Measurement Specifications - optris PI Operator's Manual

Measurement Specifications

Temperature ranges
Spectral range
Lenses
System accuracy 1)
Temperature resolution (NETD)
Frame rate
Warm-up time
Emissivity
Measurement functions
Software
1) at ambient temperature 23±5 °C; whichever is greater
6
-20...100 °C
0...250 °C
120...900 °C
7,5...13 µm
31° x 23°/ 9° x 7°
±2 °C or ±2 %
0,08 K
100 Hz
10 min
0,100...1,000 (adjustable via software)
Cross hairs (1x1, 3x3 or 5x5 pixels); free adjustable location
Measurement rectangle; Size scalable; free adjustable location
Both of these functions can be combined with the signal processing
features: Average, MAX, MIN value.
PIConnect
optris PI – E2008-06-A
