Connected Home Radiator Valve Actuator ZigBee, wireless
SSA911.02ZB
A6V13722083_de--_a
2022-12-12
Wireless radiator valve actuator, works with SIEMENS Connected Home
●
RF-controlled actuator communication based on ZigBee protocol (2.4 GHz,
bidirectional)
●
Connects and operates with Connected Home hub and receiver
●
Battery-operated with commercially available 1.5 V AA batteries
●
Valve thread connection M30x1.5 mm
●
Nominal stroke 5 mm
●
Valve positioning force 90 N
●
Adapts automatically to valve
●
Integrated temperature sensor and PI controller
●
Set temperature on device or via app
Smart Infrastructure
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Siemens SSA911.02ZB
Summary of Contents for Siemens SSA911.02ZB
- Page 1 Connected Home Radiator Valve Actuator ZigBee, wireless SSA911.02ZB Wireless radiator valve actuator, works with SIEMENS Connected Home ● RF-controlled actuator communication based on ZigBee protocol (2.4 GHz, bidirectional) ● Connects and operates with Connected Home hub and receiver ● Battery-operated with commercially available 1.5 V AA batteries ●...
- Page 2 Application ● The SSA911.02ZB wireless radiator valve actuator is designed to work on radiator valves from different manufacturers in HVAC applications using M30x1.5 thread. It operates the valve to control water flow and room temperature. ● The valve actuator works in combination with Connected Home Hub GTW100ZB and wireless repeater RCR110.2ZB (as an option)
- Page 3 Quick guide (A5W00205935A) ● Third-party valve adapter for Danfoss (RA, RAV, RAVL) ● Screw and nut for adapter Equipment combinations Siemens valves The SSA911.02ZB is suited for the following Siemens radiator valve types: V ̇ Type Data sheet [l/h] 0.63…1.41 VDN1.., VEN1..
- Page 4 Accessories Adapters for SSA911.02ZB for use with third-party valves Type Article number For use with... Adapter thread AV52 BPZ:AV52 Comap M28x1,5 AV56 BPZ:AV56 Giacomini AV57 BPZ:AV57 Herz M28x1,5 AV58 BPZ:AV58 Oventrop < 2002 M30x1 AV59 BPZ:AV59 Vaillant AV60 BPZ:AV60 TA < 2002...
- Page 5 Third-party valve adapter Adapters for Danfoss RA/RAV/RAVL valves included in delivery. • Remove connects on the plastic adapter before using one of the included adapters. • Use supplied screw and nut. • Insert pin on valve stem. Siemens A6V13722083_de--_a Smart Infrastructure 2022-12-12...
- Page 6 Product documentation Title Contents Document ID Connected Home Radiator Actuator Data sheet: Product description A6V13722083 ZigBee SSA911.02ZB Quick guide Connected Home Quick guide for mounting, commissioning, and A5W00293080A Radiator Actuator ZigBee operation SSA911.02ZB SSA911.02ZB Connected Home Hub GTW100ZB Data sheet: Product description...
- Page 7 Do not switch off Connected Home Hub and use a repeater as need to ensure proper communications. Mounting SSA911.02ZB is mounted on the radiator valve. There are no preferred mounting positions; actuator SSA911.02ZB can be operated in all mounting positions. The display must be clearly visible and the buttons easy to access.
- Page 8 Install and commission the Connected Home Hub GTW100ZB (see quick guide A6V12694180). ● Optional: Install and commission the Connected Home Receiver Hub CR110.02ZB (see quick guide A6V11562443). ● Install and commission the Connected Home Radiator valve actuator SSA911.02ZB (see quick guide A5W00293080A). Siemens A6V13722083_de--_a Smart Infrastructure 2022-12-12...
- Page 9 5 s). Battery compartment Press and hold for 5 s The device is deleted from the network. Press and hold for 3 s Displays the discovered network (Zigbee Node ID). Siemens A6V13722083_de--_a Smart Infrastructure 2022-12-12...
- Page 10 The Window open function switches off after 15 minutes and the device returns to the last active mode. Error codes Error codes An error code displays on the SSA911.02ZB in the event of a malfunction or communication error with Connected Home Hub. Press the plus or minus button to clear error codes. Siemens...
- Page 11 ● Dispose of empty batteries in designated collection points. Warranty Technical data on specific applications are valid only together with Siemens products listed under "Equipment combinations". Siemens rejects any and all warranties in the event that third-party products are used.
- Page 12 Internet if and to the extent such a connection is necessary and only when appropriate security measures (e.g. firewalls and/or network segmentation) are in place. In addition, Siemens’ guidance on appropriate security measures should be taken into account. For additional information, please contact your Siemens sales representative or visit https://www.siemens.com/global/de/home/unternehmen/themenfelder/zukunft-der-...
- Page 13 Permissible temperature of medium in the connected valve Directives and standards Product standard IEC 60730-1 Electromagnetic compatibility For residential, commercial, and industrial environments EU conformity (CE) A5W00090263A UKCA A5W00206069A EAC compliance Eurasian conformity for SSA911.02ZB Siemens A6V13722083_de--_a Smart Infrastructure 2022-12-12...
- Page 14 (RoHS compliance, compositions, packaging, environmental benefits and disposal). Material and dimensions Display Housing Material Plastic, light ASA+PC Color White NCS S 052-G Thread M30x1,5 See Dimensions [▶ W x H x D Weight Fully mounted Documents available at http://www.siemens.com/bt/download Siemens A6V13722083_de--_a Smart Infrastructure 2022-12-12...
- Page 16 Dimensions Dimensions in mm [kg] Including batteries 0.16 Siemens A6V13722083_de--_a Smart Infrastructure 2022-12-12...
- Page 17 Revision numbers Type Valid from rev. no. SSA911.02ZB ..01 SS5181-A105 Published by © Siemens Switzerland Ltd, 2021 Siemens Switzerland Ltd Subject to change Building Technologies Division International Headquarters Theilerstrasse 1a CH-6300 Zug +41 58 724 2424 www.siemens.com/buildingtechnologies Document ID A6V13722083_de--_a...
