF POWER POWER N.C. SANTA FE SANTA FE SPORT ONLY SPORT ONLY N.C. BLACK STEP 3 MAESTRO RR2 MODULE CONNECT TO RR2 HK3 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 114 Illumination Orange Orange/White Orange/White Orange Reverse Light Purple/White Orange/White Purple/White Purple/White Purple/White E-Brake Lt Green Yellow/Blue Lt Green Lt Green Lt Green VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 115 Phone: 1-866-427-2999 Email: maestro.support@idatalink.com Web: maestro.idatalink.com/support add www.12voltdata.com/forum/ IMPORTANT: To ensure proper operation, the aftermarket radio needs to have the latest fi rmware from the manufacturer. Please visit the radio manufacturer’s website and look for any updates pertaining to your radio.
  • Page 116 RETAINS STEERING WHEEL CONTROLS, BACKUP CAMERA, GAUGES, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRN-RR-HK3 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 117 Kia rio 5 witH apple carplay or android auto, witHout aMp 2018-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 118 AUX cable into the AUX In on the aftermarket radio. If the vehicle has no RSE, isolate (tape) the 3.5mm jack and secure it out of the way. Note: On Pioneer radio, ensure that there is nothing plugged into the W/R port. Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 119 SPDIF POWER POWER N.C. SANTA FE SANTA FE SPORT ONLY SPORT ONLY N.C. BLACK STEP 3 MAESTRO RR2 MODULE CONNECT TO RR2 HK3 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 120 Illumination Orange Orange/White Orange/White Orange Reverse Light Purple/White Orange/White Purple/White Purple/White Purple/White E-Brake Lt Green Yellow/Blue Lt Green Lt Green Lt Green VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 121 Phone: 1-866-427-2999 Email: maestro.support@idatalink.com Web: maestro.idatalink.com/support add www.12voltdata.com/forum/ IMPORTANT: To ensure proper operation, the aftermarket radio needs to have the latest fi rmware from the manufacturer. Please visit the radio manufacturer’s website and look for any updates pertaining to your radio.
  • Page 122 RETAINS STEERING WHEEL CONTROLS, BACKUP CAMERA, GAUGES, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRN-RR-HK3 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 123 Kia rio witH apple carplay or android auto, witHout aMp 2018-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 124 AUX cable into the AUX In on the aftermarket radio. If the vehicle has no RSE, isolate (tape) the 3.5mm jack and secure it out of the way. Note: On Pioneer radio, ensure that there is nothing plugged into the W/R port. Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 125 SPDIF POWER POWER N.C. SANTA FE SANTA FE SPORT ONLY SPORT ONLY N.C. BLACK STEP 3 MAESTRO RR2 MODULE CONNECT TO RR2 HK3 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 126 Illumination Orange Orange/White Orange/White Orange Reverse Light Purple/White Orange/White Purple/White Purple/White Purple/White E-Brake Lt Green Yellow/Blue Lt Green Lt Green Lt Green VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 127 Phone: 1-866-427-2999 Email: maestro.support@idatalink.com Web: maestro.idatalink.com/support add www.12voltdata.com/forum/ IMPORTANT: To ensure proper operation, the aftermarket radio needs to have the latest fi rmware from the manufacturer. Please visit the radio manufacturer’s website and look for any updates pertaining to your radio.
  • Page 128 RETAINS STEERING WHEEL CONTROLS, BACKUP CAMERA, GAUGES, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRN-RR-HK3 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 129 Kia sedona naviGation radio, witH aMp 2019-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 130 • Plug the Data Cable into the BLACK 4 pin port of the RR2. STEP 4 • Plug the aftermarket radio harnesses into the aftermarket radio. • Plug the backup camera RCA into the aftermarket radio’s Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 131 SANTA FE SPORT ONLY SPORT ONLY N.C. GRAY TO USB ADAPTER UHK1 OR UHK2 BLACK STEP 3 MAESTRO RR2 MODULE CONNECT TO RR2 HK3 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 132 Illumination Orange Orange/White Orange/White Orange Reverse Light Purple/White Orange/White Purple/White Purple/White Purple/White E-Brake Lt Green Yellow/Blue Lt Green Lt Green Lt Green VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 133 Phone: 1-866-427-2999 Email: maestro.support@idatalink.com Web: maestro.idatalink.com/support add www.12voltdata.com/forum/ IMPORTANT: To ensure proper operation, the aftermarket radio needs to have the latest fi rmware from the manufacturer. Please visit the radio manufacturer’s website and look for any updates pertaining to your radio.
