Summary of Contents for RigExpert AA-3000 ZOOM
- Page 1 AA-3000 ZOOM RigExpert ® User’s manual...
- Page 2 For latest manuals and software updates, please visit http://rigexpert.com...
-
Page 3: Table Of Contents
Table of contents Introduction Operating the AA -3000 ZOOM First time use Main menu Multifunctional keys Connecting to your antenna SWR chart Chart ZOOM Data screen Frequency and range entry Return loss chart R X chart Smith chart Memory operation SWR meter SWR2Air Display all parameters MultiSWR mode... - Page 4 Annex 4: Setup menu Annex 5: TDR mode Annex 6: Calibration Annex 7: Dummy loads DECLARATION OF CONFORMITY...
-
Page 5: Introduction
Introduction Thank you for purchasing a RigExpert AA-3000 ZOOM Antenna and Cable Analyzer! We did our best to make it powerful yet easy to use. The analyzer is designed for measuring SWR (standing wave ratio), return loss, cable loss, as well as other parameters of cable and antenna systems in the range of 100 kHz to 3000 MHz. -
Page 6: Operating The Aa-3000 Zoom
Operating the First time use AA-3000 ZOOM Please insert three AA sized batteries (alkaline, Ni-MH or LiPO accumulators) into the battery compartment of the analyzer, watching the polarity. Press the (Power) key located at the bottom-right corner of the keypad to turn on the analyzer. -
Page 7: Multifunctional Keys
The rest of the connector, as well as the cable, should remain stationary. If you twist other parts of the connector when tightening or loosening, damage may easily occur. Twisting is not allowed by design of the N-connector. RigExpert AA-3000 ZOOM... -
Page 8: Swr Chart
SWR chart Once your antenna is connected to the analyzer, it is time to measure its charac- teristics. Press the (SWR chart) key to open the SWR chart screen, then press (OK) to start a new measurement. A few moments later, the result will be displayed on the analyzer’s screen. -
Page 9: Data Screen
Return loss chart The return loss (RL) chart, which is very similar to the SWR chart, is activated by pressing (Functional key) and (RL chart) key combination in the Main menu. RigExpert AA-3000 ZOOM... -
Page 10: R X Chart
R,X chart Press the (R,X chart) key in the Main menu to access the R,X chart mode. Positive values reactance correspond to inductive load, while negative values correspond to capacitive load. The chart will display R and X for series or parallel models of a load. -
Page 11: Memory Operation
5.0 and above are represented as long dash. Portable, FM -able radio is typically used to pick up radio channel. Change transmit frequency by pressing , other SWR2Air related parameters you can find in Setup menu. Use to switch between meter and trend view. RigExpert AA-3000 ZOOM... -
Page 12: Display All Parameters
Display all parameters To display various parameters of a load on a single screen, press the (All) key. Do not be confused by negative values of L or C. This can be useful for experienced users. This screen displays values for series as well as parallel models of impedance of a load. -
Page 13: Multiswr Mode
SWR of band and frequency at this point provided by text. Measuring is done in continous “in loop” manner, providing conviently “alive” picture. buttons to choose group, press and select the band for curve. Use the button to start and stop measuring. RigExpert AA-3000 ZOOM... -
Page 14: Hold Functions
HOLD functions RL and Smith charts. You can keep some measuring result on screen next to fresh measuring result. There are two ways of using HOLD. Using keys allows you to make current curve as reference curve (you can use even RECORD curve). Reference curve will be retained until next arbitrary user action. -
Page 15: My Bands
“gaps”, having in mind, to insert later some bands with expected place. Please, explore built-in help for other details and keys functionality. RigExpert AA-3000 ZOOM... -
Page 16: Applications
Applications Antennas Checking the antenna It is a good idea to check an antenna before connecting it to the receiving or transmit- ting equipment. The SWR chart mode is good for this purpose. Also you can use Multé tool located in Tools. Multé will check your rig against all HAM bands defined in your region and rate all bands where SWR lower than 3.0 in range of 1...5 stars. -
Page 17: Coaxial Lines
• In the open-circuited case, resonant frequencies correspond to (left to right) 1/4, 3/4, 5/4, etc. of the wavelength in this cable; • For the short-circuited cable, these points are located at 1/2, 1, 3/2, etc. of the wavelength. RigExpert AA-3000 ZOOM... - Page 18 Cable length measurement Resonant frequencies of a cable depend on its length as well as on the velocity factor. A velocity factor is a parameter which characterizes the slowdown of the speed of the wave in the cable compared to vacuum. The speed of wave (or light) in vacuum is known as the electromagnetic constant: c=299,792,458 meters (or 983,571,056 feet) per second.
