LidSaver
2 Mini Lid and Condiment Cup Dispensers
Thank you for purchasing this Vollrath equipment. Before operating the
equipment, read and familiarize yourself with the following operating
and safety instructions. SAVE THESE INSTRUCTIONS FOR FUTURE
REFERENCE. Save the original box and packaging. Use this packaging
to ship the equipment if repairs are needed.
SAFETY PRECAUTIONS
To ensure safe operation, read the following statements and understand
their meaning. This manual contains safety precautions which are
explained below. Please read carefully.
WARNING
Warning is used to indicate the presence of a hazard that will or can
cause severe personal injury or death.
CAUTION
Caution is used to indicate the presence of a hazard that will or can
cause minor or major personal injury if the caution is ignored.
NOTICE: Notice is used to note information that is important but not
hazard-related.
Item No.
LS02MS18B
LS02MVS18B Vertical
NOTICE: Each LidSaver™ 2 Mini is factory set to dispense a
OVERVIEW
A
Bezel/Housing
B
"A" Claw. Marked with lid manufacturer and model no.
C
Door Spring
D
Spring Covers
E
Piston
F
Pivoting Pager Flipper. For smooth lid loading.
G
Piston Lid Plate
Shear Screws. (10-24 x ³⁄₈ R.H.M.S.)
H
I
Door
J
"B" Claw. Marked with lid manufacturer and model no.
Shear Screws. (6-32 x ³⁄₄ F.H.M.S.)
K
Please register your product at Vollrath.com
©
2016 The Vollrath Company L.L.C.
Operator's Manual
Mounting Description
Horizontal Dispenses lids and cups with diameter 1³⁄₄ - 3¹⁄₄
(4.4 - 8.3 cm) and max height of 1⁷⁄₈ (4.8 cm)
particular lid or cup. If you change manufacturers or sizes,
your LidSaver™ 2 Mini will need to be modified. Vollrath
offers lid change out kits that are easy to install. Visit
www.Vollrath.com for more information.
F
E
D
C
B
A
Part No. 513502-1 en
G
H
I
J
K
5/18/16