  • Page 134 Kia Sedona navigation radio, without aMP RETAINS STEERING WHEEL CONTROLS, BACKUP CAMERA, GAUGES, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRN-RR-HK3 Installation Harness Radar Installation Guides ACC-RR-SPDIF E L E C T R O N I C S...
  • Page 135 Kia sedona naviGation radio, witHout aMp 2019-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 136 • Plug the aftermarket radio harnesses into the aftermarket radio. • Plug the backup camera RCA into the aftermarket radio’s backup camera input (if applicable). • Plug the Data cable to the data port of the aftermarket radio. Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 137 SANTA FE SANTA FE SPORT ONLY SPORT ONLY N.C. N.C. SPDIF2 SPDIF2 N.C. STEP 3 STEP 4 OBDII CONNECTOR MAESTRO RR2 MODULE HK3 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 138 Illumination Orange Orange/White Orange/White Orange Reverse Light Purple/White Orange/White Purple/White Purple/White Purple/White E-Brake Lt Green Yellow/Blue Lt Green Lt Green Lt Green VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 139 Phone: 1-866-427-2999 Email: maestro.support@idatalink.com Web: maestro.idatalink.com/support add www.12voltdata.com/forum/ IMPORTANT: To ensure proper operation, the aftermarket radio needs to have the latest fi rmware from the manufacturer. Please visit the radio manufacturer’s website and look for any updates pertaining to your radio.
  • Page 140 RETAINS STEERING WHEEL CONTROLS, BACKUP CAMERA, GAUGES, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRN-RR-HK3 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 141 Kia sedona sMall display radio, witH aMp 2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 142 AUX cable into the AUX In on the aftermarket radio. If the vehicle has no RSE, isolate (tape) the 3.5mm jack and secure it out of the way. Note: On Pioneer radio, ensure that there is nothing plugged into the W/R port. Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 143 SPDIF POWER POWER N.C. SANTA FE SANTA FE SPORT ONLY SPORT ONLY N.C. STEP 3 STEP 4 OBDII CONNECTOR MAESTRO RR2 MODULE HK3 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 144 Illumination Orange Orange/White Orange/White Orange Reverse Light Purple/White Orange/White Purple/White Purple/White Purple/White E-Brake Lt Green Yellow/Blue Lt Green Lt Green Lt Green VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 145 Phone: 1-866-427-2999 Email: maestro.support@idatalink.com Web: maestro.idatalink.com/support add www.12voltdata.com/forum/ IMPORTANT: To ensure proper operation, the aftermarket radio needs to have the latest fi rmware from the manufacturer. Please visit the radio manufacturer’s website and look for any updates pertaining to your radio.
  • Page 146 Kia Sedona Small diSplay radio, without amp RETAINS STEERING WHEEL CONTROLS, BACKUP CAMERA, GAUGES, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRN-RR-HK3 Installation Harness Radar Installation Guides ACC-RR-SPDIF E L E C T R O N I C S...
  • Page 147 Kia sedona sMall display radio, witHout aMp 2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 148 21 pin connector to the RR2. STEP 3 • Connect all the harnesses from the rHK3 to the Maestro RR2 module. • Plug the Data Cable into the BLACK 4 pin port of the RR2. Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 149 TO AUDIO/CLIMATE SPDIF1 SPDIF1 N.C. PANEL GRAY TO USB ADAPTER UHK1 OR UHK2 STEP 3 BLACK MAESTRO RR2 MODULE CONNECT TO RR2 HK3 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 150 Illumination Orange Orange/White Orange/White Orange Reverse Light Purple/White Orange/White Purple/White Purple/White Purple/White E-Brake Lt Green Yellow/Blue Lt Green Lt Green Lt Green VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 151 Phone: 1-866-427-2999 Email: maestro.support@idatalink.com Web: maestro.idatalink.com/support add www.12voltdata.com/forum/ IMPORTANT: To ensure proper operation, the aftermarket radio needs to have the latest fi rmware from the manufacturer. Please visit the radio manufacturer’s website and look for any updates pertaining to your radio.
