Technical Data

General Specifications

Environmental rating
Ambient temperature
Storage temperature
Relative humidity
Material (housing)
Dimensions
Weight
Cable length (USB 2.0)
Vibration
Shock
EMI

Electrical Specifications

Power Supply
Current draw
Output
Process Interface (PIF out)
Input
Process Interface (PIF in)
Digital interface
IP65 (NEMA-4)
0...50 °C
-20...70 °C
10...95 %, non condensing
aluminium, anodized
45 mm x 45 mm x 65 mm
250 g (incl. lens and 1 m USB cable)
1 m (Standard), 5 m, 20 m
IEC 68-2-6: 3G, 11 – 200Hz, any axis
IEC 68-2-27: 50G, 11ms, any axis
89/336/EWG
5 VDC (powered via USB 2.0 interface)
max. 500 mA
0-10 V (TObj, TInt or Flag status)
0-10 V (Emissivity, Flag control)
USB 2.0
optris PI – E2008-06-A
5
