Pinout
Pin
Signal / Function
1
FORCE_RECOV#
2
GND
3
BOOT_SEL0#
4
GND
J44
5
BOOT_SEL1#
6
GND
7
BOOT_SEL2#
8
GND
5.2. V-TCON Selection Jumper
Reference Designator: – J60
Description
The J60 voltage selection jumper allows selecting the V-TCON voltage level for V-By-One display between
5V/10V/12V.
Component drawing
Figure 46 Connector – J60
Pin
Signal / Function
1
V_TCON_12V
J60
2
V_3V3_S0
3
V_TCON_10V
Functional table.
See voltage selection information printed on the PCB-Silkscreen below the J60.
V_TCON
5V
10V
12V
Force V-TCON DCDC enable override
(V-TCON disabled)
12048321 Rev. 01 (Draft)
Pin Type
Signal Description
I (1.8V)
Boot-Strap Input
GND
Connected to ground potential of the PCB
I (1.8V)
Boot-Strap Input
GND
Connected to ground potential of the PCB
I (1.8V)
Boot-Strap Input
GND
Connected to ground potential of the PCB
I (1.8V)
Boot-Strap Input
GND
Connected to ground potential of the PCB
Pinout
Pin Type
Signal Description
V-TCON 12V selection input, high active
I
Pull-down 10kOhm on CB
Power 3.3V (S0)
Power for selektion pins
V-TCON 10V selection input, high active
I
Pull-down 10kOhm on CB
V_TCON_10V
V_TCON_12V
0
0
1
0
0
1
1
1
DATA MODUL AG | www.data-modul.com
65
