Delta Children babyGap Legacy 6 Drawer Dresser Instructions Manual
  1. Manuals
  2. Brands
  3. Delta Children Manuals
  4. Indoor Furnishing
  5. babyGap Legacy 6 Drawer Dresser
  6. Instructions manual

Delta Children babyGap Legacy 6 Drawer Dresser Instructions Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Read all instructions
before assembly and use.
KEEP INSTRUCTIONS FOR
FUTURE USE.
EN
Style #:
___________
Lot:
___________
A
REV
Date:
___________
Before contacting Delta Consumer
Experience Center please ensure this
information matches the information
found on the label on the Back Panel.
To Make Assembly Even
Easier Watch Video Here!
ADULT ASSEMBLY REQUIRED
Due to the presence of small parts during assembly,
keep out of reach of children until assembly is complete.
This product is not intended for institutional or commercial use.
6 Drawer Dresser
For Questions or
to Contact Us:
DeltaChildren.com/Help
If unable to access website, please email
wcs@DeltaChildren.com
Expect longer response times via email.
May 31, 2022, 43033, R2

Advertisement

loading
Need help?

Need help?

Do you have a question about the babyGap Legacy 6 Drawer Dresser and is the answer not in the manual?

Questions and answers

Related Manuals for Delta Children babyGap Legacy 6 Drawer Dresser

Summary of Contents for Delta Children babyGap Legacy 6 Drawer Dresser

  • Page 1 6 Drawer Dresser Read all instructions For Questions or To Make Assembly Even before assembly and use. to Contact Us: Easier Watch Video Here! DeltaChildren.com/Help KEEP INSTRUCTIONS FOR FUTURE USE. If unable to access website, please email wcs@DeltaChildren.com Expect longer response times via email. Style #: ___________ ADULT ASSEMBLY REQUIRED...
  • Page 2 Cómodade 6 Gavetas Para facilitar más aun el Lea todas las instrucciones Para preguntar o para ensamblaje ver el video aquí contactarnos : antes de ensamblar y usar. DeltaChildren.com/Help MANTENGA LAS Si no puede acceder el sitio web, por INSTRUCCIONES PARA SU favor envíenos un email a USO FUTURO.
  • Page 4 B A B Y S A F E S L E E P T I P S Visit Deltachildren.Com/Pages/Crib-Safety-Tips for more information Read all warnings and DO NOT place any follow all instructions. items in the crib. The safest place for your Pillows and blankets have baby to sleep is in a caused infants to suffocate,...
  • Page 5 F U R N I T U R E S A F E T Y T I P S Visit Deltachildren.Com/Pages/Leaders-In-Safety for more information SERIOUS OR FATAL CRUSHING INJURIES CAN OCCUR FROM FURNITURE TIP-OVER. NEVER open more than Read all warnings and one drawer at a time.
  • Page 6 C O N S E J O S P A R A U N S U E Ñ O S E G U R O P A R A L O S B E B É S Visite Deltachildren.Com/Pages/Crib-Safety-Tips para obtener más información Lea todas las NO coloque artículos advertencias y siga...
  • Page 7 C O N S E J O S D E S E G U R I D A D S O B R E M U E B L E S Visite Deltachildren.Com/Pages/Leaders-In-Safety para obtener más información PUEDEN PRODUCIRSE LESIONES GRAVES O MORTALES POR APLASTAMIENTO AL VOLCARSE MUEBLES.

  • Page 8: Notes On Assembly

    NOTES ON CARE AND MAINTENANCE: - Do not scratch or chip the finish. - Inspect the product periodically, contact Delta Children's Products for replacement parts or questions. - Do not store the product or any parts in extreme temperatures and conditions such as a hot attic or a damp, cold basement.