  • Page 152 Kia Sedona with apple Carplay or android auto, with aMp RETAINS STEERING WHEEL CONTROLS, BACKUP CAMERA, GAUGES, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRN-RR-HK3 Installation Harness Radar Installation Guides ACC-RR-SPDIF...
  • Page 153 Kia sedona witH apple carplay or android auto, witH aMp 2017-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 154 • Plug the backup camera RCA into the aftermarket radio’s backup camera input (if applicable). • Plug the Data cable to the data port of the aftermarket radio. • Connect the RCA cables (from the ACC-RR-SPDIF) in the Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 155 SANTA FE SANTA FE SPORT ONLY SPORT ONLY N.C. N.C. SPDIF1 SPDIF1 N.C. STEP 3 BLACK MAESTRO RR2 MODULE CONNECT TO RR2 HK3 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 156 Illumination Orange Orange/White Orange/White Orange Reverse Light Purple/White Orange/White Purple/White Purple/White Purple/White E-Brake Lt Green Yellow/Blue Lt Green Lt Green Lt Green VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 157 Phone: 1-866-427-2999 Email: maestro.support@idatalink.com Web: maestro.idatalink.com/support add www.12voltdata.com/forum/ IMPORTANT: To ensure proper operation, the aftermarket radio needs to have the latest fi rmware from the manufacturer. Please visit the radio manufacturer’s website and look for any updates pertaining to your radio.
  • Page 158 RETAINS STEERING WHEEL CONTROLS, BACKUP CAMERA, GAUGES, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRN-RR-HK3 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 159 Kia sedona witH apple carplay or android auto, witHout aMp 2017-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 160 AUX cable into the AUX In on the aftermarket radio. If the vehicle has no RSE, isolate (tape) the 3.5mm jack and secure it out of the way. Note: On Pioneer radio, ensure that there is nothing plugged into the W/R port. Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 161 SPDIF POWER POWER N.C. SANTA FE SANTA FE SPORT ONLY SPORT ONLY N.C. BLACK STEP 3 MAESTRO RR2 MODULE CONNECT TO RR2 HK3 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 162 Illumination Orange Orange/White Orange/White Orange Reverse Light Purple/White Orange/White Purple/White Purple/White Purple/White E-Brake Lt Green Yellow/Blue Lt Green Lt Green Lt Green VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 163 Phone: 1-866-427-2999 Email: maestro.support@idatalink.com Web: maestro.idatalink.com/support add www.12voltdata.com/forum/ IMPORTANT: To ensure proper operation, the aftermarket radio needs to have the latest fi rmware from the manufacturer. Please visit the radio manufacturer’s website and look for any updates pertaining to your radio.
  • Page 164 Kia Sorento with apple Carplay or android auto, with aMp RETAINS STEERING WHEEL CONTROLS, BACKUP CAMERA, GAUGES, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRN-RR-HK3 Installation Harness Radar Installation Guides ACC-RR-SPDIF...
  • Page 165 Kia sorento witH apple carplay or android auto, witH aMp 2017-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 166 • Plug the backup camera RCA into the aftermarket radio’s backup camera input (if applicable). • Plug the Data cable to the data port of the aftermarket radio. • Connect the RCA cables (from the ACC-RR-SPDIF) in the Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 167 SANTA FE SANTA FE SPORT ONLY SPORT ONLY N.C. N.C. SPDIF1 SPDIF1 N.C. STEP 3 BLACK MAESTRO RR2 MODULE CONNECT TO RR2 HK3 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 168 Illumination Orange Orange/White Orange/White Orange Reverse Light Purple/White Orange/White Purple/White Purple/White Purple/White E-Brake Lt Green Yellow/Blue Lt Green Lt Green Lt Green VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 169 Phone: 1-866-427-2999 Email: maestro.support@idatalink.com Web: maestro.idatalink.com/support add www.12voltdata.com/forum/ IMPORTANT: To ensure proper operation, the aftermarket radio needs to have the latest fi rmware from the manufacturer. Please visit the radio manufacturer’s website and look for any updates pertaining to your radio.
