Summary of Contents for iDataLink Maestro RR

Page 1 Print only the pages for your vehicle using the advanced options in the Print menu. Install your Maestro RR according to the guide for your vehicle. WARNING Pressing the printer icon or “quick printing” this document will print all of the guides in this compilation.
Page 2 RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER, AND MORE! HEAD UNIT ADAPTER READY PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MFT1 Dash Kit Radar Installation Guides E L E C T R O N I C S...
Page 3 Ford EdgE with MyFord touch 2011-2013 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 4 OEM screen. (Fig. 1.4 ) Fig. 1.3 Fig. 1.4 Keep screws and brackets for MFT1 dash kit assembly. Unbox MFT1 dash kit and locate bracket set #1, discard set #2. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 5 • Plug the data cable to the data port of the aftermarket radio. • Insert the audio cable into the iDatalink 3.5mm audio jack of the aftermarket radio (labeled iDatalink. If there is no iDatalink audio input, connect to AUX).
Page 6 BLACK BLACK WHITE STEP 3 WIRES FROM VEHICLE FACTORY RADIO HARNESS HARNESS BEHIND RADIO STEP 4 MAESTRO RR MODULE IF PRESENT AMP TURNON AMP TURNON RR-MFT1 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN...
Page 7 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 8 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 9 Ensure the 4-pin data cable is connected between the radio and the RR, and RED TWICE that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty. Make sure the correct radio model and serial number were entered during the fl ash.
Page 10 RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER, AND MORE! HEAD UNIT ADAPTER READY PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MFT1 Dash Kit Radar Installation Guides E L E C T R O N I C S...
Page 11 Ford EdgE with MyFord touch 2014-2019 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 12 8. Cut and remove the plastic behind the screen. (Fig. 1.7 ) Fig. 1.5 Fig. 1.6 Keep screws and brackets fot MFT1 dash kit assembly. Unbox MFT1 dash kit and locate bracket set #1, discard set #2. Fig. 1.7 Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 13 • Plug the data cable to the data port of the aftermarket radio. • Insert the audio cable into the iDatalink 3.5mm audio jack of the aftermarket radio (labeled iDatalink. If there is no iDatalink audio input, connect to AUX).
Page 14 BLACK BLACK WHITE STEP 3 WIRES FROM VEHICLE FACTORY RADIO HARNESS HARNESS BEHIND RADIO STEP 4 MAESTRO RR MODULE IF PRESENT AMP TURNON AMP TURNON RR-MFT1 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN...
Page 15 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 16 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 17 Ensure the 4-pin data cable is connected between the radio and the RR, and RED TWICE that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty. Make sure the correct radio model and serial number were entered during the fl ash.
Page 18 RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER, AND MORE! HEAD UNIT ADAPTER READY PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MFT1 Dash Kit Radar Installation Guides E L E C T R O N I C S...
Page 19 Ford EscapE with MyFord touch with sony aMp 2013-2016 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 20 (Fig. 1.7) Keep screws and brackets for MFT1 dash kit assembly. Unbox MFT1 dash kit and locate bracket set #1, discard set #2. Fig. 1.5 Fig. 1.6 Fig. 1.7 Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 21 A, B and D harnesses. • Connect the MFT1 T-harness to the factory radio harness. 4. Connect all harnesses to the Maestro RR module. 5. Plug the harnesses into the aftermarket radio. • Plug the data cable to the data port of the aftermarket radio.
Page 22 CONNECT IF EQUIPPED * UNPLUG BLACK WHITE STEP 3 WIRES FROM VEHICLE FACTORY RADIO HARNESS HARNESS BEHIND RADIO STEP 4 MAESTRO RR MODULE IF PRESENT AMP TURNON AMP TURNON RR-MFT1 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 23 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 24 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 25 Ensure the 4-pin data cable is connected between the radio and the RR, and RED TWICE that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty. Make sure the correct radio model and serial number were entered during the fl ash.
Page 26 RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER, AND MORE! HEAD UNIT ADAPTER READY PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MFT1 Dash Kit Radar Installation Guides E L E C T R O N I C S...
