Open the Bookmarks menu and find your vehicle OR scroll
down until you find the install guide for your vehicle.
2
Print only the pages for your vehicle using the advanced
options in the Print menu.
3
Install your Maestro RR according to the guide for your vehicle.
Pressing the printer icon or "quick printing" this document will print
NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certifi ed technician. Logos and trademarks used here in
Page 1
Print only the pages for your vehicle using the advanced options in the Print menu. Install your Maestro RR according to the guide for your vehicle. WARNING Pressing the printer icon or “quick printing” this document will print all of the guides in this compilation.
Page 2
Ford EconolinE RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 3
Ford EconolinE 2008-2014 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 4
STEP 5 Note: only connect purple/white wire to radio reverse input or module damage will occur. • Connect all the harnesses to the Maestro RR module then test your installation. STEP 2 (Required for vehicles equipped with SYNC, without factory navigation system;...
Page 5
SWI 2 : BLUE/ORANGE CONTROL CABLE CENTER DASH, UNDER THE RADIO CONNECTION REQUIRED ONLY IF EQUIPPED WITH SYNC STEP 3 FACTORY RADIO HARNESS WIRES FROM VEHICLE STEP 5 MAESTRO RR MODULE HRR-FO1 T-HARNESS NOT REQUIRED DATA CABLE BACKUP CAM BACKUP CAM AUDIO CABLE Automotive Data Solutions Inc.
Page 9
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 10
Ford EdgE RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 11
Ford EdgE 2007-2010 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 12
STEP 5 Note: only connect purple/white wire to radio reverse input or module damage will occur. • Connect all the harnesses to the Maestro RR module then test your installation. STEP 2 (Required for vehicles equipped with SYNC, without factory navigation system;...
Page 13
CENTER CONSOLE, RIGHT SIDE, HARNESS GOING TO THE BACK CONNECTION REQUIRED ONLY IF EQUIPPED WITH SYNC STEP 3 FACTORY RADIO HARNESS WIRES FROM VEHICLE STEP 5 MAESTRO RR MODULE HRR-FO1 T-HARNESS NOT REQUIRED DATA CABLE BACKUP CAM BACKUP CAM AUDIO CABLE Automotive Data Solutions Inc.
Page 17
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 18
Ford EscapE RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 19
Ford EscapE 2008-2012 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 20
STEP 5 Note: only connect purple/white wire to radio reverse input or module damage will occur. • Connect all the harnesses to the Maestro RR module then test your installation. STEP 2 (Required for vehicles equipped with SYNC, without factory navigation system;...
Page 21
CONTROL CABLE JUNCTION CONNECTOR, BEHIND THE RADIO TO THE RIGHT CONNECTION REQUIRED ONLY IF EQUIPPED WITH SYNC STEP 3 FACTORY RADIO HARNESS WIRES FROM VEHICLE STEP 5 MAESTRO RR MODULE HRR-FO1 T-HARNESS NOT REQUIRED DATA CABLE BACKUP CAM BACKUP CAM AUDIO CABLE Automotive Data Solutions Inc.
Page 25
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 26
Ford ExpEdition RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 27
Ford ExpEdition 2007-2014 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 28
STEP 5 Note: only connect purple/white wire to radio reverse input or module damage will occur. • Connect all the harnesses to the Maestro RR module then test your installation. STEP 2 (Required for vehicles equipped with SYNC, without factory navigation system;...
Page 29
CENTER CONSOLE, RIGHT SIDE, HARNESS GOING TO THE BACK CONNECTION REQUIRED ONLY IF EQUIPPED WITH SYNC STEP 3 FACTORY RADIO HARNESS WIRES FROM VEHICLE STEP 5 MAESTRO RR MODULE HRR-FO1 T-HARNESS NOT REQUIRED DATA CABLE BACKUP CAM BACKUP CAM AUDIO CABLE Automotive Data Solutions Inc.
Page 33
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 34
Ford ExplorEr RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 35
Ford ExplorEr 2006-2010 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 36
STEP 5 Note: only connect purple/white wire to radio reverse input or module damage will occur. • Connect all the harnesses to the Maestro RR module then test your installation. STEP 2 (Required for vehicles equipped with SYNC, without factory navigation system;...
