Chapter 1 GENERAL DESCRIPTION

1.1 General identification data

This instruction handbook is considered as an essential document
of podoscope AP500GIMA (GIMA 27363). Therefore they must not be separated in case
of cessation to third parties, in accordante with EC Directive 93/42/EC
and following norms.
This handbook gives the operator all the relevant information to carry out the following operations correctly:
- INSTALLATION - USAGE - MAINTENANCE
Instructions for a correct installation are contained in the par.
2.2 CONDITIONS FOR THE INSTALLATION.
All serious accidents concerning the medical device supplied by us must be reported to the ma-
nufacturer and competent authority of the member state where your registered office is located.
Company Name
Commercial Trademark: Gima
Typology: Podoscope
Model: AP500GIMA (GIMA 27363)
Manufacturer: Gima S.p.A. - Via Marconi, 1 20060 Gessate (MI) - Italy
Identification and labels, symbols explication
Warning: maximum load 135 kg (297 lbs)
AP500GIMA (GIMA 27363)
VOLTAGGIO/
MAINS VOLTAGE
220-240V
On each device you will find a similar plate with the manufacturer's
identification

1.2 Description and general characteristics

The particular system of light diffusion of the Podoscope AP500GIMA (GIMA 27363 enables
you to study the patient's foot plant and to mark the parts with the heaviest pressure.
Its structure is very simple: the methacrylate structure is an excellent
light conductor and it is also endowed with an inner light source: in this way
you can discover variations of colour intensity on the foot plant,
corresponding to higher or lower plant pressure.
The base is of ABS.
A separable net cable with plug, a jack, and a led strip are its electric
components.

1.3 Technical features and voltage

Material
FREQUENZA/ POTENZA/
FREQUENCY POWER
50/60 Hz 7,5 VA
ENGLISH
Transparent methacrylate
Tecniwork S.p.A.
V.Benini 8 - 50013
Campi Bisenzio - FI - Italy