  • Page 170 RETAINS STEERING WHEEL CONTROLS, BACKUP CAMERA, GAUGES, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRN-RR-HK3 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 171 Kia sorento witH apple carplay or android auto, witHout aMp 2017-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 172 AUX cable into the AUX In on the aftermarket radio. If the vehicle has no RSE, isolate (tape) the 3.5mm jack and secure it out of the way. Note: On Pioneer radio, ensure that there is nothing plugged into the W/R port. Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 173 SPDIF POWER POWER N.C. SANTA FE SANTA FE SPORT ONLY SPORT ONLY N.C. BLACK STEP 3 MAESTRO RR2 MODULE CONNECT TO RR2 HK3 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 174 Illumination Orange Orange/White Orange/White Orange Reverse Light Purple/White Orange/White Purple/White Purple/White Purple/White E-Brake Lt Green Yellow/Blue Lt Green Lt Green Lt Green VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 175 Phone: 1-866-427-2999 Email: maestro.support@idatalink.com Web: maestro.idatalink.com/support add www.12voltdata.com/forum/ IMPORTANT: To ensure proper operation, the aftermarket radio needs to have the latest fi rmware from the manufacturer. Please visit the radio manufacturer’s website and look for any updates pertaining to your radio.
  • Page 176 Kia Soul with uVo, with aMP RETAINS STEERING WHEEL CONTROLS, BACKUP CAMERA, GAUGES, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRN-RR-HK3 Installation Harness Radar Installation Guides ACC-RR-SPDIF E L E C T R O N I C S...
  • Page 177 Kia soul witH uvo, witH aMp 2017-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 178 • Plug the aftermarket radio harnesses into the aftermarket radio. • Plug the backup camera RCA into the aftermarket radio’s backup camera input (if applicable). • Plug the Data cable to the data port of the aftermarket Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 179 SANTA FE SANTA FE SPORT ONLY SPORT ONLY N.C. N.C. SPDIF1 SPDIF1 N.C. STEP 3 BLACK MAESTRO RR2 MODULE CONNECT TO RR2 HK3 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 180 Illumination Orange Orange/White Orange/White Orange Reverse Light Purple/White Orange/White Purple/White Purple/White Purple/White E-Brake Lt Green Yellow/Blue Lt Green Lt Green Lt Green VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 181 Phone: 1-866-427-2999 Email: maestro.support@idatalink.com Web: maestro.idatalink.com/support add www.12voltdata.com/forum/ IMPORTANT: To ensure proper operation, the aftermarket radio needs to have the latest fi rmware from the manufacturer. Please visit the radio manufacturer’s website and look for any updates pertaining to your radio.
  • Page 182 RETAINS STEERING WHEEL CONTROLS, BACKUP CAMERA, GAUGES, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRN-RR-HK3 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 183 Kia soul witH uvo, witHout aMp 2017-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 184 AUX cable into the AUX In on the aftermarket radio. If the vehicle has no RSE, isolate (tape) the 3.5mm jack and secure it out of the way. Note: On Pioneer radio, ensure that there is nothing plugged into the W/R port. Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 185 SPDIF POWER POWER N.C. SANTA FE SANTA FE SPORT ONLY SPORT ONLY N.C. BLACK STEP 3 MAESTRO RR2 MODULE CONNECT TO RR2 HK3 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 186 Illumination Orange Orange/White Orange/White Orange Reverse Light Purple/White Orange/White Purple/White Purple/White Purple/White E-Brake Lt Green Yellow/Blue Lt Green Lt Green Lt Green VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 187 Phone: 1-866-427-2999 Email: maestro.support@idatalink.com Web: maestro.idatalink.com/support add www.12voltdata.com/forum/ IMPORTANT: To ensure proper operation, the aftermarket radio needs to have the latest fi rmware from the manufacturer. Please visit the radio manufacturer’s website and look for any updates pertaining to your radio.