Page 27 Ford EscapE with MyFord touch without aMp 2013-2019 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 28 (Fig. 1.7) Keep screws and brackets for MFT1 dash kit assembly. Unbox MFT1 dash kit and locate bracket set #1, discard set #2. Fig. 1.5 Fig. 1.6 Fig. 1.7 Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 29 • Plug the data cable to the data port of the aftermarket radio. • Insert the audio cable into the iDatalink 3.5mm audio jack of the aftermarket radio (labeled iDatalink. If there is no iDatalink audio input, connect to AUX).
Page 30 CONNECT IF EQUIPPED * FACTORY RADIO HARNESS WHITE BLACK WIRES FROM VEHICLE HARNESS BEHIND RADIO STEP 3 MAESTRO RR MODULE IF PRESENT AMP TURNON AMP TURNON RR-MFT1 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 31 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 32 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 33 Ensure the 4-pin data cable is connected between the radio and the RR, and RED TWICE that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty. Make sure the correct radio model and serial number were entered during the fl ash.
Page 34 RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER, AND MORE! HEAD UNIT ADAPTER READY PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MFT1 Dash Kit Radar Installation Guides E L E C T R O N I C S...
Page 35 Ford ExpEdition with MyFord touch 2015-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 36 Fig. 1.3 Fig. 1.4 tws and brackets for MFT1 dash kit assembly. Unbox MFT1 dash kit and locate bracket set #2, discard set #1. Fig. 1.5 Fig. 1.6 Fig. 1.7 Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 37 • Plug the data cable to the data port of the aftermarket radio. • Insert the audio cable into the iDatalink 3.5mm audio jack of the aftermarket radio (labeled iDatalink. If there is no iDatalink audio input, connect to AUX).
Page 38 BLACK BLACK WHITE STEP 3 WIRES FROM VEHICLE FACTORY RADIO HARNESS HARNESS BEHIND RADIO STEP 4 MAESTRO RR MODULE IF PRESENT AMP TURNON AMP TURNON RR-MFT1 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN...
Page 39 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 40 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 41 Ensure the 4-pin data cable is connected between the radio and the RR, and RED TWICE that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty. Make sure the correct radio model and serial number were entered during the fl ash.
Page 42 RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER, AND MORE! HEAD UNIT ADAPTER READY PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MFT1 Dash Kit Radar Installation Guides E L E C T R O N I C S...
Page 43 Ford ExpEdition with MyFord touch without aMp 2018-2019 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 44 Fig. 1.3 Fig. 1.4 Keep screws and brackets for MFT1 dash kit assembly. Unbox MFT1 dash kit and locate bracket set #2, discard set #1. Fig. 1.5 Fig. 1.6 Fig. 1.7 Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 45 • Plug the data cable to the data port of the aftermarket radio. • Insert the audio cable into the iDatalink 3.5mm audio jack of the aftermarket radio (labeled iDatalink. If there is no iDatalink audio input, connect to AUX).
Page 46 CONNECT IF EQUIPPED * FACTORY RADIO HARNESS WHITE BLACK WIRES FROM VEHICLE HARNESS BEHIND RADIO STEP 3 MAESTRO RR MODULE IF PRESENT AMP TURNON AMP TURNON RR-MFT1 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 47 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 48 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 49 Ensure the 4-pin data cable is connected between the radio and the RR, and RED TWICE that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty. Make sure the correct radio model and serial number were entered during the fl ash.
Page 50 RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER, AND MORE! HEAD UNIT ADAPTER READY PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MFT1 Dash Kit Radar Installation Guides E L E C T R O N I C S...
Page 51 Ford ExplorEr with MyFord touch 2011-2015 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 52 7. Cut or bend metal bracket (if required). (Fig. 1.7) Keep screws and brackets for MFT1 dash kit assembly. Unbox MFT1 dash kit and locate bracket set #1, discard set #2. Fig. 1.5 Fig. 1.6 Fig. 1.7 Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 53 • Plug the data cable to the data port of the aftermarket radio. • Insert the audio cable into the iDatalink 3.5mm audio jack of the aftermarket radio (labeled iDatalink. If there is no iDatalink audio input, connect to AUX).