Page 37
CONTROL CABLE CENTER CONSOLE, HARNESS GOING TO THE BACK CONNECTION REQUIRED ONLY IF EQUIPPED WITH SYNC STEP 3 FACTORY RADIO HARNESS WIRES FROM VEHICLE STEP 5 MAESTRO RR MODULE HRR-FO1 T-HARNESS NOT REQUIRED DATA CABLE BACKUP CAM BACKUP CAM AUDIO CABLE Automotive Data Solutions Inc.
Page 41
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 42
Ford ExplorEr Sport trac RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 43
Ford ExplorEr Sport trac 2006-2010 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 44
STEP 5 Note: only connect purple/white wire to radio reverse input or module damage will occur. • Connect all the harnesses to the Maestro RR module then test your installation. STEP 2 (Required for vehicles equipped with SYNC, without factory navigation system;...
Page 45
CONTROL CABLE CENTER CONSOLE, HARNESS GOING TO THE BACK CONNECTION REQUIRED ONLY IF EQUIPPED WITH SYNC STEP 3 FACTORY RADIO HARNESS WIRES FROM VEHICLE STEP 5 MAESTRO RR MODULE HRR-FO1 T-HARNESS NOT REQUIRED DATA CABLE BACKUP CAM BACKUP CAM AUDIO CABLE Automotive Data Solutions Inc.
Page 49
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 50
Ford F-SerieS Super duty RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 51
Ford F-SerieS Super duty 2008-2010 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 52
STEP 5 Note: only connect purple/white wire to radio reverse input or module damage will occur. • Connect all the harnesses to the Maestro RR module then test your installation. STEP 2 (Required for vehicles equipped with SYNC, without factory navigation system;...
Page 53
CONTROL CABLE PASSENGER SIDE, NEXT TO GLOVE BOX CONNECTION REQUIRED ONLY IF EQUIPPED WITH SYNC STEP 3 FACTORY RADIO HARNESS WIRES FROM VEHICLE STEP 5 MAESTRO RR MODULE HRR-FO1 T-HARNESS NOT REQUIRED DATA CABLE BACKUP CAM BACKUP CAM AUDIO CABLE Automotive Data Solutions Inc.
Page 57
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 58
Ford F-SerieS Super duty RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 59
Ford F-SerieS Super duty 2011-2016 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 65
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 66
NAV RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 67
Ford F150 with NAV 2009-2012 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 73
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 74
NAV RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 75
Ford F150 without NAV 2009-2010 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 76
STEP 5 Note: only connect purple/white wire to radio reverse input or module damage will occur. • Connect all the harnesses to the Maestro RR module then test your installation. STEP 2 (Required for vehicles equipped with SYNC, without factory navigation system;...
Page 77
SWI 2 : BLUE/ORANGE CONTROL CABLE CENTER DASH, UNDER THE TRAY CONNECTION REQUIRED ONLY IF EQUIPPED WITH SYNC STEP 3 FACTORY RADIO HARNESS WIRES FROM VEHICLE STEP 5 MAESTRO RR MODULE HRR-FO1 T-HARNESS NOT REQUIRED DATA CABLE BACKUP CAM BACKUP CAM AUDIO CABLE Automotive Data Solutions Inc.
Page 81
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 82
NAV RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 83
Ford F150 without NAV 2011-2014 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 89
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 90
Ford Five hundred RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 91
Ford Five hundred 2006-2007 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 97
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 98
NAV RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 99
Ford Flex with NAV 2009-2012 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 100
STEP 6 STEP 2 • Connect all the harnesses to the Maestro RR module then (Required for vehicles equipped with SYNC, without factory test your installation. navigation system; refer to Vehicle Wire Chart) •...
Page 105
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 106
NAV RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 107
Ford Flex without NAV 2009-2012 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 108
STEP 5 Note: only connect purple/white wire to radio reverse input or module damage will occur. • Connect all the harnesses to the Maestro RR module then test your installation. STEP 2 (Required for vehicles equipped with SYNC, without factory navigation system;...
Page 109
CENTER CONSOLE, JUNCTION CONNECTOR, IN FRONT OF THE SHIFTER CONNECTION REQUIRED ONLY IF EQUIPPED WITH SYNC STEP 3 FACTORY RADIO HARNESS WIRES FROM VEHICLE STEP 5 MAESTRO RR MODULE HRR-FO1 T-HARNESS NOT REQUIRED DATA CABLE BACKUP CAM BACKUP CAM AUDIO CABLE Automotive Data Solutions Inc.
