- Page 1 AC2A Portable Power Station User Manual V 2.0 Please read this manual carefully before use and keep it for future reference.
- Page 2 Warning 1. Charge the unit before first use. 2. Do not use solar panels with open circuit voltage higher than 60V. Solar input voltage range for the unit is 12V-28VDC. 3. Charge the unit immediately when the SoC drops below 5%. If the SoC drops to 0, power off the unit and charge it for at least 30 minutes before restarting.
- Page 3 Thank You! Thank you for making BLUETTI a part of your family. From the very beginning, BLUETTI has tried to stay true to a sustainable future through green energy storage solutions while delivering an exceptional eco-friendly experience for our homes and our world.
-
Page 4: Table Of Contents
Packing List Product Introduction Product Overview Power ON / OFF LCD Display Charging Discharging Settings BLUETTI App Specifications Button Operation Instructions Troubleshooting Appx. 1 Estimating Operation Time Appx. 2 FAQ Appx. 3 FCC Statement Appx. 4 IC Caution Appx. 5 Consignes de sécurité... -
Page 5: Safety Instructions
The safety instructions provided herein are for illustrative purposes that include but are not limited to those listed in this manual. Actual operation shall comply with all applicable safety standards. If you have any questions, feel free to contact BLUETTI support or your local BLUETTI dealers. - Page 6 ports of the product. • Use of an attachment not recommended or sold by the manufacturer may result in a risk of fire, electric shock, or injury to persons. • To reduce the risk of damage to the electric plug and cord, pull the plug rather than the cord when disconnecting the product.
- Page 7 • Do not stack anything on top of the product while in storage or use. Do not move the product while operating as vibrations and sudden impacts may lead to poor connections to the hardware inside. • In case of fire, use only a dry powder fire extinguisher appropriate for the product. •...
- Page 8 Please refer to the information on the exterior bottom enclosure for electrical and safety information before installing or operating the apparatus. SAVE THESE INSTRUCTIONS BLUETTI shall not be liable for any equipment damage caused by the violation of the above instructions. JUST POWER ON...
-
Page 9: Packing List
AC2A Portable Power Station User Manual V 2.0 Please read this manual carefully before use and keep it for future reference. Product Documentation Optional Accessory (Available on the official BLUETTI website: https://www.bluettipower.com) Item Picture Car Charging Cable JUST POWER ON... -
Page 10: Product Introduction
3. Product Introduction Introducing the BLUETTI AC2A, your perfect partner for lightweight and minimalist travel. With its 204.8Wh capacity and 300W output, it effortlessly charges smartphones, camer- as, lights, laptops, drones, and more. Pair it with solar panels to extend its usage time, ensuring you stay powered up throughout your trip. -
Page 11: Product Overview
4. Product Overview Grounding Pole DC Input ① ⑦ LCD Display AC Input ② ⑧ DC Power Button USB-A Port ③ ⑨ USB-C Port POWER Button ④ ⑩ ⑪ AC Power Button Cigarette Lighter Port ⑤ AC Outlet ⑥ JUST POWER ON... -
Page 12: Power On / Off
• Power OFF: Press and hold the POWER Button for about 2 seconds to turn off the unit. • AC ON / OFF: When the AC2A is on, press the AC Power Button to turn it on / off. • DC ON / OFF: When the AC2A is on, press the DC Power Button to turn it on / off. -
Page 13: Lcd Display
6. LCD Display The AC2A features an informative LCD display that offers easy access to all the essential information about the unit's status and performance. When you power on the unit, the LCD display lights up, and when you power off the unit, the display turns off as well. - Page 14 : Charging : Discharging The temperature inside the unit is higher than 70°C (158°F). The AC2A is drawing too much current, which can cause damage to the unit or any connected devices. The AC2A is overloaded. There's an issue with the AC2A, which may require troubleshooting or repair.
-
Page 15: Charging
Avoid getting the plug and socket wet to prevent any potential damage. 7.1 AC Charging Plug the AC2A into a standard wall outlet and start charging. Once it's fully charged, the AC2A automatically stops charging to prevent overcharging. For a fast charge, you can enable Turbo Charging in the BLUETTI App, which allows for an 80% capacity in just 45 minutes at an ambient temperature of 25°C (77°F). - Page 16 7.3 Car Charging Connect AC2A to the vehicle's 12V cigarette lighter port via the car charging cable. The AC2A can charge at a maximum of 96W, and it'll automatically stop charging once it's fully charged. Note: Make sure your vehicle meets the following conditions for charging: •...