Page 54 BLACK BLACK WHITE STEP 3 WIRES FROM VEHICLE FACTORY RADIO HARNESS HARNESS BEHIND RADIO STEP 4 MAESTRO RR MODULE IF PRESENT AMP TURNON AMP TURNON RR-MFT1 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN...
Page 55 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 56 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 57 Ensure the 4-pin data cable is connected between the radio and the RR, and RED TWICE that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty. Make sure the correct radio model and serial number were entered during the fl ash.
Page 58 RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER, AND MORE! HEAD UNIT ADAPTER READY PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MFT1 Dash Kit Radar Installation Guides E L E C T R O N I C S...
Page 59 Ford ExplorEr with MyFord touch 2016-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 60 7. Cut or bend metal bracket (if required). (Fig. 1.7) Keep screws and brackets for MFT1 dash kit assembly. Unbox MFT1 dash kit and locate bracket set #1, discard set #2. Fig. 1.5 Fig. 1.6 Fig. 1.7 Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 61 • Plug the data cable to the data port of the aftermarket radio. • Insert the audio cable into the iDatalink 3.5mm audio jack of the aftermarket radio (labeled iDatalink. If there is no iDatalink audio input, connect to AUX).
Page 62 BLACK BLACK WHITE STEP 3 WIRES FROM VEHICLE FACTORY RADIO HARNESS HARNESS BEHIND RADIO STEP 4 MAESTRO RR MODULE IF PRESENT AMP TURNON AMP TURNON RR-MFT1 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN...
Page 63 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 64 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 65 Ensure the 4-pin data cable is connected between the radio and the RR, and RED TWICE that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty. Make sure the correct radio model and serial number were entered during the fl ash.
Page 66 RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER, AND MORE! HEAD UNIT ADAPTER READY PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MFT1 Dash Kit Radar Installation Guides E L E C T R O N I C S...
Page 67 Ford ExplorEr with MyFord touch without aMp 2018-2019 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 68 7. Cut or bend metal bracket (if required). (Fig. 1.7) Keep screws and brackets for MFT1 dash kit assembly. Unbox MFT1 dash kit and locate bracket set #1, discard set #2. Fig. 1.5 Fig. 1.6 Fig. 1.7 Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 69 • Plug the data cable to the data port of the aftermarket radio. • Insert the audio cable into the iDatalink 3.5mm audio jack of the aftermarket radio (labeled iDatalink. If there is no iDatalink audio input, connect to AUX).
Page 70 CONNECT IF EQUIPPED * FACTORY RADIO HARNESS WHITE BLACK WIRES FROM VEHICLE HARNESS BEHIND RADIO STEP 3 MAESTRO RR MODULE IF PRESENT AMP TURNON AMP TURNON RR-MFT1 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 71 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 72 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 73 Ensure the 4-pin data cable is connected between the radio and the RR, and RED TWICE that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty. Make sure the correct radio model and serial number were entered during the fl ash.
Page 74 RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER, AND MORE! HEAD UNIT ADAPTER READY PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MFT1 Dash Kit Radar Installation Guides E L E C T R O N I C S...
Page 75 Ford F Super duty with MyFord touch 2013-2016 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 76 7. Cut and remove the metal brace at the top of the radio cavity. (Fig.1.5) Keep screws and brackets for MFT1 dash kit assembly. Unbox MFT1 dash kit and locate bracket set #1, discard set #2. Fig. 1.5 Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 77 • Plug the data cable to the data port of the aftermarket radio. • Insert the audio cable into the iDatalink 3.5mm audio jack of the aftermarket radio (labeled iDatalink. If there is no iDatalink audio input, connect to AUX).
Page 78 BLACK BLACK WHITE STEP 3 WIRES FROM VEHICLE FACTORY RADIO HARNESS HARNESS BEHIND RADIO STEP 4 MAESTRO RR MODULE IF PRESENT AMP TURNON AMP TURNON RR-MFT1 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN...
