D, SCFD, CFD, YHBT#14, HBT#50 Models
HD, SCFHD Models
FRYMASTER FPD65, FPHD65, FPLHDC65 Models
READ THE INSTRUCTIONS BEFORE USING THE
Frymaster, a member of the Commercial Food Equipment Service Association, recommends
using CFESA Certified Technicians.
www.frymaster.com
Original Instructions

CAUTION
FRYER.
24-Hour Service Hotline 1-800-551-8633
E-mail:
fryservice@welbilt.com
NON-CE &
08/2019
*8197001*