Page 113
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 114
Ford Focus RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 115
Ford Focus 2008-2011 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 116
STEP 5 Note: only connect purple/white wire to radio reverse input or module damage will occur. • Connect all the harnesses to the Maestro RR module then test your installation. STEP 2 (Required for vehicles equipped with SYNC, without factory navigation system;...
Page 117
CONTROL CABLE CENTER CONSOLE, HORIZONTAL HARNESS ON THE HEATER BOX CONNECTION REQUIRED ONLY IF EQUIPPED WITH SYNC STEP 3 FACTORY RADIO HARNESS WIRES FROM VEHICLE STEP 5 MAESTRO RR MODULE HRR-FO1 T-HARNESS NOT REQUIRED DATA CABLE BACKUP CAM BACKUP CAM AUDIO CABLE Automotive Data Solutions Inc.
Page 121
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 122
Ford Fusion RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 123
Ford Fusion 2006-2009 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 124
STEP 5 Note: only connect purple/white wire to radio reverse input or module damage will occur. • Connect all the harnesses to the Maestro RR module then test your installation. STEP 2 (Required for vehicles equipped with SYNC, without factory navigation system;...
Page 125
CENTER CONSOLE, RIGHT SIDE, IN FRONT OF THE ARM REST CONNECTION REQUIRED ONLY IF EQUIPPED WITH SYNC STEP 3 FACTORY RADIO HARNESS WIRES FROM VEHICLE STEP 5 MAESTRO RR MODULE HRR-FO1 T-HARNESS NOT REQUIRED DATA CABLE BACKUP CAM BACKUP CAM...
Page 129
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 130
RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 131
Ford Fusion with nAV 2010-2012 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 132
STEP 6 STEP 2 • Connect all the harnesses to the Maestro RR module then (Required for vehicles equipped with SYNC, without factory test your installation. navigation system; refer to Vehicle Wire Chart) •...
Page 137
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 138
RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 139
Ford Fusion without nAV 2010-2012 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 140
STEP 5 Note: only connect purple/white wire to radio reverse input or module damage will occur. • Connect all the harnesses to the Maestro RR module then test your installation. STEP 2 (Required for vehicles equipped with SYNC, without factory navigation system;...
Page 141
CENTER CONSOLE, RIGHT SIDE, IN FRONT OF THE ARM REST CONNECTION REQUIRED ONLY IF EQUIPPED WITH SYNC STEP 3 FACTORY RADIO HARNESS WIRES FROM VEHICLE STEP 5 MAESTRO RR MODULE HRR-FO1 T-HARNESS NOT REQUIRED DATA CABLE BACKUP CAM BACKUP CAM...
Page 145
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 146
Ford Mustang RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 147
Ford Mustang 2007-2009 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 149
SWI 2 : BLUE/ORANGE OR BLUE SYNC UNIT, BEHIND THE GLOVE BOX CONNECTION REQUIRED ONLY IF EQUIPPED WITH SYNC STEP 3 FACTORY RADIO HARNESS WIRES FROM VEHICLE STEP 5 MAESTRO RR MODULE HRR-FO1 T-HARNESS NOT REQUIRED BACKUP CAM BACKUP CAM DATA CABLE SUB 1...
Page 153
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 154
Base RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 155
Ford Mustang Base 2013-2014 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 156
STEP 5 Note: only connect purple/white wire to radio reverse input or module damage will occur. • Connect all the harnesses to the Maestro RR module then test your installation. STEP 2 (Required for vehicles equipped with SYNC, without factory navigation system;...
Page 157
CONTROL CABLE SYNC UNIT, BEHIND THE GLOVE BOX CONNECTION REQUIRED ONLY IF EQUIPPED WITH SYNC STEP 3 FACTORY RADIO HARNESS WIRES FROM VEHICLE STEP 5 MAESTRO RR MODULE HRR-FO1 T-HARNESS NOT REQUIRED DATA CABLE BACKUP CAM BACKUP CAM AUDIO CABLE Automotive Data Solutions Inc.