Page 79 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 80 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 81 Ensure the 4-pin data cable is connected between the radio and the RR, and RED TWICE that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty. Make sure the correct radio model and serial number were entered during the fl ash.
Page 82 RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER, AND MORE! HEAD UNIT ADAPTER READY PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MFT1 Dash Kit Radar Installation Guides E L E C T R O N I C S...
Page 83 Ford F Super duty with MyFord touch 2017-2019 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 84 Note: the bracket may be cut but this will prevent reinstalling OEM equipment. Keep screws and brackets for MFT1 dash kit assembly. Fig. 4.0 Fig. 5.0 Unbox MFT1 dash kit and locate bracket set #2, discard set #1. Fig. 5.1 Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 85 • Plug the data cable to the data port of the aftermarket radio. • Insert the audio cable into the iDatalink 3.5mm audio jack of the aftermarket radio (labeled iDatalink. If there is no iDatalink audio input, connect to AUX).
Page 86 BLACK BLACK WHITE STEP 3 WIRES FROM VEHICLE FACTORY RADIO HARNESS HARNESS BEHIND RADIO STEP 4 MAESTRO RR MODULE IF PRESENT AMP TURNON AMP TURNON RR-MFT1 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN...
Page 87 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 88 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 89 Ensure the 4-pin data cable is connected between the radio and the RR, and RED TWICE that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty. Make sure the correct radio model and serial number were entered during the fl ash.
Page 90 RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER, AND MORE! HEAD UNIT ADAPTER READY PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MFT1 Dash Kit Radar Installation Guides E L E C T R O N I C S...
Page 91 Ford F Super duty with MyFord touch without aMp 2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 92 Note: the bracket may be cut but this will prevent reinstalling OEM equipment. Keep screws and brackets for MFT1 dash kit assembly. Fig. 4.0 Fig. 5.0 Unbox MFT1 dash kit and locate bracket set #2, discard set #1. Fig. 5.1 Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 93 • Plug the data cable to the data port of the aftermarket radio. • Insert the audio cable into the iDatalink 3.5mm audio jack of the aftermarket radio (labeled iDatalink. If there is no iDatalink audio input, connect to AUX).
Page 94 CONNECT IF EQUIPPED * FACTORY RADIO HARNESS WHITE BLACK WIRES FROM VEHICLE HARNESS BEHIND RADIO STEP 3 MAESTRO RR MODULE IF PRESENT AMP TURNON AMP TURNON RR-MFT1 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 95 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 96 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 97 Ensure the 4-pin data cable is connected between the radio and the RR, and RED TWICE that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty. Make sure the correct radio model and serial number were entered during the fl ash.
Page 98 RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER, AND MORE! HEAD UNIT ADAPTER READY PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MFT1 Dash Kit Radar Installation Guides E L E C T R O N I C S...
Page 99 Ford F Super duty with MyFord touch without aMp 2021 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 100 Note: the bracket may be cut but this will prevent Fig. 4.0 Fig. 5.0 reinstalling OEM equipment. Keep screws and brackets for MFT1 dash kit assembly. Unbox MFT1 dash kit and locate bracket set #2, discard set #1. Fig. 5.1 Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 101 • Plug the data cable to the data port of the aftermarket radio. • Insert the audio cable into the iDatalink 3.5mm audio jack of the aftermarket radio (labeled iDatalink. If there is no iDatalink audio input, connect to AUX).
Page 102 BRANCHER SI PRÉSENT* CONNECT IF EQUIPPED * FACTORY RADIO HARNESS WHITE BLACK WIRES FROM VEHICLE HARNESS BEHIND RADIO STEP 3 MAESTRO RR MODULE AMP TURNON AMP TURNON RR-MFT1 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN...
Page 103 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 104 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 105 Ensure the 4-pin data cable is connected between the radio and the RR, and RED TWICE that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty. Make sure the correct radio model and serial number were entered during the fl ash.
Page 106 RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER, AND MORE! HEAD UNIT ADAPTER READY PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MFT1 Dash Kit Radar Installation Guides E L E C T R O N I C S...
