APPENDIX A SHIELD BLOCK CONNECTOR INSTALLATION
INSTRUCTIONS
A.1 Shield Block Installation Parts
Table 2-3 and Table A-1 list the parts needed to install a Shield Block. Parts listed in
supplied in the GTR 200/200B Connector Kit (011-003240-00) and the GTR 200/200B Connector Kit
FAA-PMA (011-003240-01). Parts listed in Table A-1 are to be provided by the installer.
Table A-1 Parts not supplied for a Shield Block Installation
Figure
Ref
Multiple Conductor Shielded Cable (2-conductor shown in
4
Figure A-1)
5 Drain Wire Shield Termination (method optional)
Braid, Flat (19-20 AWG equivalent, tinned plated copper strands
6
36 AWG, Circular Mil Area 1000 -1300)
7 Floating Shield Termination (method optional)
13 Silicon Fusion Tape
190-01553-00
Rev. P
Description
Table 2-3
(Figure A-1)
GPN or MIL spec
Parts used depend on
method chosen
Parts used depend on
method chosen
Parts used depend on
method chosen
Parts used depend on
method chosen
