Omcan FP-CN-0003 Instruction Manual page 9

Model FP-CN-0003
Item No. Description
23437 Bowl Cover without Handle for 10916
23438 Rubber Ring for 10916
23439 Knife for 10916
23440 Tight Screw for 10916
23441 Set Pin for 10916
23442 Set Pole for 10916
69071 Spring for 10916
23443 Bump Pole I for 10916
23444 Round Screw for 10916
23445 Bump Pole II for 10916
Model FP-CN-0005
Item No. Description
23412 Bowl Cover without Handle for 10917
23413 Rubber Ring for 10917
23414 Knife for 10917
23415 Tight Screw for 10917
23416 Set Pin for 10917
69071 Spring for 10917
23418 Bump Pole I for 10917
23419 Round Screw for 10917
23420 Bump Pole II for 10917
23421 Pressure Spring for 10917
10916
Position Item No. Description
1 23446 Pressure Spring for 10916
2 23447 Set Screw for 10916
3 31517 Universal Switch for 10916
4 31518 Start Button for 10916
5 31520 Stop Button for 10916
6 23450 Rack for 10916
7 23452 Bowl Adjust Ring for 10916
8 23453 Copper Setting for 10916
9 69072 Clasp for 10916
10 23455 Bowl for 10916
10917
Position Item No. Description
1 23422 Set Screw for 10917
2 31517 Universal Switch for 10917
3 31518 Start Button for 10917
4 31520 Stop Button for 10917
5 23425 Rack for 10917
7 23427 Bowl Adjust Ring for 10917
8 23428 Copper Setting for 10917
9 69072 Clasp for 10917
10 23430 Bowl for 10917
11 23431 Six Angle Screw for 10917
Parts Breakdown
Position Item No.
11 23456
12 23457
13, 16 23458
14 23459
14 23460
15 23461
17 31514
18 31515
19 24421
20
Position Item No.
12 23432
13, 16 23433
14 23434
14 23435
15 23436
17 31514
18 31516
19 24421
20
21
9
Description Position
Six Angle Screw for 10916 21
Motor Set Plate for 10916 22
Six Angle Screw for 10916 23
Motor for 10916 24
Bottom Plate for 10916 25
Bottom Foot for 10916 26
AC Contactor for 10916
Thermal Relay for 10916
Magnetic Switch for 10916
Description Position
Motor Set Plate for 10917 22
Six Angle Screw for 10917 23
Motor for 10917 24
Bottom Plate for 10917 25
Bottom Foot for 10917 26
AC Contactor for 10917
Thermal Relay for 10917
Magnetic Switch for 10917