Page 161
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 162
Pro RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER:...
Page 163
Ford Mustang with naV with shaker or shaker Pro 2010-2014 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 164
STEP 5 connector. • Connect the white and white/black wires to a RCA • Connect all the harnesses to the Maestro RR module then connector. Connect the gray and gray/black wires to a RCA test your installation. connector. Connect the green and green/black wires to a RCA connector.
Page 169
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 170
RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 171
Ford Mustang with naV without shaker 2010-2014 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 177
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 178
RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 179
Ford Mustang without naV 2010-2012 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 181
SWI 2 : BLUE/ORANGE OR BLUE SYNC UNIT, BEHIND THE GLOVE BOX CONNECTION REQUIRED ONLY IF EQUIPPED WITH SYNC STEP 3 FACTORY RADIO HARNESS WIRES FROM VEHICLE STEP 5 MAESTRO RR MODULE HRR-FO1 T-HARNESS NOT REQUIRED BACKUP CAM BACKUP CAM DATA CABLE SUB 1...
Page 185
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 186
Pro RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER:...
Page 187
Ford Mustang without naV with shaker or shaker Pro 2013-2014 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 188
• Cut and remove the black 20 pin connector from the HRR- FO1 T-harness and connect the wires, shown in the wiring • Connect all the harnesses to the Maestro RR module then diagram, from aftermarket radio main harness to the HRR- test your installation.
Page 189
SYNC UNIT, BEHIND THE GLOVE BOX CONNECTION REQUIRED ONLY IF EQUIPPED WITH SYNC STEERING WHEEL CONTROL CABLE STEP 3 WIRES FROM FACTORY RADIO HARNESS VEHICLE STEP 5 MAESTRO RR MODULE HRR-FO1 T-HARNESS NOT REQUIRED DATA CABLE BACKUP CAM BACKUP CAM AUDIO CABLE Automotive Data Solutions Inc.
Page 193
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 194
Ford Taurus RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 195
Ford Taurus 2008-2009 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 196
STEP 5 Note: only connect purple/white wire to radio reverse input or module damage will occur. • Connect all the harnesses to the Maestro RR module then test your installation. STEP 2 (Required for vehicles equipped with SYNC, without factory navigation system;...
Page 197
CENTER CONSOLE, RIGHT SIDE, HARNESS GOING TO THE BACK CONNECTION REQUIRED ONLY IF EQUIPPED WITH SYNC STEP 3 FACTORY RADIO HARNESS WIRES FROM VEHICLE STEP 5 MAESTRO RR MODULE HRR-FO1 T-HARNESS NOT REQUIRED DATA CABLE BACKUP CAM BACKUP CAM AUDIO CABLE Automotive Data Solutions Inc.
Page 201
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 202
Ford Taurus RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 203
Ford Taurus 2010-2012 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 204
STEP 5 Note: only connect purple/white wire to radio reverse input or module damage will occur. • Connect all the harnesses to the Maestro RR module then test your installation. STEP 2 (Required for vehicles equipped with SYNC, without factory navigation system;...
Page 205
CENTER CONSOLE, RIGHT SIDE, HARNESS GOING TO THE BACK CONNECTION REQUIRED ONLY IF EQUIPPED WITH SYNC STEP 3 FACTORY RADIO HARNESS WIRES FROM VEHICLE STEP 5 MAESTRO RR MODULE HRR-FO1 T-HARNESS NOT REQUIRED DATA CABLE BACKUP CAM BACKUP CAM AUDIO CABLE Automotive Data Solutions Inc.
Page 209
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 210
Ford Taurus X RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 211
Ford Taurus X 2008-2012 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 212
STEP 5 Note: only connect purple/white wire to radio reverse input or module damage will occur. • Connect all the harnesses to the Maestro RR module then test your installation. STEP 2 (Required for vehicles equipped with SYNC, without factory navigation system;...
Page 213
CENTER CONSOLE, RIGHT SIDE, HARNESS GOING TO THE BACK CONNECTION REQUIRED ONLY IF EQUIPPED WITH SYNC STEP 3 FACTORY RADIO HARNESS WIRES FROM VEHICLE STEP 5 MAESTRO RR MODULE HRR-FO1 T-HARNESS NOT REQUIRED DATA CABLE BACKUP CAM BACKUP CAM AUDIO CABLE Automotive Data Solutions Inc.
