RSA Lighting CMOB Specification Sheet

Recessed fixed trim suitable for
downlighting applications.
Ultra low profile trim flange for
minimum ceiling architecture
interference. Provides a sleek,
architectural look.
Trim has a durable powder coat
finish.
Inside of trim and lamp holder
finished with flat black powder
coat for reduced lamp glare.
Trim is retained in housing with
heavy duty torsion spring clip.
All ComboMini™ fixtures can
accept up to two (2) optical
accessories per lamp.
Housing Construction:
Plaster frame and housing are
18 gauge CRS with durable pow-
der coat finish.
Integral electronic transformer
with 14 gauge CRS galvanized J-
Box assembly. External thermal
protection. UL listed for through
branch wiring for 8 #12, 90ºC
supply conductors or 60ºC sup-
ply conductors for end of run.
Type:
Combo Mini Recessed Downlight
One (1) Light Square
New Construction Housing - 7.13" Height
12V Bi-Pin Base MR16 Lamp 75 Watts Max.
7.125"
4.75"
5.5"
1.625"
Provided with two (2) 14 gauge steel
butterfly type brackets for black iron
installations.
Vent holes in housing (1/2" diameter)
provide cooler operation.
Item # Description
CM0W Combo Mini Recessed Downlight
CM0B One Light Square
CM0S
©2002 RSA Lighting LLC All Rights Reserved • Specifications subject to change without notice.
Project:
7.125"
2.5"
4.5"
Aperture
Finish
White
Black
Silver
RSA LIGHTING LLC 9660 - 9700 TOPANGA CANYON BLVD. CHATSWORTH CA. 91311
TOLL FREE: 800-356-3030 • 818-349-3030 • FAX: 818-349-3031 • www.rsalighting.com
CM0W
15"
3.625" 4.25"
2.5"
Aperture
4.5"
Housing adjusts in plaster frame to accom-
modate various ceiling thicknesses.
Voltage / Wattage
12V / 75W Max.
CM0B
CM0S
CM1