- Page 19 16.4 / (1/4) x 9,400,000 = frequency (in Hz). 616,640,000 feet per second 3. Finally, find the velocity factor. Just 188,000,000 /299,792,458 = 0.63 divide the above speed by the electro- - or - magnetic constant. 616,640,000 /983,571,056 = 0.63 RigExpert AA-3000 ZOOM...
- Page 20 Cable fault location To locate the position of a probable fault in a cable, just use the same method as when measuring its length. Watch the behavior of the reactive component (X) near the zero frequency: • If the value of X is moving from –∞ to 0, the cable is open-circuited: •...
- Page 21 4. Cut little pieces (1/10 to 1/5 of the 11 cm (0.36 ft) were cut off. margin) from the far end of the cable until the X value falls to zero (or changes its sign). Do not forget to restore the open-circuit, if needed. RigExpert AA-3000 ZOOM...
- Page 22 Measuring the characteristic impedance The characteristic impedance is one of the main parameters of any coaxial cable. Usually, its value is printed on the cable by the manufacturer. However, in certain cases the exact value of the characteristic impedance is unknown or is in question. To measure the characteristic impedance of a cable, 1.
- Page 23 (36.2 * 71.6) = 50.9 Ohm Example 2: square root of (114.0 * 50.0) = 75.5 Ohm The Tools menu (see page 29) contains several automated tools for coaxial line calculations. RigExpert AA-3000 ZOOM...
-
Page 24: Measurement Of Other Elements
The analyzer can measure capacitance from a few pF to about 0.1 µF as well as induct- ance from a few nH to about 100 µH. Since measuring of capacitance and inductance is not a main purpose of RigExpert analyzers, the user will have to gain some experi- ence in such measurements. - Page 25 Unknown inductor Transformers RigExpert analyzers can also be used for checking RF transformers. Connect a 50 Ohm resistor to the secondary coil (for 1:1 transformers) and use SWR chart, R,X chart or Smith chart modes to check the frequency response of the transformer. Similarly, use resistors with other values for non-1:1 transformers.
- Page 26 Traps A trap is usually a resonant L-C network used in multi-band antennas. By using a simple one-turn wire coil, a resonant frequency of a trap may be measured. Example: A coaxial trap constructed of 5 turns of TV cable (coil diameter is 6 cm) was measured.
-
Page 27: Annexes
• Records: 250 unified memory slots (32…104 °F) RF output: Weight: 442 g (15.6 oz) • Connector type: N Warranty: 2 years • Output signal shape: square Made in Ukraine. • Output power: -10 dBm (at 50 Ohm load) RigExpert AA-3000 ZOOM... -
Page 28: Annex 2 Precautions
Annex 2 Precautions Never connect the analyzer to your antenna in thunderstorms. Lightning strikes as well as static discharge may kill the operator. Never leave the analyzer connected to your antenna after you fin- ished operating it. Occasional lightning strikes or nearby trans- mitters may permanently damage it. -
Page 29: Annex 3: Tools Menu
Connect either open or short circuited cable to the analyzer and press (OK) to start. The analyzer will immediately show resonant frequencies for both quarter- wave and halfwave stubs. Longer cables have lower resonant frequency. RigExpert AA-3000 ZOOM... - Page 30 Length & VF Knowing the velocity factor, a physical length of a cable can be easily calculated. Press the (Up) button and edit the value of the velocity factor, then press (OK) to start measurement. To find the velocity factor of an unknown cable, press the (Down) key and enter the physical length, then press...
