FUEL SYSTEM
3.2.3.

REMOVING THE DELIVERY FILTER

•
Remove the whole fuel supply pump unit.
NOTE: Have the appropriate special tool OPT at hand:
- Aprilia part# 0277295 (hose clamp installation pliers).
CAUTION
Upon installation, replace the hose clamp that
has been removed with a new one having the
same dimensions.
Do not attempt to reinstall the removed hose
clamp, since it is unusable.
Do not replace the removed hose clamp with a
screw clamp or with other types of clamp.
•
Release the hose clamp (1).
•
Slip the pipe off the filter.
•
Release the hose clamp (2).
• Slip the filter off the pipe.
CAUTION
Do not use filters that have already been used.
•
Replace the filter with a new one of the same type.
3 - 14
RSV 1000 R - RSV 1000 R FACTORY