Page 107 Ford F-150 with MyFord touch 2013-2014 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 108 OEM screen. (1.8) Fig. 1.5 Fig. 1.6 Keep screws and brackets for MFT1 dash kit assembly. Unbox MFT1 dash kit and locate bracket set #1, discard set #2. Fig. 1.8 Fig. 1.7 Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 109 • Plug the data cable to the data port of the aftermarket radio. • Insert the audio cable into the iDatalink 3.5mm audio jack of the aftermarket radio (labeled iDatalink. If there is no iDatalink audio input, connect to AUX).
Page 110 BLACK BLACK WHITE STEP 3 WIRES FROM VEHICLE FACTORY RADIO HARNESS HARNESS BEHIND RADIO STEP 4 MAESTRO RR MODULE IF PRESENT AMP TURNON AMP TURNON RR-MFT1 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN...
Page 111 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 112 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 113 Ensure the 4-pin data cable is connected between the radio and the RR, and RED TWICE that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty. Make sure the correct radio model and serial number were entered during the fl ash.
Page 114 RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER, AND MORE! HEAD UNIT ADAPTER READY PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MFT1 Dash Kit Radar Installation Guides E L E C T R O N I C S...
Page 115 Ford F-150 with MyFord touch 2015-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 116 Note: the bracket may be cut but this will prevent reinstalling OEM equipment. Keep screws and brackets for MFT1 dash kit assembly. Fig. 4.0 Fig. 5.0 Unbox MFT1 dash kit and locate bracket set #2, discard set #1. Fig. 5.1 Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 117 • Plug the data cable to the data port of the aftermarket radio. • Insert the audio cable into the iDatalink 3.5mm audio jack of the aftermarket radio (labeled iDatalink. If there is no iDatalink audio input, connect to AUX).
Page 118 BLACK BLACK WHITE STEP 3 WIRES FROM VEHICLE FACTORY RADIO HARNESS HARNESS BEHIND RADIO STEP 4 MAESTRO RR MODULE IF PRESENT AMP TURNON AMP TURNON RR-MFT1 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN...
Page 119 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 120 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 121 Ensure the 4-pin data cable is connected between the radio and the RR, and RED TWICE that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty. Make sure the correct radio model and serial number were entered during the fl ash.
Page 122 RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER, AND MORE! HEAD UNIT ADAPTER READY PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MFT1 Dash Kit Radar Installation Guides E L E C T R O N I C S...
Page 123 Ford F-150 with MyFord touch without aMp 2018-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 124 Note: the bracket may be cut but this will prevent reinstalling OEM equipment. Keep screws and brackets for MFT1 dash kit assembly. Fig. 4.0 Fig. 5.0 Unbox MFT1 dash kit and locate bracket set #2, discard set #1. Fig. 5.1 Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 125 • Plug the data cable to the data port of the aftermarket radio. • Insert the audio cable into the iDatalink 3.5mm audio jack of the aftermarket radio (labeled iDatalink. If there is no iDatalink audio input, connect to AUX).
Page 126 CONNECT IF EQUIPPED * FACTORY RADIO HARNESS WHITE BLACK WIRES FROM VEHICLE HARNESS BEHIND RADIO STEP 3 MAESTRO RR MODULE IF PRESENT AMP TURNON AMP TURNON RR-MFT1 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 127 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 128 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 129 Ensure the 4-pin data cable is connected between the radio and the RR, and RED TWICE that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty. Make sure the correct radio model and serial number were entered during the fl ash.
Page 130 RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER, AND MORE! HEAD UNIT ADAPTER READY PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MFT1 Dash Kit Radar Installation Guides E L E C T R O N I C S...
Page 131 Ford Flex with MyFord touch 2013-2019 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 132 Fig. 1.3 Fig. 1.4 Keep screws and brackets for MFT1 dash kit assembly. Unbox MFT1 dash kit and locate bracket set #1, discard set #2. Fig. 1.5 Fig. 1.6 Fig. 1.7 Fig. 1.8 Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 133 • Plug the data cable to the data port of the aftermarket radio. • Insert the audio cable into the iDatalink 3.5mm audio jack of the aftermarket radio (labeled iDatalink. If there is no iDatalink audio input, connect to AUX).
