RSA Lighting Mini Die Cast MS5008 Specifications

Recessed trim suitable
for downlighting
applications.
All die cast construc-
tion with durable pow-
der coat or plated fin-
ish.
Eyeball lamp holder
provides 45º adjustability
Includes recessed hous-
ing with porcelain bi-pin
lamp socket and 30" 18
AWG SF-1 wire leads.
U.L. Listed for undercabi-
net installations.
Item # Description
MS5008 Recessed Adjustable Eyeball Trim
MS5009
Type:
3.13" Die Cast Eyeball Trim
45º Adjustability
12V Bi-Pin Base MR11 Lamp 20 Watts Max.
2.5"
0.125"
1.813"
3.125"
Finish
White
Black
RSA LIGHTING LLC 9660 - 9700 TOPANGA CANYON BLVD. CHATSWORTH CA. 91311
TOLL FREE: 800-356-3030 • 818-349-3030 • FAX: 818-349-3031 • www.rsalighting.com
©2002 RSA Lighting LLC All Rights Reserved • Specifications subject to change without notice.
Project:
2"
Trim Dia. Ceiling Cut-Out
3.13" 2.50"
MS5008
MS5009
Lamp holder adjusts for
variable beam placement.
3"
Overall can height
(Actual space required
above ceiling: 2.5")
Lamp
12 volts Bi-Pin MR11
Halogen
20 watts max.
MD3
