AC60P
Portable Power Station
User Manual
Please Read This Manual Before Use And Follow Its Guidance.
Keep This Manual For Future Reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AC60P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Bluetti AC60P

  • Page 1 AC60P Portable Power Station User Manual Please Read This Manual Before Use And Follow Its Guidance. Keep This Manual For Future Reference.
  • Page 2 For optimum battery life, discharge and charge the unit every 3 months. 7. This product must be grounded before operation. Connect a grounding cable (recommended 14AWG(1.5mm C/yellow-green color) to the )/105 grounding terminal of AC60P. Fasten the grounding screw (M4*12) to fix the cable.
  • Page 3 Thank You! Thank you for making BLUETTI a part of your family. From the very beginning, BLUETTI has tried to stay true to a sustainable future through green energy storage solutions for both indoor and outdoor use while delivering an exceptional eco-friendly experience for our homes and our world.
  • Page 4: Table Of Contents

    Contents Safety Instructions General Safety Handling Storage and Usage What’s In The Box Product Overview Diagram Specifications Operating Instructions Buttons LCD Screen Charging Discharging Connect AC60P and B80P BLUETTI App Appendix FAQs Troubleshooting Abbreviations FCC Warning Important Instructions...
  • Page 5: Safety Instructions

    The Safety Requirements provided herein are for illustrative purposes that include but are not limited to those listed in this manual. Actual operation shall comply with all applicable safety standards. If you have any questions, feel free to contact BLUETTI support or your local BLUETTI dealers. 1.1. General Safety •...
  • Page 6 Do not move the unit during operation as the vibrations and shocks associated with movement may cause damage to the internal hardware. • In case of malfunction, turn off the unit immediately and contact BLUETTI support or your local BLUETTI dealers if this manual cannot adequately explain the malfunction to you.
  • Page 7: Handling

    It is recommended to charge the unit via an AC source. If charging via solar energy, ensure that your solar system provides an output of more than 100W. BLUETTI shall not be liable for any equipment damage caused by the violation of above instructions.
  • Page 8: What's In The Box

    2. What’s In The Box Standard Packaging Item Picture Qty. Portable Power Station AC Charging Cable (16AWG, 1800mm) Car Charging Cable ((16AWG, 720mm) Solar Charging Cable (16AWG, 1500mm) Grounding screw (M4*12) Fuse User Manual JUST POWER ON...
  • Page 9 Optional (Available on official BLUETTI website) Item Picture TYPE-C Cable (5A/100W, 2m) Cigarette Lighter to 5521 Cable (For 12V devices with 5521 port, such as routers, cameras, etc.) Cigarette Lighter to Clamp Cable (Charging lead-acid battery via the cigarette lighter port)
  • Page 10: Product Overview

    3. Product Overview 3.1 Diagram As a portable power station, AC60P weighs only 9.1 kg, yet features a 600W pure sine wave inverter and 504Wh LiFePO4 battery pack, enough to run most of your essentials for hours. LiFePO4 cells, the safest chemistry available, together with advanced Battery Management System (BMS), give you the highest level of security.
  • Page 11: Specifications

    3.2 Specifications Model AC60P Area EU/UN/AU Battery Capacity 504Wh Cell Type LiFePO4 Net Weight About 9.1kg/20.06lbs Dimensions (L*W*H) 290mm×205mm×234mm/11.42in×8.07in×9.21in Charging Temperature C~40 C/32°F~104°F -20°C~40°C(-20°C~30°C: 600W Max.; 30°C~40°C: 500W Max.) Discharging Temperature -4°F~104°F(-4°F~86°F: 600W Max.; 86°F~104°F: 500W Max.) Storage Temperature C~40 C/-4°F~104°F...
  • Page 12: Operating Instructions

    4.1.1. Power ON/OFF • Press the PWR button to start the AC60P. When AC60P is on, press this button to turn on/off the LCD screen. Press and hold the button for more than 2 seconds to turn off the AC60P.
  • Page 13 Grid Enhancement mode: By default, the Grid Enhancement mode is disabled. Please turn it on directly in the BLUETTI app. This mode ensures that the AC60P has a stable and continuous AC input, as it allows AC60P to adapt to voltage fluctuations and waveform distortion of an AC source.
  • Page 14: Lcd Screen

    4.2. LCD Screen ① ⑧ ⑮ DC Input Expansion battery 1 Short circuit alert ② ⑨ ⑯ Bluetooth Expansion battery 2 Overload alert ③ ⑩ ⑰ Wireless charging Input power Remaining time indicator ④ ⑪ ⑱ Battery capacity Power Lifting mode ⑤...
  • Page 15: Charging

