Summary of Contents for Titan 0532035
- Page 1 - e - instrucciones de uso - p - MAnuAl de proprietário 54 Impact 440 Airless, high-pressure sprAying unit Airless equipo de AltA presión pArA pulverizAr unidAde de pulverizAção de AltA pressão Airless MODEL 0532035 0532038 • Form No. 0532881B 0317...
- Page 2 Before any work is done on the unit or for every break in work the following rules must be observed: Release the pressure from spray gun and hose. Secure the Titan spray gun using the trigger lock on the trigger. Switch off unit. Be safety conscious!
-
Page 3: Table Of Contents
Impact 440 contents cleANINg The uNIT (ShuTTINg DoWN) __ 17 SAfeTy regulATIoNS for AIrleSS SprAyINg ______________________________ 4 Cleaning unit from outside _____________________17 Explanation of symbols used _____________________4 Suction filter _________________________________17 Electric safety _________________________________8 Cleaning the high-pressure filter ________________18 Electrostatic charging (formation of sparks or flames) 8 Cleaning Airless spray gun _____________________18 geNerAl vIeW of ApplIcATIoN __________ 9 remeDy IN cASe of fAulTS _____________ 19... -
Page 4: Safety Regulations For Airless Spraying
Impact 440 safety precautions SAfeTy regulATIoNS for AIrleSS SprAyINg hAZArD: INjecTIoN INjury explANATIoN of SymBolS uSeD Attention: Danger of injury by This manual contains information that must be injection! A high pressure stream read and understood before using the equipment. produced by this equipment can When you come to an area that has one of the pierce the skin and underlying tissues,... - Page 5 1MΩ. For reasons of function, safety and durability • use only original Titan high-pressure hoses. • Before each use, check all hoses for cuts, leaks, abrasion or bulging of cover. Check for damage or movement of couplings.
- Page 6 Impact 440 safety precautions container to ground container and prevent hAZArD: exploSIoN or fIre static sparks. Flammable vapors, such as solvent Follow material and solvent manufacturer’s • and paint vapors, in work area can warnings and instructions. Be familiar with ignite or explode.
- Page 7 Impact 440 safety precautions hAZArD: hAZArDouS hAZArD: geNerAl vAporS This product can cause severe injury or property damage. Paints, solvents, and other materials can be harmful if inhaled or come in contact with body. Vapors can cause preveNTIoN: severe nausea, fainting, or poisoning. Follow all appropriate local, state, and •...
-
Page 8: Electric Safety
Impact 440 safety precautions elecTrIc SAfeTy elecTroSTATIc chArgINg (formATIoN of SpArkS or Electric models must be earthed. In the event flAmeS) of an electrical short circuit, earthing reduces the risk of electric shock by providing an escape Electrostatic charging of the unit may wire for the electric current. -
Page 9: General View Of Application
Dilutable lacquers and paints or those containing solvents, two- component coating materials, dispersions, latex paints, release agents, oils, undercoats, primers, and fillers. No other materials should be used for spraying without Titan’s approval. fIlTerINg Despite suction filter and insertion filter in the spray gun, filtering of the coating material is generally advisable. -
Page 10: Description Of Unit
Titan Impact 440 units are electrically driven high-pressure A piston pump takes in the coating material by suction and spraying units. conveys it to the tip. Pressed through the tip at a pressure of A gear unit transfers the driving force to a crankshaft. -
Page 11: Legend For Explanatory Diagram Impact 440
Impact 440 description of unit legeND for explANATory DIAgrAm ImpAcT 440 9. Relief valve 1. Spray gun Lever position vertical – PRIME ( k circulation) 2. High-pressure hose Lever position horizontal – SPRAY ( p) 3. Return hose 10. ON/OFF switch 4. -
Page 12: Technical Data
Impact 440 description of unit / starting operation STArTINg operATIoN TechNIcAl DATA hIgh-preSSure hoSe, SprAy guN AND SepArATINg oIl voltage 1. Screw the pressure gauge (1) to the coating material 220~240 VAC, 50/60 Hz outlet (Fig. 2, Item 2). max. current consumption 2. -
Page 13: Control Panel Indicators
Impact 440 starting operation Solid yellow When the pressure indicator is solid yellow, the sprayer is operating between 1.4 MPa (14 bar) and 12 MPa (120 bar). A solid yellow pressure indicator means: • The sprayer is at the proper pressure setting for spraying stain, lacquer, varnish, and multi-colors Solid green When the pressure indicator is solid green, the sprayer is... -