-
Page 17: Discharging
Compatible Loads 120V AC Outlet x 2 Appliances up to 300W power. 50Hz / 60Hz Note: Do not apply AC2A to loads higher than 300W, as this may cause damage to AC2A and your devices. 8.2 DC Discharging Port Picture Specifications... -
Page 18: Settings
9. Settings The AC2A offers the convenience of adjusting its settings either via physical buttons or the BLUETTI App. With the buttons located on the device itself, you have direct control over various settings such as ECO Mode, Power Lifting Mode, output frequency, charging modes, and other functionalities. - Page 19 AC2A and your devices. 9.7 Exit Setting Mode To save your AC2A settings and exit the Setting Mode, press and hold both the AC and DC Power Buttons at the same time. Note: If you do not perform any operation in 1 minute, the AC2A will automatically exit the Setting Mode, and no changes will be saved.
-
Page 20: Bluetti App
10. BLUETTI App Scan the QR code below or search "BLUETTI" in the App Store or Google Play to download the BLUETTI App. For more details, please refer to BLUETTI APP INSTRUCTIONS. JUST POWER ON... -
Page 21: Specifications
11. Specifications Model AC2A Battery Capacity 204.8Wh / 8Ah Cell Type Lithium Iron Phosphate (LiFePO , LFP) AC + DC Input 270W Max. Weight 3.6kg / 7.9lbs Dimensions (L × W × H) 250mm × 150mm × 180mm / 9.8in × 5.9in × 7.1in Charging Temperature 0°C to 40°C / 32°F to 104°F... -
Page 22: Button Operation Instructions
Buttons simultaneously and hold Mode If you do not perform any operation in for more than 2 seconds till the 1 minute, the AC2A will automatically output frequency flashes exit the Setting Mode, and no changes will be saved. The flashing setting item is selected and editable. -
Page 23: Troubleshooting
13. Troubleshooting In the Setting Mode, press and hold the DC Power Button for more than 2 seconds until the error code appears on the display. Please refer to the table below for helpful guidance. Error Code Alarm Icon Description Troubleshooting Check if the power consumption of your E001... - Page 24 Check if the grid frequency is too high. Grid overfrequency Contact your local power provider if E115 necessary. Check if the grid frequency is too low. Grid underfrequency Contact your local power provider if E116 necessary. Please contact BLUETTI support for Others assistance. JUST POWER ON...
-
Page 25: Appx. 1 Estimating Operation Time
Operation time = Battery Capacity (Wh) x DoD x η ÷ (Load Power + AC2A Self-con- sumption) Note: DoD refers to the depth of discharge. AC2A works at 90% DoD for longer battery life. η is the conversion efficiency of the inverter, typically over 85% for AC2A. -
Page 26: Appx. 2 Faq
Please evaluate the total constant load of your devices. If it doesn't exceed the Max. output power of AC2A (300W), you can use this power station to run your devices. Note: Some devices with built-in motors or compressors may start at 2-4 times the rated power, which can easily overload the AC2A. -
Page 27: Appx. 3 Fcc Statement
Appx. 3 FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. -
Page 28: Appx. 4 Ic Caution
Appx. 4 IC Caution This device contains licence-exempt transmitter(s) / receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. -
Page 29: Appx. 5 Consignes De Sécurité
Évitez tout démontage, tout remplacement des composants ou toute modification des codes logiciels non autorisés. BLUETTI n'est pas responsable des dommages résultant des circonstances suivantes : • Les cas de force majeure tels que les tremblements de terre, les incendies, les tempêtes, les inondations ou les coulées de boue. - Page 30 d. L'utilisation d'un accessoire non recommandé ou vendu par le fabricant peut entraîner un risque d'incendie, d'électrocution ou de blessure. e. Pour réduire le risque d'endommagement de la fiche et du câble électriques, tirez au niveau de la fiche plutôt que sur le cordon lors du débranchement. f.
- Page 31 p. N'utilisez PAS le produit dans des conditions humides. Si le produit est mouillé, veuillez le sécher soigneusement avant de l'utiliser. q. Veuillez assurer une ventilation adéquate pendant l'utilisation et ne pas obstruer les ouvertures du ventilateur. Une ventilation inadéquate peut causer des dommages permanents sur le produit.
- Page 32 CA. Si vous le chargez à l'aide de l'énergie solaire, assurez-vous que votre système solaire fournit une puissance supérieure à 100 W. BLUETTI n'est pas responsable des dommages causés à l'équipement en raison du non-respect des consignes ci-dessus.
- Page 33 SHENZHEN POWEROAK NEWENER CO., LTD. Add: F19, BLD No.1, Kaidaer, Tongsha Rd No.168, Xili Street, Nanshan, Shenzhen, China USA Agent Company: BLUETTI POWEROAK INC Add: 6185 S VALLEY VIEW BLVD STE D LAS VEGAS NEVADA 89118 United States FRN: 0033559824...
- Page 34 P/N:17.0303.0643-01A1...
- Page 36 Cer ti fi cate Inspector: Q C :...
