RigExpert Stick 500.
Users Manual
Stick 500 is an antenna and cable vector analyzer. The analyzer allows you to measure various parameters of antennas, cables, lines, lters,
and many others in the frequency range from 100 kHz to 500 MHz.
The Stick 500 analyzer has a compact size and lightweight, which is great for using the analyzer both in the home and in the eld.
The main parameters of the Stick 500 analyzer:
Operating frequency: 100 kHz – 500 MHz
Size: 185 * 40 * 33 mm (7,3 in x 1,6 in x 1,3 in)
Weight: 185 grams (6.5 Oz) (unpacked, with battery installed)
Type of antenna connector: SO-239
Number of Enter Keys: 6
Display: high contrast E Ink display, 200 * 200 pixels.
Type of battery used: Li-ion 18650 (included)
PC Connector Type: USB 2.0 Type-C
Charging Port Type: USB Type-C
Bluetooth Availability: Yes, Bluetooth ver. 4.2 BLE Single-mode, Class B
Battery Charge Time: 3 hours.
RF Power: -10 dBm (at 50 Ohm load)
Minimum frequency step: 1 kHz
Operating temperature: -15°...40 °C (5...104 °F)
The Stick 500 analyzer can be turned on in several ways: – by pressing the
on automatically). – by long-pressing one of the keys :
measurement mode to which the pressed key corresponds.
You can turn off the analyzer from any mode by long-pressing the
Important! When the analyzer is turned off, its screen does not become blank. The screen always displays the following information:
Show less
https://rigexpert.com/products/antenna-analyzers/stick-500/users-manual/
Every job needs the right tool
Where to service The RigExpertCare™
DigiFest News & Press
Users Manual | RigExpert™
HAM Radio Sponsorship
Company
Turning on the analyzer.
key. – when connecting the analyzer to a PC via a USB cable (the analyzer will turn
Important! At the same time, the analyzer will turn on and activate the
key.
Main menu.