  • Page 9: Información Sobre El Uso

    NOTAS SOBRE SU CUIDADO Y MANTENIMIENTO: - No arañe ni desconche el acabado. - Inspeccione el producto con regularidad, póngase en contacto con Delta Children’s Products para el recambio de partes o para formular preguntas. - No guarde el producto ni ninguna de sus partes a temperaturas ni en condiciones extremas como un ático caluroso o un sótano húmedo y frío.
  • Page 10 PARTS: MAKE SURE THAT ALL PRE-ASSEMBLED PARTS ARE TIGHT PIEZAS: ASEGÚRESE DE QUE TODAS LAS PIEZAS PRE-ENSAMBLADAS ESTÁN BIEN APRETADAS. Right Drawer Rail x1 Barra derecho de la Top Panel x1 gaveta Panel superior #43021 #43014 Left Side x1 Right Side x1 Left Drawer Rail x1 Center Panel Lado izquierdo...
  • Page 11 PARTS: HARDWARE KITS PART#43032 PIEZAS: EL KIT DE HERRAMIENTAS - PIEZA #43032 50mm Bolt x30 30mm Bolt x14 Crescent Washer x12 Perno 50mm Perno 30mm Arandela de media luna Φ8x30mm Dowel x36 Pasador Φ8x30mm 12mm Screw x36 10x15mm Barrel Nut x2 Tornillo 12mm Tuerca cilíndrica 10x15mm Back Panel Screw x22...
  • Page 12 Hardware System - Review Before Assembly Revise Antes De Armar- Elementos De Fijacion Y Ensamble 50mm Bolt Perno 50mm Crescent Washer Arandela de Media Luna 1. Insert the Dowels in the Rail into the holes in the Post. 1. Inserte los pasadores del Riel en los agujeros del Poste.
  • Page 13 Install (1) bolt and (1) crescent washer at a time. Tighten until it looks like the picture. Instale (1) perno y (1) Arandela de media luna al mismo tiempo. Apriételos hasta que quede como en la ilustración. Tighten the bolt with the ball end screwdriver.
  • Page 14 STEP 1 PASO 1 Parts and tools required to complete step Piezas y herramientas necesarias para completar este paso 50mm Bolt x4 Crescent Washer x4 Perno 50mm Arandela de media luna Φ8x30mm Dowel x8 Pasador Φ8x30mm M4 Allen Wrench Llave Allen M4 M4 Ballend Screwdriver destornillador M4 con cabeza de bola Attach the Top Front Rail (Part E), Left...
  • Page 15 FF x8...
  • Page 16 STEP 2 PASO 2 Parts and tools required to complete step Piezas y herramientas necesarias para completar este paso 50mm Bolt x1 Crescent Washer x1 Perno 50mm Arandela de media luna Φ8x30mm Dowel x4 Pasador Φ8x30mm M4 Allen Wrench Llave Allen M4 M4 Ballend Screwdriver destornillador M4 con cabeza de bola Attach the Center Panel (Part V)
  • Page 18 STEP 3 PASO 3 Parts and tools required to complete step Piezas y herramientas necesarias para completar este paso 50mm Bolt x5 Crescent Washer x5 Perno 50mm Arandela de media luna Φ8x30mm Dowel x10 Pasador Φ8x30mm M4 Allen Wrench Llave Allen M4 M4 Ballend Screwdriver destornillador M4 con cabeza de bola Attach the Right...
  • Page 19 FF x10...
  • Page 20 STEP 4 PASO 4 Parts and tools required to complete step Piezas y herramientas necesarias para completar este paso 50mm Bolt x5 Perno 50mm 30mm Wood Dowel x6 Barrel Nut x2 Pasador de Madera 30mm Tuercacilíndrica M4 Ballend Screwdriver M4 Allen Wrench destornillador M4 con cabeza de bola Llave Allen M4 Flat Screwdriver –...
  • Page 21 CC x5 FF x6...
  • Page 22 STEP 5 PASO 5 Parts and tools required to complete step Piezas y herramientas necesarias para completar este paso 30mm Bolt x4 Perno 30mm M4 Allen Wrench Llave Allen M4 Attach the Bottom Panel (Part R) using Fije el Panel inferior (Pieza R) utilizando (4) (4) 30mm bolts (Part GG).
  • Page 24 STEP 6 PASO 6 Parts and tools required to complete step Piezas y herramientas necesarias para completar este paso 50mm Bolt x2 Crescent Washer x2 Perno 50mm Arandela de media luna 30mm Bolt x2 Φ8x30mm Dowel x4 Perno 30mm Pasador Φ8x30mm M4 Allen Wrench Llave Allen M4 M4 Ballend Screwdriver...
  • Page 25 FF x4...
  • Page 26 STEP 7 PASO 7 Parts and tools required to complete step Piezas y herramientas necesarias para completar este paso 50mm Bolt x7 Perno 50mm 30mm Bolt x2 Perno 30mm M4 Allen Wrench Llave Allen M4 M4 Ballend Screwdriver destornillador M4 con cabeza de bola Attach the Assembly from Step 7 to the Fije el ensamblaje del paso 7 al conjunto assembly from step 6 using (2) 30mm...
  • Page 28 STEP 8 PASO 8 Parts and tools required to complete step Piezas y herramientas necesarias para completar este paso 50mm Bolt x6 Perno 50mm 30mm Wood Dowel x4 Pasador de Madera 30mm M4 Allen Wrench Llave Allen M4 Attach the Top Panel (Part A) using Fije el Panel Superior(Pieza A) utilizando (6) 50mm bolts (Part CC) and (4) Pernos 50mm (Pieza CC) y (4)
  • Page 30 STEP 9 PASO 9 Parts and tools required to complete step Piezas y herramientas necesarias para completar este paso 30mm Bolt x6 Perno 30mm M4 Allen Wrench Llave Allen M4 Attach the Top Panel (Part A) using Fije el Panel Superior(Pieza A) utilizando (6) 30mm bolts (Part GG).
