Welcome!

Thank you for choosing the optris PI thermal imager!
The optris PI calculates the surface temperature based on the emitted infrared energy of objects [► Basics of
Infrared Thermometry]. The two-dimensional detector (FPA - focal plain array) allows a measurement of
160 x 120 pixels and will be shown as thermographic image using standardized palettes. The radiometric
processing of the picture data enables the user to do a comfortable detailed analysis with the software
PI Connect.
The optris PI is a precise instrument and contains a sensitive infrared detector and a high-quality
lens. The alignment of the camera to intensive energy sources (high power laser or reflexions of such
equipment, e.g.) can have effect on the accuracy of the measurement or can cause an irreparable
defect of the infrared detector.
The mounting should be made only via the mounting threads or tripod connection the housing is
providing.

Scope of Supply

optris PI Thermal Imager incl. one lens
USB cable (1 m)
Process interface cable
Table tripod
Thermographic software PI Connect
Operators manual
