Chapter 4
Install the Compaq Rack Front Bezel
Install the front bezel optimized for Compaq racks as follows:
1. Hold the bezel in front of the HP NetServer, as shown in Figure 4-8. Align
the four studs on the back of the bezel with the four oval holes indicated in
the figure.
2. Press the front bezel firmly into place.
40
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Figure 4-8. Installing the Front Bezel for Compaq Racks
Installing into the Rack