- Page 31 Once the analyzer finishes the measure- ment, you will see the Loss versus frequency chart. Use (Left) and (Right) cursor keys to change frequency and watch the loss value in decibels at the bottom of the analyzer’s screen. RigExpert AA-3000 ZOOM...
- Page 32 Cable impedance To measure the characteristic imped- ance, use a piece of an open circuited cable: a half of a meter (or a foot) or longer should be fine. Press (OK) to start. Next, the far end of the cable should be short circuited.
- Page 33 Self tests There are several built-in self tests in the AA-3000 ZOOM analyzer, which can be run by the user to make sure the analyzer is working properly. Press to start the test and then follow instructions given on the display.
- Page 34 Annex 4 Setup menu For the quick access to the Setup menu, press the key combination. There are several settings in the Setup menu: • Language – select a language for the analyzer’s menus • Palette – choose a color scheme •...
- Page 35 Pulse Echo fault. sent received Voltage Instead of a short pulse, a “step” function may be sent over the cable. delay Time Step Echo RigExpert AA-3000 ZOOM...
- Page 36 Unlike many other commercially-available reflectometers, RigExpert AA-3000 ZOOM does not send pulses into the cable. Instead, another technique is used. First, R and X (the real and the imaginary part of the impedance) are measured over the whole frequency range (up to 3000 MHz). Then, the IFFT (Inverse Fast Fourier Transform) is applied to the data.
- Page 37 Capacitive Inductive coefficient coefficient discontinuity discontinuity distance distance Capacitive Inductive reflection reflection termination termination coefficient coefficient distance distance Lossy reflection Cable with reflection cable coefficient Z > Z 0 coefficient distance distance RigExpert AA-3000 ZOOM...
- Page 38 Practice for quick setup popup, choose smallest range approriate for your cable length (shorter distances have better length resolution), tune velocity factor fast. Change of velocity factor corrects range distances. The result of measure can be viewed in three modes: impulse response, step response, impedance response.
- Page 39 Annex 5 TDR mode RigExpert AA-3000 ZOOM is designed for high performance and uses factory open- short-load (OSL) calibration. To make usage more flexible for expirienced users there are 10 user OSL profiles, that can be applied above factory OSL.
- Page 40 in main menu to go in calibration profiles managment screen. Select profile and press to make profile active, combination of allows to edit existing profile name. starts calibration sequence for selected profile. Follow instructions on screen to perform 3 step calibration. You may connect calibration standards to the far end of a cable, so the cable will be “nulled”.
- Page 41 RF terminators which provide low SWR over the wide frequency range. High-power terminators, with cable or not, are suitable neither for calibration purposes (page 32), nor for analyzer self-tests (page 30). Bird 8201 500 Watt oil-cooled termination High SWR RigExpert AA-3000 ZOOM...
- Page 42 We, Rig Expert Ukraine Ltd. of 2 Solomenska Ploscha, Kyiv, 03035, Ukraine Declare under our sole responsibility that the product: Antenna and cable analyser Equipment RigExpert Brand name Model number AA-30000 ZOOM to which this declaration relates, is in conformity with the following standards and / or other normative documents: Reference No.:...
- Page 43 RigExpert AA-3000 ZOOM...
- Page 44 This symbol is only valid in the European Union (EU). If you wish to discard this product, please contact your local authorities or dealer and ask for the correct method of disposal. http://www.rigexpert.com Copyright © 2020-2022 Rig Expert Ukraine Ltd. “RigExpert” is a registered trademark of Rig Expert Ukraine Ltd. Doc. date: 11-May-2023...