    Turbo and silent modes can be enabled in BLUETTI app. BLUETTI’s AC charging mode guide is as follows: 1) Turbo charging comes in handy when you need AC60P to be replenished in short time. 2) Standard charging is more friendly to AC60P’s battery.
  • Page 16 4.3.2.Solar Charging Connect the solar panels (in series or parallel) to AC60P via the solar charging cable. Note: Please make sure your solar panels comply with: Voc: 12V~28V Input Current: 8A Max. Input Power: 200W Max. Warning: The open circuit voltage of solar panels cannot exceed 28V, otherwise it will damage the device.(Note: This is not covered in the warranty.)
  • Page 17: Discharging

    The operation time of AC60P is subject to many factors, such as ambient temperature, discharge rate, battery capacity, altitude, load characteristics, etc. 4.4.1.AC Output AC60P has 2 AC output ports, providing a total of up to 600W AC power. It can also handle a surge of 1200W. 4.4.2.DC Output •...
  • Page 18: Connect Ac60P And B80P

    (AC60P+2*B80P) (AC60P+1*B80P) 4.6 BLUETTI App Scan the QR code below or search "BLUETTI" in the App Store or Google Play to down- load the BLUETTI app. AC60P supports Bluetooth connection. Once connected, the AC60P can be accessed and controlled on a mobile phone or other smart devices. For more details, please refer to BLUETTI APP INSTRUCTIONS.
  • Page 19: Appendix

    Please evaluate the total constant load of your devices. If it doesn't exceed the Max. output power of AC60P (600W), you can use this power station to run your devices. Please note that if the total load exceeds the limit, but the loads on AC output is lower than 600W, the inverter will turn off the DC output only.
  • Page 20: Troubleshooting

    When should I use the Grid Enhancement mode? This mode is handy when charging the AC60P via an unstable AC source, such as an unreliable grid or generator. E.g. If you change the generator's output while charging the AC60P, the voltage dip will also cause the charge to fail.
  • Page 21: Abbreviations

    5.3 Abbreviations • MPPT: Maximum Power Point Tracking • SoC: State of Charge • UPS: Uninterruptible Power Supply • AC: Alternating Current • DC: Direct Current • PV: Photovoltaic (Solar Panels) • DoD: Depth of Discharge 5.4 FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
  • Page 22 This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innova- tion, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device.
  • Page 23: Important Instructions

    5.5 Important Instructions INSTRUCTIONS PERTAINING TO RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS IMPORTANT SAFETY INSTRUCTIONS, SAVE THESE INSTRUCTIONS WARNING – When using this product, basic precautions should always be followed, including the following: a)Read all the instructions before using the product. b)To reduce the risk of injury, close supervision is necessary when the product is used near children.
  • Page 24 2)NEVER smoke or allow a spark or flame in vicinity of battery or engine. 3)Be extra cautious to reduce risk of dropping a metal tool onto battery.It might spark or short-circuit battery or other electrical part that may cause explosion. l)When charging the internal battery, work in a well ventilated area and do notrestrict ventilation in any way.
  • Page 25 CONSIGNES DE SÉCURITÉ IMPORTANTES AVERTISSEMENT: lors de l’utilisation de ce produit, les précautions de base doivent toujours être respectées, y compris le Les éléments suivants: A)lire toutes les instructions avant d’utiliser le produit. B)pour réduire le risque de blessure, une surveillance étroite est nécessaire lorsque le produit est utilisé...
  • Page 26 L)lors du chargement de la batterie interne, travailler dans une zone bienventilée et ne pas restreindre la ventilation. M)dans des conditions abusives, le liquide peut être éjecté de la batterie;Évitezle contact.En cas de contact accidentel, rincer à l’eau.Si le liquide entre encontact avec les yeux, consulter un médecin.Le liquide éjecté...
  • Page 28 SHENZHEN POWEROAK NEWENER CO., LTD. Add: F19, BLD No.1, Kaidaer, Tongsha Rd No.168, Xili Street, Nanshan, Shenzhen, China USA Agent Company name: BLUETTI POWEROAK INC Address: 6185 S VALLEY VIEW BLVD STE D LAS VEGAS NEVADA 89118 United States FRN: 0033559824...
  • Page 29 * Only applies to products purchased directly from the official BLUETTI website. If you purchased the product from other channels, the warranty is valid for 24 months. However, you can register for BLUETTI VIP on the official website to get a free warranty extension.
  • Page 30 Customer Name: Date: Compay(optional): Address: City: State: Zip: Phone: Fax: Email Address: Purchase From: Name of Tech Support Spoken To: RMA #: Model Name: Serial #: Purchase Date: Problem Description:...
  • Page 32 Cer ti fi cate Inspector: Q C :...