Page 134 BLACK BLACK WHITE STEP 3 WIRES FROM VEHICLE FACTORY RADIO HARNESS HARNESS BEHIND RADIO STEP 4 MAESTRO RR MODULE IF PRESENT AMP TURNON AMP TURNON RR-MFT1 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN...
Page 135 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 136 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 137 Ensure the 4-pin data cable is connected between the radio and the RR, and RED TWICE that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty. Make sure the correct radio model and serial number were entered during the fl ash.
Page 138 RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER, AND MORE! HEAD UNIT ADAPTER READY PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MFT1 Dash Kit Radar Installation Guides E L E C T R O N I C S...
Page 139 Ford Fusion with MyFord touch 2013-2016 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 140 8. Trim the plastic behind the OEM screen. (Fig. 1.7) Keep screws and brackets for MFT1 dash kit assembly. Unbox MFT1 dash kit and locate bracket set #2, discard set #1. Fig. 1.5 Fig. 1.6 Fig. 1.7 Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 141 • Plug the data cable to the data port of the aftermarket radio. • Insert the audio cable into the iDatalink 3.5mm audio jack of the aftermarket radio (labeled iDatalink. If there is no iDatalink audio input, connect to AUX).
Page 142 BLACK BLACK WHITE STEP 3 WIRES FROM VEHICLE FACTORY RADIO HARNESS HARNESS BEHIND RADIO STEP 4 MAESTRO RR MODULE IF PRESENT AMP TURNON AMP TURNON RR-MFT1 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN...
Page 143 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 144 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 145 Ensure the 4-pin data cable is connected between the radio and the RR, and RED TWICE that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty. Make sure the correct radio model and serial number were entered during the fl ash.
Page 146 RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER, AND MORE! HEAD UNIT ADAPTER READY PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MFT1 Dash Kit Radar Installation Guides E L E C T R O N I C S...
Page 147 Ford Fusion with MyFord touch without aMp 2017-2019 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 148 8. Trim the plastic behind the OEM screen. (Fig. 1.7) Keep screws and brackets for MFT1 dash kit assembly. Unbox MFT1 dash kit and locate bracket set #2, discard set #1. Fig. 1.5 Fig. 1.6 Fig. 1.7 Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 149 • Plug the data cable to the data port of the aftermarket radio. • Insert the audio cable into the iDatalink 3.5mm audio jack of the aftermarket radio (labeled iDatalink. If there is no iDatalink audio input, connect to AUX).
Page 150 CONNECT IF EQUIPPED * FACTORY RADIO HARNESS WHITE BLACK WIRES FROM VEHICLE HARNESS BEHIND RADIO STEP 3 MAESTRO RR MODULE IF PRESENT AMP TURNON AMP TURNON RR-MFT1 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 151 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 152 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 153 Ensure the 4-pin data cable is connected between the radio and the RR, and RED TWICE that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty. Make sure the correct radio model and serial number were entered during the fl ash.
Page 154 RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER, AND MORE! HEAD UNIT ADAPTER READY PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MFT1 Dash Kit Radar Installation Guides E L E C T R O N I C S...
Page 155 Ford Mustang with MyFord touch with B&o aMp 2019 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 156 11. Cut and remove back panel in radio cavity behind the screen. (Fig. 1.9) Unbox MFT1 dash kit and locate bracket set #2, discard set #1. Fig. 1.6 Fig. 1.7 Fig. 1.1 Fig. 1.8 Fig. 1.9 Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 157 • Plug the white and gray RCAs into the aftermarket radio. • Plug the backup camera RCA into the aftermarket radio (if applicable). • Insert the audio cable into the iDatalink 3.5mm audio jack of the aftermarket radio (labeled iDatalink. If there is no iDatalink audio input, connect to AUX).
