Use this area to record important information about your Sports-LITE kit. UNIT SERIAL NUMBERS You will be required to supply the products serial numbers when contacting Ritelite (Systems) Ltd or one of Ritelite’s approved dealers about parts and service. CONTENTS...
Section 1: INTRODUCTION & APPLICATIONS FOR USE The Sports-LITE is designed as a simple to use but powerful portable sports LED lighting system. It should only be used as a device to provide light as designed and for no other purpose. All users must read, understand and obey these safety rules and operating instructions before operating the Sports-LITE lighting system.
Page 4
TIP OVER HAZARDS • Do not raise the mast until the Sports-LITE is positioned level on a firm, flat, horizontal surface with all three support legs correctly deployed and locked. • Do not place the Sports-LITE on a smooth low friction surface even if firm and level. e.g. snow/Ice.
Page 5
CRUSHING HAZARDS • Ensure the Sports-LITE is set up on a firm and horizontal flat surface. • Do not raise the mast until the Sports-LITE is positioned level on a firm horizontal flat surface with all three support legs correctly deployed and locked. •...
Page 6
• The manufacturer shall not be liable for any changes made to the device nor for any damage resulting from such changes. • The Sports-LITE is not designed to be setup / used on a live public highway.
Charger - Input 100-240V 1A Max AC 50/60Hz 55W Mains input via 110V/240V plug/cable as per customer/country specific requirements. Check with Ritelite (Systems) Ltd for your specific requirements. Battery – 7S Lithium Ion 7.8AH nominally 25.9V Light Head – 80W...
Section 4: SETTING UP THE SPORTS-LITE Inspect the proposed area for use. An inspection of the proposed area in which to set up the Sports-LITE is necessary to ensure it is suitable for safe operation. This inspection should be performed by the operator prior to moving the Sports-LITE into position.
LITE must be removed from service until it has been repaired. Maintenance and repairs can be executed only by authorised personnel. If any person maintaining or repairing the device is in any doubt, they should contact their dealer or Ritelite (Systems) Ltd. PRE-OPERATION INSPECTION Check the following parts or areas for any signs of damage or missing parts.
4b) SETUP OPERATION SETUP VIDEO & RESOURCES 1. Plan the suitable location(s) for the light(s)to be 2. Locate the leg release knob and slacken by setup to maximise the spread of light for the task. rotating is an anti-clockwise direction. Remove the tripod from it’s storage bag.
Page 11
5. Re-tighten the leg release knob by turning in a 6. Remove the light head from its storage bag. Check clockwise direction. Do not over tighten. the light head locking knob is fully undone. 7. Place the battery pack into the bracket. Only use 8.
Page 12
9. Connect the battery cable to the light head 10. Push the connector in until it clicks into place. cable, it only fits one way. This ensures a good water resistant connection. Dependant on battery model the light may switch on as soon as this connection is made.
Page 13
13. The head has a limited level of adjustment for 14. Press the button the rear of the unit to turn the optimum illumination of the ground. Tilt the head back power on. The light-head unit will now illuminate. depending on the area to be illuminated. Note that the The battery level lights will also illuminate at the limited movement is intentional and that the advanced same time and stay on whilst the head is running,...
Page 14
17. Re-tighten the mast knob by rotating in a clockwise 18. The Sports-LITE is now setup and ready for use. direction. Do not over tighten.
4c) BREAKING DOWN OPERATION Breaking down the Sports-LITE to put it away is a reverse of the setting up operation. 1. Slacken off the mast knob by rotating in an anti- 2. Press and hold the lever below the knob. The clockwise direction.
Page 16
6. IMPORTANT Disconnect the battery cable by 5. Lift the light head off the unit and place on the pressing in the tab of the connector as shown above, ground. If the head is hot at end of use allow to cool then gently pull the connectors apart.
Page 17
9. Once the light head has cooled down place back 10. Unscrew the tripod leg securing knob by in it’s storage bag. If transporting the batteries in rotating in an anti-clockwise direction. the head unit in the bag, ensure the battery cable is disconnected first.
Page 18
13. Place the tripod back inside it’s storage bag. As you lower the mast always be conscious of other personnel and the surrounding area above and around the Sports-LITE. Take extra care handling light heads when packing the Sports-LITE away for transport in case housings are still hot.
The single charger uses a figure of 8 mains input cable, multiple country mains input plug types can be catered for and provided for on request. Please ask your distributor or Ritelite (Systems) Ltd.
Page 20
3. After turning on the mains power to the charger 4. Charging from empty will take approximately 6 the charger indication light will glow red. The state hours. Once charged the state of charge indicator of charge (SOC) can be seen on the battery itself on the battery will show all status LED’s lit (one red as it charges up.
Be aware of the light required for the time it takes to finish the task in hand and pack away. 5c) BATTERY CARE For advice on how to look after your lithium batteries to maximise life and performance please visit www.ritelite.co.uk/lithium-battery-care/ or scan the QR code below. LITHIUM BATTERY CARE...
The use of spares other than original parts from Ritelite (Systems) Ltd will invalidate any warranty. ADVICE ON DISPOSAL OF RITELITE PRODUCTS AT END OF LIFE For our latest advice on the disposal of Ritelite products at end of life please visit the link below. https://www.ritelite.co.uk/disposal-advice DISCLAIMER OF WARRANTY For details about the warranty offered on Ritelite products please visit the link below.
Section 7: ACCESSORIES FOR THE SPORTS-LITE TRAINING KITS TRIPOD BATTERY CHARGER LITHIUM BATTERY LSPL/TRIPOD LSPL/CHARGER LSPL/BATT200 6-WAY CHARGER 4-WAY CHARGER 5-WAY CHARGER LSPL/6WAYCHARGER LSPL/4WAYCHARGER LSPL/5WAYCHARGER FOR 2 UNITS FOR 2 UNITS STABILITY KIT HEAD STORAGE BAG TRIPOD STORAGE BAG LSPL/STABILITYKIT LSPL/HEADBAG LSPL/TRIPODBAG FULL RANGE OF ACCESSORIES...
Page 24
No part of this manual may be reproduced in any form or by any means, electronic or mechanical without express written permission from Ritelite (Systems) Ltd. Any type of reproduction or distribution not authorized by Ritelite (Systems) Ltd represents an infringement of valid copyrights, and violators will be prosecuted. We expressly reserve the right to make technical modifications, even without due notice, which aim at improving our products or their safety standards.