Page 14: Connection To The Mains Network
The connection must be equipped with a residual current protective device with INF ≤ 30 mA. Titan‘s accessories program also includes a mobile operator protection device for the electronic supply, which can also be used with other electronic equipment. -
Page 15: Spraying Technique
Impact 440 spraying SprAyINg Injection hazard. Do not spray without the tip guard in place. NEVER trigger the gun unless the tip is completely turned to either the spray or the unclog position. ALWAYS engage the 25 - 30 cm 25 - 30 cm gun trigger lock before removing, replacing or cleaning tip. -
Page 16: Handling The High-Pressure Hose
Never pull on the high-pressure hose to move the device. cleaning agent. Make sure that the high-pressure hose cannot twist. This can be avoided by using a Titan spray gun with a swivel joint and a If fast-drying or two-component coating material hose system. -
Page 17: Cleaning The Unit (Shutting Down)
Impact 440 cleaning the unit (shutting down) cleANINg The uNIT (ShuTTINg DoWN) cleANINg uNIT from ouTSIDe A clean state is the best method of ensuring operation without problems. After you have finished spraying, clean the unit. Under no First of all pull out mains plug from socket. circumstances may any remaining coating material dry and harden in the unit. -
Page 18: Cleaning The High-Pressure Filter
Impact 440 cleaning the unit (shutting down) cleANINg The hIgh-preSSure fIlTer cleANINg AIrleSS SprAy guN Clean the filter cartridge regularly. A soiled or Clean the spray gun after each use. clogged high-pressure filter can cause a poor spray pattern or a clogged tip. 1. -
Page 19: Remedy In Case Of Faults
Piston is worn. Remove and replace piston. Increased pulsation at the spray Incorrect high-pressure hose type. Only use TITAN original-high-pressure hoses in order to ensure functionality, safety and durability. Tip worn or too large. Replace tip. Pressure too high. -
Page 20: Servicing
11.1 relIef vAlve The risk of damage rises with the age of the high-pressure hose. Titan recommends replacing The valve housing (4) should not be repaired. If high-pressure hoses after 6 years. worn, it should always be replaced with a new one. -
Page 21: Inlet And Outlet Valve
Impact 440 repairs at the unit 10. Unscrew outlet valve housing (Fig. 12, Item 8) from the 11.2 INleT AND ouTleT vAlve piston (9) with adjusting wrench. 1. Remove the four screws in the front cover and then remove 11. Remove the upper ball cage (11), crush washer (10), outlet the front cover. -
Page 22: Packings
Impact 440 repairs at the unit 11.3 pAckINgS 1. Remove inlet valve housing in accordance with the steps 11. Insert lower packing (Fig. 15) with the beveled edge (1) in Chapter 11.2, Page 21. facing upward. 2. It is not necessary to remove the outlet valve. 3. -
Page 23: Replacing The Motor
11.4 replAcINg The moTor The following procedure must only be performed by a Titan Authorized Service Center. 1. Open the relief valve, valve position PRIME (k circulation). Switch the unit OFF. Unplug the power plug from the outlet. -
Page 24: Replacing The Gears
11.5 replAcINg The geArS The following procedure must only be performed by a Titan Authorized Service Center. 1. Open the relief valve, valve position PRIME (k circulation). Switch the unit OFF. Unplug the power plug from the outlet. -
Page 25: Replacing The Transducer
11.6 replAcINg The TrANSDucer The following procedure must only be performed by a Titan Authorized Service Center. 1. Loosen and remove the four front cover screws (1). Remove the front cover (2). 2. Stop the sprayer at the bottom of its stroke so that the piston is in its lowest position. -
Page 26: Impact 440 Connection Diagram
Impact 440 repairs at the unit / appendix 11.7 ImpAcT 440 coNNecTIoN DIAgrAm Power Cord EMI Filter Blue Potentiometer Ground L.E.D. Switch P/N 0516360 Blue Circuit Brown P/N 0522052 Breaker Red (+) Red (+) White Gray P/N 0522053 Motor Brown Black Black Ground... -
Page 27: Warranty
WArrANTy Titan Tool, Inc., (“Titan”) warrants that at the time of delivery to the original purchaser for use (“End User”), the equipment covered by this warranty is free from defects in material and workmanship. With the exception of any special, limited, or extended warranty published by Titan, Titan’s obligation under this warranty is limited to replacing or repairing without charge those parts which, to...