Page 158 UNPLUG BLACK WHITE STEP 3 WIRES FROM VEHICLE FACTORY RADIO HARNESS HARNESS BEHIND RADIO STEP 4 MAESTRO RR MODULE IF PRESENT AMP TURNON AMP TURNON RR-MFT1 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN...
Page 159 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 160 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 161 Ensure the 4-pin data cable is connected between the radio and the RR, and RED TWICE that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty. Make sure the correct radio model and serial number were entered during the fl ash.
Page 162 RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER, AND MORE! HEAD UNIT ADAPTER READY PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MFT1 Dash Kit Radar Installation Guides E L E C T R O N I C S...
Page 163 Ford Mustang with MyFord touch with shaker aMp 2015-2019 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 164 11. Cut and remove back panel in radio cavity behind the screen. (Fig. 1.9) Unbox MFT1 dash kit and locate bracket set #2, discard set #1. Fig. 1.6 Fig. 1.7 Fig. 1.1 Fig. 1.8 Fig. 1.9 Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 165 • Plug the 4 speaker RCAs into the aftermarket radio. • Plug the backup camera RCA into the aftermarket radio (if applicable). • Insert the audio cable into the iDatalink 3.5mm audio jack of the aftermarket radio (labeled iDatalink. If there is no iDatalink audio input, connect to AUX).
Page 166 CUT AND DISCARD WHITE STEP 3 WIRES FROM VEHICLE FACTORY RADIO HARNESS HARNESS BEHIND RADIO STEP 4 MAESTRO RR MODULE IF PRESENT AMP TURNON AMP TURNON RR-MFT1 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 167 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 168 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 169 Ensure the 4-pin data cable is connected between the radio and the RR, and RED TWICE that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty. Make sure the correct radio model and serial number were entered during the fl ash.
Page 170 RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER, AND MORE! HEAD UNIT ADAPTER READY PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MFT1 Dash Kit Radar Installation Guides E L E C T R O N I C S...
Page 171 Ford Mustang with MyFord touch without aMp 2015-2019 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 172 11. Cut and remove back panel in radio cavity behind the screen. (Fig. 1.9) Unbox MFT1 dash kit and locate bracket set #2, discard set #1. Fig. 1.6 Fig. 1.7 Fig. 1.1 Fig. 1.8 Fig. 1.9 Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 173 • Plug the data cable to the data port of the aftermarket radio. • Insert the audio cable into the iDatalink 3.5mm audio jack of the aftermarket radio (labeled iDatalink. If there is no iDatalink audio input, connect to AUX).
Page 174 CONNECT IF EQUIPPED * FACTORY RADIO HARNESS WHITE BLACK WIRES FROM VEHICLE HARNESS BEHIND RADIO STEP 3 MAESTRO RR MODULE IF PRESENT AMP TURNON AMP TURNON RR-MFT1 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 175 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 176 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 177 Ensure the 4-pin data cable is connected between the radio and the RR, and RED TWICE that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty. Make sure the correct radio model and serial number were entered during the fl ash.
Page 178 RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER, AND MORE! HEAD UNIT ADAPTER READY PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MFT1 Dash Kit Radar Installation Guides E L E C T R O N I C S...
Page 179 Ford ranger with MyFord touch without aMp 2019-2021 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 180 Fig. 1.3 Fig. 1.4 Keep screws and brackets for MFT1 dash kit assembly. Unbox MFT1 dash kit and locate bracket set #2, discard set #1. Fig. 1.5 Fig. 1.6 Fig. 1.7 Fig. 1.8 Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 181 • Plug the data cable to the data port of the aftermarket radio. • Insert the audio cable into the iDatalink 3.5mm audio jack of the aftermarket radio (labeled iDatalink. If there is no iDatalink audio input, connect to AUX).
Page 182 CONNECT IF EQUIPPED * FACTORY RADIO HARNESS WHITE BLACK WIRES FROM VEHICLE HARNESS BEHIND RADIO STEP 3 MAESTRO RR MODULE IF PRESENT AMP TURNON AMP TURNON RR-MFT1 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 183 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 184 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 185 Ensure the 4-pin data cable is connected between the radio and the RR, and RED TWICE that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty. Make sure the correct radio model and serial number were entered during the fl ash.