  • Page 32 STEP 10 PASO 10 Parts and tools required to complete step Piezas y herramientas necesarias para completar este paso Phillips Screwdriver – Not included Back Panel Screw x22 Destornillidor Phillips – no incluido Tornillo de Panel Trasero No drills necessary. Do not use power screwdriver.
  • Page 33 AA x 22...
  • Page 34 STEP 11 Tipover Restraint PASO 11 Protección contra volcamiento Parts and tools required to complete step Piezas y herramientas necesarias para completar este paso WARNING ADVERTENCIA Use of tip-over restraints may only El uso de herramientas de contención de reduce, but not eliminate, the risk of vuelcos tan solo puede reducir, pero no tip-over.
  • Page 35 NOTE: Be sure to attach any accessory items to case before completing this step. 7)Feed the Tipover Restarint through the hole as you place the dresser in it’s final position. NOTA: Asegúrese de fijar todos los accesorios a la carcasa antes de completar este paso.
  • Page 36 STEP 12 PASO 12 Phillips Screwdriver – Not included Destornillidor Phillips – no incluido 20mm Screw x12 Tornillo 20mm No drills necessary. Do not use power screwdriver. No hace falta taladrar. No utilice destornilladores eléctricos Slide the Left Drawer Bottom (Part G) Deslice la Fondo izquierdo...
  • Page 37 Label “Delta” Etiqueta " Delta " Label “GAP” Ettiqueta "GAP"...
  • Page 38 STEP 13 PASO 13 Parts and tools required to complete step Piezas y herramientas necesarias para completar este paso 40mm Screw x12 Plastic Barrel Nut x12 Tornillo 40mm Tuercacilíndricaplástica Phillips Screwdriver – Not included No drills necessary. Destornillidor Phillips – no incluido Do not use power screwdriver.
  • Page 40 STEP 14 PASO 14 Parts and tools required to complete step Piezas y herramientas necesarias para completar este paso Knob Screw x6 Knob x6 Tornillo para Perilla Perilla Phillips Screwdriver – Not included Destornillidor Phillips – no incluido No drills necessary. Do not use power screwdriver.
  • Page 42 STEP 15 PASO 15 Parts and tools required to complete step Piezas y herramientas necesarias para completar este paso Phillips Screwdriver – Not included Destornillidor Phillips – no incluido 20mm Screw x12 Tornillo 20mm No drills necessary. Do not use power screwdriver. No hace falta taladrar.
  • Page 44 STEP 16 PASO 16 Parts and tools required to complete step Piezas y herramientas necesarias para completar este paso 40mm Screw x12 Plastic Barrel Nut x12 Tornillo 40mm Tuercacilíndricaplástica Phillips Screwdriver – Not included No drills necessary. Destornillidor Phillips – no incluido Do not use power screwdriver.
  • Page 46 STEP 17 PASO 17 Parts and tools required to complete step Piezas y herramientas necesarias para completar este paso Knob Screw x3 Knob x3 Tornillo para Perilla Perilla Phillips Screwdriver – Not included Destornillidor Phillips – no incluido No drills necessary. Do not use power screwdriver.
  • Page 48 STEP 18 PASO 18 OR, O Allen Wrench Llave Allen Left/Izquiredo Press lever on right glide down Empujar la palanca a la dere- cha se deslizan por Lift lever on left glide up izquierda se deslizan hacia arriba Right/Derecho...
  • Page 49 The silver portion of the glide must be pulled to the front of the glide when assembling the drawer into the case. La parte plateada de la guía de la gaveta debe estar al frente de la guía cuando se está armando la cómoda.
  • Page 50 STEP 19 PASO 19 Parts and tools required to complete step Piezas y herramientas necesarias para completar este paso 12mm Screw x18 Tornillo 12mm No drills necessary. Phillips Screwdriver – Not included Do not use power screwdriver. Destornillidor Phillips – no incluido No hace falta taladrar.
  • Page 52 STEP 20 PASO 20 Parts and tools required to complete step Piezas y herramientas necesarias para completar este paso Install the drawers in the case body. Instale las gavetas en el cuerpo del Carefully align the Drawer Guides on mueble. Alinee cuidadosamente las guías each drawer with the Drawer Guides de gaveta en cada una de ellas con las on the case.
  • Page 53 Label “Delta” Etiqueta " Delta " Label “GAP” Ettiqueta "GAP"...

  • Page 54: Limited Warranty

    Limited Warranty: This Delta Product is warranted to be free from defects for a period of 90 days from the date of purchase under normal use. If a product is defective during this period, we will at our option repair or replace the defective part or product. This limited warranty extends only to the original retail purchaser and is valid only when supplied with proof of purchase, or if received as a gift, when the registration is on file with Delta.
  • Page 55 SAFETY LEADERS Visit Deltachildren.Com/Pages/Leaders-In-Safety for more information SAFE MATERIALS PRODUCTS YOU CAN TRUST WE GO ABOVE & BEYOND...
  • Page 56 LÍDERES EN LA SEGURIDAD Visite Deltachildren.Com/Pages/Leaders-In-Safety para más información MATERIALES SEGUROS PRODUCTOS CONFIABLES ESTAMOS POR ENCIMA Y MÁS ALLÁ...