Page 217
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 218
LincoLn MKS RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 219
LincoLn MKS 2009-2012 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 220
STEP 5 Note: only connect purple/white wire to radio reverse input or module damage will occur. • Connect all the harnesses to the Maestro RR module then test your installation. STEP 2 (Required for vehicles equipped with SYNC, without factory navigation system;...
Page 221
CENTER CONSOLE, RIGHT SIDE, HARNESS GOING TO THE BACK CONNECTION REQUIRED ONLY IF EQUIPPED WITH SYNC STEP 3 FACTORY RADIO HARNESS WIRES FROM VEHICLE STEP 5 MAESTRO RR MODULE HRR-FO1 T-HARNESS NOT REQUIRED DATA CABLE BACKUP CAM BACKUP CAM AUDIO CABLE Automotive Data Solutions Inc.
Page 225
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 226
LincoLn MKT RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 227
LincoLn MKT 2010-2012 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 228
STEP 5 Note: only connect purple/white wire to radio reverse input or module damage will occur. • Connect all the harnesses to the Maestro RR module then test your installation. STEP 2 (Required for vehicles equipped with SYNC, without factory navigation system;...
Page 229
CENTER CONSOLE, RIGHT SIDE, HARNESS GOING TO THE BACK CONNECTION REQUIRED ONLY IF EQUIPPED WITH SYNC STEP 3 FACTORY RADIO HARNESS WIRES FROM VEHICLE STEP 5 MAESTRO RR MODULE HRR-FO1 T-HARNESS NOT REQUIRED DATA CABLE BACKUP CAM BACKUP CAM AUDIO CABLE Automotive Data Solutions Inc.
Page 233
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 234
LincoLn MKX RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 235
LincoLn MKX 2007-2010 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 236
STEP 5 Note: only connect purple/white wire to radio reverse input or module damage will occur. • Connect all the harnesses to the Maestro RR module then test your installation. STEP 2 (Required for vehicles equipped with SYNC, without factory navigation system;...
Page 237
CENTER CONSOLE, RIGHT SIDE, HARNESS GOING TO THE BACK CONNECTION REQUIRED ONLY IF EQUIPPED WITH SYNC STEP 3 FACTORY RADIO HARNESS WIRES FROM VEHICLE STEP 5 MAESTRO RR MODULE HRR-FO1 T-HARNESS NOT REQUIRED DATA CABLE BACKUP CAM BACKUP CAM AUDIO CABLE Automotive Data Solutions Inc.
Page 241
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 242
LincoLn MKZ RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 243
LincoLn MKZ 2007-2012 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 244
STEP 5 Note: only connect purple/white wire to radio reverse input or module damage will occur. • Connect all the harnesses to the Maestro RR module then test your installation. STEP 2 (Required for vehicles equipped with SYNC, without factory navigation system;...
Page 245
CENTER CONSOLE, RIGHT SIDE, HARNESS GOING TO THE BACK CONNECTION REQUIRED ONLY IF EQUIPPED WITH SYNC STEP 3 FACTORY RADIO HARNESS WIRES FROM VEHICLE STEP 5 MAESTRO RR MODULE HRR-FO1 T-HARNESS NOT REQUIRED DATA CABLE BACKUP CAM BACKUP CAM AUDIO CABLE Automotive Data Solutions Inc.
Page 249
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 250
RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 251
LincoLn Mark LT wiTh naV 2010-2011 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 252
STEP 6 STEP 2 • Connect all the harnesses to the Maestro RR module then (Required for vehicles equipped with SYNC, without factory test your installation. navigation system; refer to Vehicle Wire Chart) •...
Page 257
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 258
LincoLn navigator RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 259
LincoLn navigator 2007-2014 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 260
STEP 5 Note: only connect purple/white wire to radio reverse input or module damage will occur. • Connect all the harnesses to the Maestro RR module then test your installation. STEP 2 (Required for vehicles equipped with SYNC, without factory navigation system;...