  • Page 188 RETAINS STEERING WHEEL CONTROLS, BACKUP CAMERA, GAUGES, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRN-RR-HK3 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 189 Kia soul witHout uvo, witHout aMp 2017-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 190 AUX cable into the AUX In on the aftermarket radio. If the vehicle has no RSE, isolate (tape) the 3.5mm jack and secure it out of the way. Note: On Pioneer radio, ensure that there is nothing plugged into the W/R port. Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 191 SPDIF POWER POWER N.C. SANTA FE SANTA FE SPORT ONLY SPORT ONLY N.C. STEP 3 STEP 4 OBDII CONNECTOR MAESTRO RR2 MODULE HK3 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 192 Illumination Orange Orange/White Orange/White Orange Reverse Light Purple/White Orange/White Purple/White Purple/White Purple/White E-Brake Lt Green Yellow/Blue Lt Green Lt Green Lt Green VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 193 Phone: 1-866-427-2999 Email: maestro.support@idatalink.com Web: maestro.idatalink.com/support add www.12voltdata.com/forum/ IMPORTANT: To ensure proper operation, the aftermarket radio needs to have the latest fi rmware from the manufacturer. Please visit the radio manufacturer’s website and look for any updates pertaining to your radio.
  • Page 194 Kia Sportage with apple Carplay or android auto, with aMp RETAINS STEERING WHEEL CONTROLS, BACKUP CAMERA, GAUGES, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRN-RR-HK3 Installation Harness Radar Installation Guides ACC-RR-SPDIF...
  • Page 195 Kia sportaGe witH apple carplay or android auto, witH aMp 2017-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 196 21 pin connector to the RR2. STEP 3 • Connect all the harnesses from the rHK3 to the Maestro RR2 module. • Plug the Data Cable into the BLACK 4 pin port of the RR2. Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 197 TO AUDIO/CLIMATE SPDIF1 SPDIF1 N.C. PANEL GRAY TO USB ADAPTER UHK1 OR UHK2 STEP 3 BLACK MAESTRO RR2 MODULE CONNECT TO RR2 HK3 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 198 Illumination Orange Orange/White Orange/White Orange Reverse Light Purple/White Orange/White Purple/White Purple/White Purple/White E-Brake Lt Green Yellow/Blue Lt Green Lt Green Lt Green VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 199 Phone: 1-866-427-2999 Email: maestro.support@idatalink.com Web: maestro.idatalink.com/support add www.12voltdata.com/forum/ IMPORTANT: To ensure proper operation, the aftermarket radio needs to have the latest fi rmware from the manufacturer. Please visit the radio manufacturer’s website and look for any updates pertaining to your radio.
  • Page 200 RETAINS STEERING WHEEL CONTROLS, BACKUP CAMERA, GAUGES, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRN-RR-HK3 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 201 Kia sportaGe witH apple carplay or android auto, witHout aMp 2017-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 202 • Plug the Data Cable into the BLACK 4 pin port of the RR2. STEP 4 • Plug the aftermarket radio harnesses into the aftermarket radio. • Plug the backup camera RCA into the aftermarket radio’s Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 203 SANTA FE SPORT ONLY SPORT ONLY N.C. GRAY TO USB ADAPTER UHK1 OR UHK2 BLACK STEP 3 MAESTRO RR2 MODULE CONNECT TO RR2 HK3 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 204 Illumination Orange Orange/White Orange/White Orange Reverse Light Purple/White Orange/White Purple/White Purple/White Purple/White E-Brake Lt Green Yellow/Blue Lt Green Lt Green Lt Green VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink Automotive Data Solutions Inc. © 2021 ADS-RR(SR)-HK3-DS-IG-EN maestro.idatalink.com...
  • Page 205 Phone: 1-866-427-2999 Email: maestro.support@idatalink.com Web: maestro.idatalink.com/support add www.12voltdata.com/forum/ IMPORTANT: To ensure proper operation, the aftermarket radio needs to have the latest fi rmware from the manufacturer. Please visit the radio manufacturer’s website and look for any updates pertaining to your radio.
