2 INSTALLATION OVERVIEW

2.1 Introduction

Careful planning and consideration of the suggestions in this section are required to achieve the desired
performance and reliability from the GTR 200/200B. The guidance of FAA advisory circulars AC 43.13-
1B and AC 43.13-2B, where applicable, may be found useful for making retro-fit installations that comply
with FAA regulations.

2.2 Unit Configurations

Model
GTR 200 Unit Only,
Serial Number Prefix 2QQ
GTR 200 Standard,
(includes items in Table 2-2)
Serial Number Prefix 2QQ
GTR 200 Unit Only,
Serial Number Prefix 5JC
GTR 200 Standard,
(includes items in Table 2-2)
Serial Number Prefix 5JC
GTR 200B,
Serial Number Prefix 5JD
GTR 200B Standard,
(includes items in Table 2-2)
Serial Number Prefix 5JD
GTR 200B FAA-PMA,
Serial Number Prefix 5JD
GTR 200B Standard FAA-PMA,
Serial Number Prefix 5JD

2.3 Available Accessories

2.3.1 Standard Accessories
Connector Kit (see Table
Connector Kit FAA-PMA (see
Installation Rack (see Figure
Installation Rack FAA-PMA (see
190-01553-00
Rev. P

Table 2-1 Catalog Part Numbers

Catalog Part Number
010-01087-00
010-01087-01
010-01087-10
010-01087-11
010-01087-20
010-01087-21
010-01087-40
010-01087-41

Table 2-2 Standard Kit Accessories

Item
2-3)
Table 2-3)
C-2)
Figure C-2)
Unit Only Part Number
011-02980-00
011-02980-00
011-02980-10
011-02980-10
011-02980-20
011-02980-20
011-02980-40
011-02980-40
Part Number
011-03240-00
011-03240-01
115-01878-00
115-01878-02 (ordered as 011-03240-10)