Page 261
SWI 2 : BLUE/ORANGE CONTROL CABLE SYNC UNIT, CENTER CONSOLE CONNECTION REQUIRED ONLY IF EQUIPPED WITH SYNC STEP 3 FACTORY RADIO HARNESS WIRES FROM VEHICLE STEP 5 MAESTRO RR MODULE HRR-FO1 T-HARNESS NOT REQUIRED DATA CABLE BACKUP CAM BACKUP CAM AUDIO CABLE Automotive Data Solutions Inc.
Page 265
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 266
LincoLn Zephyr RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 267
LincoLn Zephyr 2006 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 273
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 274
Mazda TribuTe RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 275
Mazda TribuTe 2008-2011 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 281
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 282
Mercury Mariner RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 283
Mercury Mariner 2008-2011 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 284
STEP 5 Note: only connect purple/white wire to radio reverse input or module damage will occur. • Connect all the harnesses to the Maestro RR module then test your installation. STEP 2 (Required for vehicles equipped with SYNC, without factory navigation system;...
Page 285
CONTROL CABLE JUNCTION CONNECTOR, BEHIND THE RADIO TO THE RIGHT CONNECTION REQUIRED ONLY IF EQUIPPED WITH SYNC STEP 3 FACTORY RADIO HARNESS WIRES FROM VEHICLE STEP 5 MAESTRO RR MODULE HRR-FO1 T-HARNESS NOT REQUIRED DATA CABLE BACKUP CAM BACKUP CAM AUDIO CABLE Automotive Data Solutions Inc.
Page 289
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 290
Mercury Milan RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 291
Mercury Milan 2006-2011 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 292
STEP 5 Note: only connect purple/white wire to radio reverse input or module damage will occur. • Connect all the harnesses to the Maestro RR module then test your installation. STEP 2 (Required for vehicles equipped with SYNC, without factory navigation system;...
Page 293
CENTER CONSOLE, RIGHT SIDE, IN FRONT OF ARM REST CONNECTION REQUIRED ONLY IF EQUIPPED WITH SYNC STEP 3 FACTORY RADIO HARNESS WIRES FROM VEHICLE STEP 5 MAESTRO RR MODULE HRR-FO1 T-HARNESS NOT REQUIRED DATA CABLE BACKUP CAM BACKUP CAM AUDIO CABLE Automotive Data Solutions Inc.
Page 297
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 298
Mercury Montego RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 299
Mercury Montego 2005-2007 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 305
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 306
Mercury Mountaineer RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 307
Mercury Mountaineer 2006-2010 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 308
STEP 5 Note: only connect purple/white wire to radio reverse input or module damage will occur. • Connect all the harnesses to the Maestro RR module then test your installation. STEP 2 (Required for vehicles equipped with SYNC, without factory navigation system;...
Page 309
CONNECTION REQUIRED ONLY IF EQUIPPED WITH SYNC STEP 3 FACTORY RADIO HARNESS WIRES FROM VEHICLE SWI 2 : WHITE/BROWN CENTER CONSOLE, HARNESS GOING TO THE BACK STEP 5 MAESTRO RR MODULE HRR-FO1 T-HARNESS NOT REQUIRED DATA CABLE BACKUP CAM BACKUP CAM AUDIO CABLE Automotive Data Solutions Inc.
Page 313
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 314
Mercury Sable RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER CONTROL, ANALOG OUTPUTS AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface iDatalink Maestro HRR-FO1 Installation Harness PROGRAMMED FIRMWARE ADS-RR(SR)-FOR01-AS HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 315
Mercury Sable 2008-2009 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 316
STEP 5 Note: only connect purple/white wire to radio reverse input or module damage will occur. • Connect all the harnesses to the Maestro RR module then test your installation. STEP 2 (Required for vehicles equipped with SYNC, without factory navigation system;...
Page 317
CONNECTION REQUIRED ONLY IF EQUIPPED WITH SYNC STEP 3 FACTORY RADIO HARNESS WIRES FROM VEHICLE SWI 2 : GRAY/BLUE CENTER CONSOLE, RIGHT SIDE, HARNESS GOING TO THE BACK STEP 5 MAESTRO RR MODULE HRR-FO1 T-HARNESS NOT REQUIRED DATA CABLE BACKUP CAM BACKUP CAM AUDIO CABLE Automotive Data Solutions Inc.
Page 321
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Need help?
Do you have a question about the Maestro Rr and is the answer not in the manual?
Questions and answers