Page 186 RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER, AND MORE! HEAD UNIT ADAPTER READY PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MFT1 Dash Kit Radar Installation Guides E L E C T R O N I C S...
Page 187 Ford Taurus wiTh MyFord Touch 2013-2019 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 188 Remove the screen. (Fig. 1.8) 13. Remove four (4) 7mm screws holding the OEM radio. Remove the radio. (Fig. 1.8) Unbox MFT1 dash kit and locate bracket set #1, discard Fig. 1.7 Fig. 1.8 set #2. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 189 • Plug the data cable to the data port of the aftermarket radio. • Insert the audio cable into the iDatalink 3.5mm audio jack of the aftermarket radio (labeled iDatalink. If there is no iDatalink audio input, connect to AUX).
Page 190 BLACK BLACK WHITE STEP 3 WIRES FROM VEHICLE FACTORY RADIO HARNESS HARNESS BEHIND RADIO STEP 4 MAESTRO RR MODULE IF PRESENT AMP TURNON AMP TURNON RR-MFT1 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN...
Page 191 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 192 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 193 Ensure the 4-pin data cable is connected between the radio and the RR, and RED TWICE that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty. Make sure the correct radio model and serial number were entered during the fl ash.
Page 194 RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER, AND MORE! HEAD UNIT ADAPTER READY PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MFT1 Dash Kit Radar Installation Guides E L E C T R O N I C S...
Page 195 LincoLn MKX with MyLincoLn touch 2011-2013 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 196 OEM screen. (Fig. 1.4 ) Fig. 1.3 Fig. 1.4 Keep screws and brackets for MFT1 dash kit assembly. Unbox MFT1 dash kit and locate bracket set #1, discard set #2. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 197 • Plug the data cable to the data port of the aftermarket radio. • Insert the audio cable into the iDatalink 3.5mm audio jack of the aftermarket radio (labeled iDatalink. If there is no iDatalink audio input, connect to AUX).
Page 198 BLACK BLACK WHITE STEP 3 WIRES FROM VEHICLE FACTORY RADIO HARNESS HARNESS BEHIND RADIO STEP 4 MAESTRO RR MODULE IF PRESENT AMP TURNON AMP TURNON RR-MFT1 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN...
Page 199 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 200 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 201 Ensure the 4-pin data cable is connected between the radio and the RR, and RED TWICE that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty. Make sure the correct radio model and serial number were entered during the fl ash.
Page 202 RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER, AND MORE! HEAD UNIT ADAPTER READY PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MFT1 Dash Kit Radar Installation Guides E L E C T R O N I C S...
Page 203 LincoLn MKX with MyLincoLn touch 2014-2015 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 204 8. Cut and remove the plastic behind the screen. (Fig. 1.7 ) Fig. 1.5 Fig. 1.6 Keep screws and brackets fot MFT1 dash kit assembly. Unbox MFT1 dash kit and locate bracket set #1, discard set #2. Fig. 1.7 Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 205 • Plug the data cable to the data port of the aftermarket radio. • Insert the audio cable into the iDatalink 3.5mm audio jack of the aftermarket radio (labeled iDatalink. If there is no iDatalink audio input, connect to AUX).
Page 206 BLACK BLACK WHITE STEP 3 WIRES FROM VEHICLE FACTORY RADIO HARNESS HARNESS BEHIND RADIO STEP 4 MAESTRO RR MODULE IF PRESENT AMP TURNON AMP TURNON RR-MFT1 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN...
Page 207 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 208 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MFT1-DS-IG-EN maestro.idatalink.com...
Page 209 Ensure the 4-pin data cable is connected between the radio and the RR, and RED TWICE that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty. Make sure the correct radio model and serial number were entered during the fl ash.

This manual is also suitable for:

Maestro rr2 Maestro hrr-mft1

iDataLink Maestro RR Install Manual

Quick Links

Related Manuals for iDataLink Maestro RR

Summary of Contents for iDataLink Maestro RR

This manual is also suitable for:
