Car Seat
WARNING
Carefully read and understand all instructions and warnings in
this manual. Failure to properly use this Car Seat increases the
risk of SERIOUS INJURY or DEATH in a sudden stop or crash.
KEEP INSTRUCTIONS FOR FUTURE USE.
Store this manual in the pocket provided on the back of the seat.
Car Seat
1
2
3
Stage
Stage
Stage
Toddler Car Seat
High-back Booster
Backless Booster
with Built-in
Car Seat
Car Seat
Harness
OWNER'S MANUAL
Para instrucciones en Español, conéctese a
www.babytrend.com o llamar al: 1-800-328-7363.
Convenience through innovation and thoughtful design
www.babytrend.com
Store this manual in the pocket provided
on the side of the Car Seat Base.
Baby Trend, Inc.
13048 Valley Blvd.
Fontana CA 92335
1-800-328-7363
(8:00am ~ 4:30pm PST)
www.babytrend.com
WARNING
Carefully read and understand all instructions and warnings in
this manual. Failure to properly use this Car Seat increases the
risk of SERIOUS INJURY or DEATH in a sudden stop or crash.
KEEP INSTRUCTIONS FOR FUTURE USE.
Store this manual in the pocket provided
on the side of the car seat base.
Stage 1
Stage 2
Toddler Car Seat
High-back
with Built-in
Booster Car Seat
Harness
Hybrid 3-in-1 Car Seat
OWNER'S MANUAL
Para instrucciones en Español, conéctese a
www.babytrend.com o llamar al: 1-800-328-7363.
Copyright © 2021, Baby Trend, Inc.
Car Seat
Stage 3
Backless Booster
Car Seat
FB58
EFB58FF_40_110120U
